Panasonic PT-RZ17KU 16,800 Lumens (center), 3DLP Laser, WUXGA (1,920 x 1,200) Resolution, Filter-Free (No Lens, Black)
Panasonic PT-RZ17KU 16,800 Lumens (center), 3DLP Laser, WUXGA (1,920 x 1,200) Resolution, Filter-Free (No Lens, Black) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Panasonic PT-RZ17KU 16,800 Lumens (center), 3DLP Laser, WUXGA (1,9...
Product Overview
The Panasonic PT-RZ17KU is a 16,800-lumen WUXGA 3DLP laser projector for large-venue fixed installation and rental and staging. This large venue laser projector delivers vivid 3-chip DLP color from a compact, lightweight, filter-free chassis that installs in almost any orientation. Integrators specify the PT-RZ17KU when a venue needs dependable high WUXGA brightness and 24/7 reliability without 4K resolution or a heavy chassis.
Product Description
The PT-RZ17KU produces 16,800 lumens from a 3-chip DLP engine at native WUXGA (1,920 x 1,200), and can accept up to 4K signals while displaying on-screen via four-phase pixel-shift. Image tools including Dynamic Contrast, Gradation Smoother, and point-based black-level adjustment support clean edge-blending across flat and curved surfaces. A Multi-Laser Drive Engine limits brightness loss if a diode fails, and a Backup Input switches to a secondary source if the primary is interrupted. An Intel SDM-ready slot adds preferred terminals, while Smart Projector Control with NFC and Remote Preview Lite speed commissioning. With a 20,000-hour light source, hermetically sealed optics, and liquid cooling, it runs nearly maintenance-free in continuous operation. The projector ships without a lens; pair it with a Panasonic ET-D3LE-series lens. Step up to the PT-RZ24KU, or compare the 4K sibling PT-RQ18KU.
Key Features
- 16,800 Lumens, Native WUXGA — 3-chip DLP imaging at 1,920 x 1,200 delivers high brightness for large, bright venues.
- 4K Signal Input — Accepts up to 4K sources, displayed on screen via four-phase pixel-shift.
- Multi-Laser Drive Engine — Helps prevent visible brightness loss if a laser diode fails.
- Backup Input — Switches to a backup signal automatically if the primary source drops.
- Intel SDM-Ready Slot — Add proprietary or third-party function boards to match your signal plan.
- Filter-Free, Liquid-Cooled — Sealed optics and liquid cooling support 24/7 near-maintenance-free operation.
- Edge-Blending Tools — Dynamic Contrast, Gradation Smoother, and point-based black-level adjustment for multi-projector mapping.
- DisplayPort and Dual HDMI — One DisplayPort and two HDMI inputs simplify source integration.
Typical Applications
- Auditorium — Large auditoriums and lecture halls needing bright WUXGA imagery.
- House of Worship — Sanctuaries and worship venues running continuous schedules.
- Broadcast Studio — Studio backdrops and large-format displays where output matters more than 4K.
- All-Hands Room — Large all-hands and general-session spaces served by one high-output projector.
- Government Space — Briefing and simulation rooms requiring bright, low-maintenance projection.
Technical Specifications
| Display system | 3-Chip DLP |
|---|---|
| Native chip resolution | WUXGA (1,920 x 1,200) |
| On-screen resolution | Up to 4K UHD (3840 x 2160) via pixel-shift |
| Brightness | 16,800 lumens (center) |
| Aspect ratio | 16:10 |
| Contrast ratio | 25,000:1 |
| Light source | Laser phosphor |
| Light source life | 20,000 hours (full) / 24,000 hours (low) |
| Keystone correction | Vertical ±45°, Horizontal ±40° |
| Inputs/outputs | 2 x HDMI, 1 x DisplayPort, 2 x BNC, RS-232C in/out, RJ-45 LAN, USB-A; HDCP 2.3 |
| Expansion slots | 1 (Intel SDM-ready) |
| Lens | Optional ET-D3LE-series lenses (no lens included) |
| Fan noise | 46 dB (full) / 43 dB (low) |
| AC input | 100–240 VAC, 50/60 Hz |
| Power consumption | 1,260 W (full brightness) |
| Operating temperature | 0–45 °C (32–113 °F), 10–80% humidity |
| Dimensions (W x H x D) | 550 x 220 x 570 mm |
| Weight | 35 kg (77.2 lbs) |
Specifications sourced from Panasonic / vendor data. Verify lens-shift and final values against the current Panasonic PT-RZ17K spec sheet.
Competitor Comparison
| Criterion | Panasonic PT-RZ17KU | Barco UDX-W22 | Christie Crimson WU25 |
|---|---|---|---|
| Brightness | 16,800 lm center WUXGA, efficient mid-high output. | Approx. 22,000 lm WUXGA, higher output. | Approx. 25,000 lm WUXGA. |
| Imaging | Native WUXGA 3-chip DLP, accepts 4K input. | Native WUXGA 3-chip DLP. | Native WUXGA 3-chip DLP. |
| Reliability | Multi-Laser Drive Engine + Backup Input for live shows. | Sealed engine, redundancy varies. | Sealed engine, redundancy varies. |
| Form factor | 35 kg, compact and light for its class. | Larger, heavier chassis. | Large chassis. |
| Expansion | Intel SDM-ready slot for flexible I/O. | Barco-specific I/O options. | Christie-specific I/O options. |
| Best fit | High-brightness WUXGA installs prioritizing size and weight. | Barco-standard fleets. | Christie-standard venues. |
Frequently Asked Questions
Is the PT-RZ17KU a 4K projector? It is native WUXGA (1,920 x 1,200) and accepts up to 4K signals, displayed on screen via pixel-shift. For 4K Quad Pixel Drive imaging in the same class, consider the PT-RQ18KU.
Does it include a lens? No. It is a no-lens model that uses Panasonic ET-D3LE-series lenses. Select the lens by throw ratio for your screen and position.
How does it integrate into an AV system? Two HDMI inputs, one DisplayPort, RS-232C, and RJ-45 LAN handle sources and control, and the Intel SDM-ready slot adds optional terminals. HDCP 2.3 is supported.
How reliable is it for live events? The Multi-Laser Drive Engine limits brightness loss if a diode fails, Backup Input protects against signal loss, and the 20,000-hour sealed, liquid-cooled design supports continuous use.
What about warranty and support? The PT-RZ17KU carries Panasonic's commercial projector warranty and ProVideo service support. Creation Networks can advise on warranty, lens selection, and integration.
