Description

12-Inch High Performance Subwoofer

Sound that makes performances and audiences truly come alive doesn’t come easy. But C Series loudspeakers put the power of unique Renkus-Heinz developments like Complex Conic horns to work for you. Versatile enclosure designs, go-anywhere hardware and rugged construction help solve your sound reinforcement challenges easily and quickly.

CX112S Non-Powered Loudspeakers
For use with external amplification

C112S subwoofers were developed as companion pieces to full-range C Series loudspeakers. They provide the high-impact sub bass energy needed in many venues.

Features

• Powerful 12-inch Subwoofers
Outstanding 40 Hz to 120 Hz, 133 dB peak SPL sub-bass performance.

• High Performance, High Power Woofers
With long-throw magnetic structures easily handle 500 Watts of program power.

• Built-In Lo-Pass Filter
May be bypassed to allow use of an external electronic crossover.

Applications

• Virtually any application where high-output, low frequency content is required

Permanent Installations

• High quality music/speech systems and surround systems for houses of worship, schools, performing art centers, night clubs, etc.

Portable Applications

• Live music reinforcement, DJ systems, houses of worship, schools, etc.

Technical Information
Sensitivity: CX112S 97 dB (1W/1m)
Max SPL: CX112S 127 dB peak, half space
CA112S-A
CA112S-RN
CA112S-RD		 124 dB peak, half space
Freq. Response: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 40 Hz to 120 Hz
LF Driver: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 SSL12-23 woofer, 250 W AES @ 8 Ohms, 500 W Pgm
Enclosure: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 11 Ply Hardwood, perforated metal grille
Finish: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 Black Paint
Power: CX112S 250 W AES @ 8 Ohms
500 W Pgm @ 8 Ohms
CA112S-A
CA112S-RN
CA112S-RD		 See SA650 Amplifier Specs
Connectors: CX112S Screw terminals & looping 4-pin Neutrik SpeakOn style connectors
CA112S-A
CA112S-RN
CA112S-RD		 See SA650 Amplifier Specs
Hardware: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 12 M10 Points, 1 x 35 mm pole socket
Dimensions: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 15″ w x 23-1/8″ h x 17-1/4″ d
381 mm w x 587 mm h x 438 mm d
Weight: CX112S
CA112S-A
CA112S-RN
CA112S-RD		 52 lbs / 23.6 kg, net

SA625 Amplifier Specs
Audio Connections: CA112S-A 2 x XLR-3, In & Loop-out, Analog
CA112S-RN 2 x XLR-3, In & Loop-out, Analog & AES
CA112S-RD 2 x XLR-3, In & Loop-out, Analog and AES
2 x RJ45 Dante Primary & Secondary Ethernet
Network Connections: CA112S-RN 2 x RJ45, Looping Ethernet/RHAON
CA112S-RD 2 x RJ45 Dante Primary & Secondary Ethernet/RHAON (Note: Dante and RHAON share a single or redundant Ethernet network.)
Maximum Input Level: CA112S-A +22 dBu, Analog,
CA112S-RN
CA112S-RD		 +22 dBu, Analog; 0 dBFS digital
User DSP: CA112S-RN
CA112S-RD		 Eight fully parametric filters, high and low shelf, high and low pass filters, delay to 340 ms.
Software: CA112S-RN
CA112S-RD		 RHAON II
Latency: CA112S-A
CA112S-RN		 6.25 ms
CA112S-RD 6.25 ms + Dante transport latency
Power Output: CA112S-A
CA112S-RN
CA112S-RD		 LF= 500 watts, @ 8 ohms. Multi-band peak and thermal limiting on all channels protects the drivers.
Mains Voltage: CA112S-A
CA112S-RN
CA112S-RD		 100-240 volts, 50/60 Hz auto-switching
Power Consumption: CA112S-A
CA112S-RN
CA112S-RD		 Idle: 200 mW. 1/8 power: 120 W (onset of limiting) 1/3 power: 240 W (hard limiting)
Power Connector: CA112S-A
CA112S-RN
CA112S-RD		 Neutrik powerCON TRUE-1
Temprature Limits: CA112S-A
CA112S-RN
CA112S-RD		 Max.: 140º F/60º C, with no direct sun exposure; Min.: -22º F/-30º C; leave unit on to keep interior warm below 32º F/0º C.
