Panasonic PT-VMW51U7 5,200 lm WXGA Laser LCD Projector / Digital Link / 4K Signal Input
Panasonic PT-VMW51U7 5,200 lm WXGA Laser LCD Projector / Digital Link / 4K Signal Input is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Panasonic PT-VMW51U7 5,200 lm WXGA Laser LCD Projector / Digital Li...
Product Overview
The Panasonic PT-VMW51U7 is a 5,200-lumen WXGA laser 3LCD projector built for fully lit conference rooms, classrooms, and commercial meeting spaces. With a 1.09–1.77:1 short-throw lens, lens shift, and Digital Link (HDBaseT) signal distribution, this installation projector gives AV integrators a bright, low-maintenance display that accepts up to a 4K signal input. The solid-state laser light source supports continuous operation, making it a practical commercial-grade projector for high-use rooms.
Product Description
The PT-VMW51U7 produces large, vivid images from 30 to 300 inches, driven by a 3-chip 0.64-inch LCD engine at native WXGA (1280 x 800) resolution. Its short-throw zoom lens projects a 60-inch image from roughly 4.6 feet, and optical zoom plus the Digital Zoom Extender push the effective throw to 2.21:1 for larger screens. Vertical lens shift of +44% and horizontal shift of ±20%, combined with ±35° keystone correction, give installers latitude to align the image on a ceiling-mounted or shelf-mounted deployment without distortion.
Connectivity covers two HDMI and two VGA inputs plus a Digital Link / HDBaseT RJ45 port that carries audio, video, control, and data over a single cable up to 492 feet in Long Reach Mode, reducing in-room hardware. The laser engine is rated up to 20,000 hours, supports 360° and portrait installation, and uses a reusable filter for lower maintenance overhead. For a higher-brightness WXGA option, compare the Panasonic PT-VMW61U7 (6,200 lm); for native WUXGA resolution in the same chassis family, see the Panasonic PT-VMZ51U7.
Key Features
- 5,200-Lumen Laser Light Source — Delivers a clear image in fully lit rooms while supporting continuous, low-maintenance operation.
- Native WXGA 3LCD Engine — Three-chip 0.64-inch LCD design produces equal white and color brightness with no single-chip color breakup.
- Short-Throw 1.09–1.77:1 Lens — Fills a large screen from a short distance, suiting compact conference rooms and classrooms.
- Lens Shift and Keystone Correction — Vertical +44% / horizontal ±20% optical shift and ±35° keystone simplify off-axis ceiling installs.
- Digital Link (HDBaseT) — Carries audio, video, control, and data over a single RJ45 run up to 492 ft, reducing in-room cabling.
- 4K Signal Input Support — Accepts sources up to 4096 x 2160 and scales them to the native panel.
- Flexible 360° Installation — Ceiling-mountable with full 360° and portrait projection for digital signage and angled deployments.
- Reusable Filter and 24/7 Capability — Lowers consumable cost and supports high-duty-cycle commercial use.
Typical Applications
- Conference Room — Short throw and 5,200 lumens fill the screen in lit rooms for presentations and video calls.
- Training Room — Large, bright image supports detailed content for groups.
- House of Worship — Bright, low-maintenance laser output suits frequent services with Digital Link signal runs.
- Multi-Purpose Room — 360° install flexibility and lens shift adapt to varied layouts.
- Commercial Meeting Space — HDBaseT distribution reduces in-room hardware for clean integration.
Technical Specifications
| Display System | 3-Chip 0.64" LCD |
|---|---|
| Native Resolution | 1280 x 800 (WXGA), 16:10 |
| Supported Signal | 720 x 480 up to 4096 x 2160 (4K input) |
| Brightness | 5,200 lumens |
| Dynamic Contrast | 3,000,000:1 |
| Light Source | Laser phosphor, up to 20,000 hrs (24,000 hrs low) |
| Throw Ratio | 1.09 to 1.77:1 |
| Optical Zoom | Manual 1.6x |
| Lens Shift | Vertical +44%, Horizontal ±20% |
| Keystone Correction | Vertical ±35°, Horizontal ±35° |
| Projection Size | 30" to 300" |
| Connectors | 2x HDMI, 2x VGA, 2x 3.5mm audio in, 1x audio out, RS-232 (DB-9), Digital Link/HDBaseT RJ45, LAN RJ45, USB-A |
| HDCP | Version 1.4 |
| Built-In Speaker | 10W mono |
| Fan Noise | 26 dB (low) / 36 dB (medium) |
| Power | 100–240 VAC, 50/60 Hz; 305 W max, 0.5 W standby |
| Operating Temp | 32 to 113°F / 0 to 45°C |
| Dimensions (W×H×D) | 399 × 133 × 348 mm (15.7 × 5.2 × 13.7 in) |
| Weight | 6.5 kg (14.3 lb) |
Competitor Comparison
| Criteria | Panasonic PT-VMW51U7 | Epson PowerLite L520U | Optoma ZU607T |
|---|---|---|---|
| Imaging Technology | 3-chip LCD; equal white and color brightness with no single-chip color breakup | 3-chip LCD; comparable equal color/white brightness architecture | Single-chip DLP; can show color-wheel artifacts to sensitive viewers |
| Native Resolution | WXGA (1280 x 800), accepts 4K signal input | WUXGA (1920 x 1200), higher native resolution | WUXGA (1920 x 1200), higher native resolution |
| Light Source | Laser phosphor rated up to 20,000 hrs | Laser phosphor, comparable solid-state lifespan | Laser phosphor, comparable solid-state lifespan |
| Signal Distribution | Digital Link / HDBaseT with Long Reach to 492 ft over one RJ45 | HDBaseT availability varies by configuration; verify on the model spec | HDBaseT availability varies by configuration; verify on the model spec |
| Lens Shift | Optical shift V +44% / H ±20% for off-axis installs | Optical lens shift offered; range varies by model spec | Optical lens shift offered; range varies by model spec |
| Throw / Install | Short-throw 1.09–1.77:1, 360° and portrait capable | Standard-throw installation lens; 360° capable | Standard-throw installation lens; 360° capable |
Competitor positioning reflects published architecture and resolution classes; confirm current competitor model specifications before procurement decisions.
Frequently Asked Questions
Does the PT-VMW51U7 support 4K sources?
Yes. It accepts signals up to 4096 x 2160 and scales them to its native WXGA panel. Native panel resolution remains 1280 x 800.
What is Digital Link and how far can it run?
Digital Link is Panasonic's HDBaseT implementation, carrying video, audio, control, and data over a single RJ45 cable up to 492 feet in Long Reach Mode with a compatible transmitter.
Can it be ceiling mounted at an angle?
Yes. Optical lens shift (V +44% / H ±20%) and ±35° keystone correction allow off-axis alignment, and the projector supports full 360° and portrait orientation.
How much screen distance do I need?
With a 1.09–1.77:1 throw ratio, a 60-inch image projects from roughly 4.6 feet. Multiply screen width by the throw ratio to plan placement.
What warranty and support are available?
The projector carries Panasonic's Pro AV warranty. Contact Creation Networks for current terms, extended coverage, and integration support.
