Neat Bar Pro – Bar Pro + Shure MXA902 Ceiling Array Bundle

Product Overview

The Neat Bar Pro with Shure MXA902 bundle pairs Neat's flagship large-room collaboration bar with Shure's integrated ceiling array microphone and loudspeaker for premium audio coverage in larger meeting spaces. It combines the Bar Pro's dual 50MP camera system and 16-microphone array with the Shure MXA902's Single-Zone Automatic Coverage and IntelliMix DSP, giving integrators a complete camera-plus-ceiling-audio solution for Zoom Rooms and Microsoft Teams. Both devices are certified for Microsoft Teams, making this a strong fit for boardrooms and large conference rooms.

Product Description

This bundle addresses a common large-room challenge: pairing best-in-class camera framing with ceiling-based audio that keeps tables and walls clutter-free. The Neat Bar Pro provides the camera and codec, with a Pro 100 MP system combining a 113° wide-angle lens and a 70° telephoto lens plus an image depth sensor for up to 16x hybrid zoom. Neat Symmetry frames each in-room participant individually, and Neat Boundary defines the meeting zone so the camera ignores outside activity. The bar supports triple screens and wireless or HDMI content sharing.

The Shure MXA902 Integrated Conferencing Ceiling Array adds a ceiling-mounted microphone, a wide-dispersion loudspeaker, and onboard IntelliMix DSP in a single device. Its Single-Zone Automatic Coverage captures a 20 × 20 ft (6.1 × 6.1 m) area out of the box, shiftable up to 4 ft in any direction, while IntelliMix applies acoustic echo cancellation, noise reduction, automatic mixing, and automatic gain control for a clean far-end signal. The MXA902 installs with a single PoE+ network cable carrying power, control, and encrypted audio, and mounts in a ceiling grid, on a pole, or via wire-rope suspension.

Note that the Neat Bar Pro requires a Neat Pad for setup and room control. For the bar alone or with a controller, see the standalone Neat Bar Pro or the Bar Pro + Neat Pad bundle. The ceiling array is also sold separately as the Shure MXA902. For an all-in-one touchscreen alternative, compare the Neat Board Pro.

Key Features

• Camera + Ceiling Audio Solution — Neat Bar Pro framing paired with Shure ceiling microphone, loudspeaker, and DSP.
• Dual 50MP Camera System — Wide (113°) and tele (70°) lenses with up to 16x hybrid zoom for large rooms.
• Shure Single-Zone Automatic Coverage — Captures a 20 × 20 ft (6.1 × 6.1 m) area out of the box, shiftable up to 4 ft.
• Onboard IntelliMix DSP — Acoustic echo cancellation, noise reduction, automatic mixing, and AGC for a clean far-end mix.
• Wide-Dispersion Ceiling Loudspeaker — Integrated 2.5-inch loudspeaker reproduces natural far-end speech across the room.
• Neat Boundary & Symmetry — Defines the meeting zone and frames each participant individually.
• Triple-Screen Support — Bar Pro drives up to three screens for people and content.
• Microsoft Teams Certified — Both devices are certified for Microsoft Teams and support Zoom.
• Single-Cable Ceiling Install — MXA902 uses one PoE+ cable for power, control, and encrypted audio.

Typical Applications

• Boardroom — Premium camera framing with clutter-free ceiling audio.
• Conference room — Even voice capture across larger tables.
• Training room — Ceiling coverage for instructor and participant audio.
• All-hands room — Camera reach and room-wide audio for larger groups.
• Multi-purpose room — Flexible ceiling mounting for varied layouts.

Technical Specifications

Neat specifications sourced from the Neat Bar Pro device sheet; Shure specifications sourced from Shure MXA902 documentation. Confirm current details with each manufacturer before final system design.

Frequently Asked Questions

What is included in this bundle?
The Neat Bar Pro collaboration bar and the Shure MXA902 Integrated Conferencing Ceiling Array (microphone, loudspeaker, and DSP).

Why combine the Bar Pro with a ceiling array?
The pairing keeps the Bar Pro's camera framing while moving primary audio capture and reproduction to the ceiling, which keeps tables and walls clear and provides even coverage across larger rooms.

Does the Bar Pro still need a Neat Pad?
Yes. The Neat Bar Pro requires a Neat Pad for setup and room control; confirm whether one is needed for your deployment.

What size room does the Shure coverage suit?
The MXA902 covers a 20 × 20 ft (6.1 × 6.1 m) area out of the box, suited to small and medium rooms; the coverage can shift up to 4 ft for off-center mounting.

How is the ceiling array installed?
It mounts in a ceiling grid, on a pole, or by wire-rope suspension, with a recommended maximum height of 10 ft (3 m), and connects with a single PoE+ cable. Installation should be performed by qualified personnel per local regulations.

Are both devices certified for Teams and Zoom?
Yes. Both the Neat Bar Pro and the Shure MXA902 are certified for Microsoft Teams and support Zoom. Contact Creation Networks at sales@creationnetworks.net for system design and warranty support.
