Absen indoor LED displays are direct view video wall tiles built for permanently installed interior spaces — lobbies, control rooms, boardrooms, broadcast studios, retail and command centres. Pixel pitches run from fine-pitch 1.2mm up to 10mm, across the A-Series, A25 Series and Acclaim ranges.

Pixel pitch is set by the nearest viewer

The working rule is roughly one metre of viewing distance per millimetre of pitch. A 2.5mm wall reads cleanly from about 2.5 metres; a 10mm wall needs ten.

Specify from the closest seat, not the average. In a lobby where people walk past the wall, that distance is a metre or less — which is why fine pitch costs what it does, and why an under-specified wall looks wrong from exactly the position people stand in.

Choosing within the indoor range

• A-Series (A0421, A0621, A0821) — 4.44mm, 6.66mm and 8mm high-brightness cabinets in several cabinet sizes, for general indoor video wall work.
• A25 Series (A0425, A0625, A0825, A1025) — 4.44mm through 10mm on a 1440-tall cabinet, which changes the array arithmetic and often suits taller walls with fewer seams.
• Acclaim V3 — fixed 4K UHD panels at 27-inch module size, for straightforward 4K walls without array calculation.

Walls build in whole cabinets

A video wall is assembled from a fixed cabinet size, so finished dimensions are multiples of that cabinet rather than whatever the architect drew. Work the array out in cabinets first and confirm it against the available wall, including the structure behind it — a dvLED wall is heavy, and the mounting substrate matters as much as the tiles.

Service access is decided before installation too: front access or rear access depends on the mount, and retrofitting the other way means taking the wall down.

What else the wall needs

Tiles alone do not make a working wall. Each installation needs a mounting system matched to the substrate, a video processor sized to the pixel count, power distribution, data cabling and commissioning to align brightness and colour across every cabinet. Those items are quoted alongside the tiles and are a significant part of the budget.

For meeting rooms where a fixed-size screen is simpler than an array, see the Absenicon all-in-one range. For exterior work, see outdoor displays.

Creation Networks sizes the array against the room and the nearest viewing position, confirms the structure will carry it, specifies processing and power, and commissions the wall so brightness and colour match across every cabinet. CTS-D certified, nationwide, since 2006. Call 888-230-3661 or email sales@creationnetworks.net.
