Panasonic PT-RQ18KU 16,800 Lumens (center), 3DLP Laser, 4K (3840 x 2400) Resolution with Quad Pixel Drive, Filter-Free (No Lens, Black)
Panasonic PT-RQ18KU 16,800 Lumens (center), 3DLP Laser, 4K (3840 x 2400) Resolution with Quad Pixel Drive, Filter-Free (No Lens, Black) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Panasonic PT-RQ18KU 16,800 Lumens (center), 3DLP Laser, 4K (3840 x ...
Product Overview
The Panasonic PT-RQ18KU is a 16,800-lumen 3DLP laser projector with 4K Quad Pixel Drive resolution, built for large-venue fixed installation and rental and staging. This large venue laser projector pairs 3-chip DLP color with a compact, lightweight, filter-free chassis that installs in almost any orientation. Integrators specify the PT-RQ18KU when a project needs 4K on-screen detail and dependable high brightness without the size, weight, or budget of a 30,000-lumen-class unit.
Product Description
The PT-RQ18KU uses pixel-quadrupling Quad Pixel Drive to put up to 4K UHD (3840 x 2160) on screen from a 3-chip DLP engine driven by a 16,800-lumen laser light source. Image tools including Dynamic Contrast, Gradation Smoother, and point-based black-level adjustment support clean edge-blending across flat and curved surfaces for projection mapping. A Multi-Laser Drive Engine guards against brightness loss if a diode fails, and a Backup Input switches to a secondary signal if the primary is interrupted, both valuable on live shows. An Intel SDM-ready slot lets integrators add the input terminals a project requires, while Smart Projector Control with NFC and Remote Preview Lite speed commissioning. With a 20,000-hour light source, hermetically sealed optics, and liquid cooling, the projector runs nearly maintenance-free in continuous use. It ships without a lens; pair it with a Panasonic ET-D3LE-series lens. Step up to the PT-RQ25KU or PT-RQ35KU for more output, or compare the WUXGA PT-RZ17KU.
Key Features
- 16,800 Lumens, 4K Quad Pixel Drive — 3-chip DLP imaging with Quad Pixel Drive puts up to 4K UHD (3840 x 2160) on screen for large audiences.
- Multi-Laser Drive Engine — Helps prevent visible brightness loss if an individual laser diode fails during a show.
- Backup Input — Automatically switches to a backup signal if the primary source is interrupted.
- Intel SDM-Ready Slot — Add proprietary or third-party function boards to match input terminals to your signal plan.
- Filter-Free, Liquid-Cooled — Hermetically sealed optics and liquid cooling support 24/7 near-maintenance-free operation.
- Edge-Blending Tools — Dynamic Contrast, Gradation Smoother, and point-based black-level adjustment support multi-projector and curved-surface mapping.
- Compact, 360-Degree Install — Lightweight chassis mounts in any orientation, including ceiling and tilted rigging.
- DisplayPort and Dual HDMI — One DisplayPort and two HDMI inputs simplify source integration.
Typical Applications
- Auditorium — Large auditoriums and lecture halls needing 4K imagery on big screens.
- House of Worship — Sanctuaries and worship venues running continuous, multi-service schedules.
- Broadcast Studio — Studio backdrops and sets requiring 4K detail and edge blending.
- All-Hands Room — Large general-session and all-hands spaces served by one high-output projector.
- Government Space — Briefing and simulation rooms requiring bright, low-maintenance projection.
Technical Specifications
| Display system | 3-Chip DLP |
|---|---|
| On-screen resolution | Up to 4K UHD (3840 x 2160) via Quad Pixel Drive pixel-shift |
| Brightness | 16,800 lumens (center) |
| Aspect ratio | 16:10 |
| Contrast ratio | 25,000:1 |
| Light source | Laser phosphor |
| Light source life | 20,000 hours (full) / 24,000 hours (low) |
| Keystone correction | Vertical ±45°, Horizontal ±40° |
| Inputs/outputs | 2 x HDMI, 1 x DisplayPort, 2 x BNC, RS-232C in/out, RJ-45 LAN, USB-A; HDCP 2.3 |
| Expansion slots | 1 (Intel SDM-ready) |
| Lens | Optional ET-D3LE-series lenses (no lens included) |
| Fan noise | 46 dB (full) / 43 dB (low) |
| AC input | 100–240 VAC, 50/60 Hz |
| Power consumption | 1,280 W (full brightness) |
| Operating temperature | 0–45 °C (32–113 °F), 10–80% humidity |
| Dimensions (W x H x D) | 550 x 220 x 570 mm |
| Weight | 35 kg (77.2 lbs) |
Specifications sourced from Panasonic / vendor data. Verify lens-shift and final values against the current Panasonic PT-RQ18K spec sheet.
Competitor Comparison
| Criterion | Panasonic PT-RQ18KU | Barco UDX-4K22 | Christie M 4K25 RGB |
|---|---|---|---|
| Brightness | 16,800 lm center, efficient mid-high output. | Approx. 22,000 lm, higher output and price. | Approx. 25,000 lm RGB laser. |
| Imaging | 3-chip DLP with Quad Pixel Drive to 4K UHD. | Native 4K UHD 3-chip DLP. | Native 4K RGB pure-laser. |
| Reliability | Multi-Laser Drive Engine + Backup Input for live shows. | Sealed engine, redundancy varies by config. | RGB laser engine, premium service needs. |
| Form factor | 35 kg, compact and light for its class. | Larger, heavier chassis. | Large RGB-laser chassis. |
| Expansion | Intel SDM-ready slot for flexible I/O. | Barco-specific I/O options. | Christie-specific I/O options. |
| Best fit | 4K large-venue installs prioritizing size, weight, and value. | Higher-brightness Barco-standard fleets. | RGB color-critical premium work. |
Frequently Asked Questions
Does the PT-RQ18KU include a lens? No. It is a no-lens model that uses Panasonic ET-D3LE-series lenses. Choose the lens by throw ratio for your screen size and projector position.
Is it true 4K? It uses Quad Pixel Drive pixel-shift to put up to 4K UHD (3840 x 2160) on screen from a 3-chip DLP engine. It delivers 4K on-screen detail; for native 4K chips, consider the PT-RQ50KU.
How does it integrate into an AV system? Two HDMI inputs, one DisplayPort, RS-232C, and RJ-45 LAN cover most source and control needs, and the Intel SDM-ready slot adds optional terminals. HDCP 2.3 is supported.
How reliable is it for live events? The Multi-Laser Drive Engine limits brightness loss if a diode fails, Backup Input protects against signal loss, and the 20,000-hour sealed, liquid-cooled design supports continuous operation.
What about warranty and support? The PT-RQ18KU carries Panasonic's commercial projector warranty and ProVideo service support. Creation Networks can advise on warranty, lens selection, and integration.
