Symetrix 80-0112 xOut 4
Product Overview
The Symetrix 80-0112 xOut 4 is a 4-channel Dante-to-analog output endpoint that converts 4 Dante network audio channels to 4 balanced analog line outputs. In a half-rack form factor, it delivers processed audio from a Symetrix DSP to analog amplifiers, speakers, or other devices at remote locations in a distributed AV installation — eliminating the need for analog cable runs from the central equipment rack to each output zone.
Product Description
The xOut 4 is the smaller-channel counterpart to the xOut 12 (80-0090) and is suited to installations where 4 analog outputs at a remote location are sufficient for the application — such as a single speaker zone, a small conference room audio zone, or a monitor feed location. All routing and channel assignment is managed in Symetrix Composer within the DSP site file. The half-rack chassis can be rack-mounted with the optional 1U Rack Tray (80-0107) or surface-mounted with the 1/2U Surface Mount Bracket (80-0108). For 4-channel bidirectional I/O, see the xIO 4x4 (80-0106).
Key Features
- 4 Balanced Analog Outputs — Line-level outputs for remote analog amplifiers or devices.
- 4 Dante Receive Channels — Receives 4 Dante channels for conversion to analog.
- Half-Rack Form Factor — Compact for flexible rack or surface installation.
- Composer Programmable — Channel routing managed in the Symetrix DSP site file.
- AES67 Compatible — Interoperates with non-Symetrix Dante devices.
Typical Applications
- Single-zone speaker output at a remote location in a distributed audio system
- Small conference room audio zone fed from a central Prism or EDGE Dante DSP
- Monitor output feed at a stage or lectern location
- Classroom or training room speaker feed over Dante
Technical Specifications
| Specification | Value |
|---|---|
| SKU | 80-0112 |
| Analog Outputs | 4 balanced line |
| Dante Receive Channels | 4 |
| AES67 | Supported |
| Form Factor | Half-Rack |
| Network | RJ45 Ethernet |
| Programming | Symetrix Composer |
