Panasonic ET-D75LE95 0.39:1, Fixed Ultra Short-Throw Lens (for use with all 3DLP projectors excluding the PT-RQ50KU)

Product Overview

The Panasonic ET-D75LE95 is a fixed ultra short-throw projector lens for 3-chip DLP projectors, designed for installations where projector-to-screen distance is severely limited. Using an integrated-mirror optical system, this ultra short-throw lens projects large images from very close range, making it well suited to lobbies, multi-purpose rooms, and house of worship installations where rear space is scarce. It is compatible with select Panasonic 3DLP projectors, excluding the PT-RQ50KU.

Product Description

The ET-D75LE95 has a fixed 7.5 mm focal length and f/2.5 aperture, and its mirror-based optical system enables a throw ratio around 0.39:1, projecting diagonal image sizes between 120 and 600 inches from short distances depending on the host projector. Because the lens sits close to the screen, it minimizes shadowing from presenters and keeps cabling and rigging compact in tight rooms. Lens shift varies by projector model, and the lens supports a range of Panasonic high-brightness 3-chip DLP installation projectors. For projects needing different coverage on the same projector platform, the catalog includes the immersive ET-D3LEF70 fisheye lens and the fixed-focus ET-D3LEW50. It pairs with compatible installation projectors such as the PT-RZ34KU.

Key Features

• Ultra Short-Throw Optics — An integrated-mirror system projects large images from very close to the screen.
• 0.39:1 Throw Ratio (model dependent) — Fills large surfaces where rear projection space is unavailable.
• 120 to 600-Inch Image Size — Supports a wide range of screen sizes across compatible projectors.
• Fixed 7.5 mm Focal Length, f/2.5 — Consistent optical performance for permanent installs.
• Broad 3DLP Compatibility — Works with select Panasonic 3-chip DLP projectors, excluding the PT-RQ50KU.

Typical Applications

• Multi-purpose rooms with limited rear space
• House of worship lobby and feature walls
• Auditorium short-throw installations
• Commercial meeting space and government space

Technical Specifications

Specifications sourced from Panasonic / vendor data. The published throw distance figure in the source data appears inconsistent and was omitted; confirm exact throw distance, per-model throw ratios, and lens shift against the current Panasonic ET-D75LE95 spec sheet and the host projector's lens compatibility chart before specifying.

Frequently Asked Questions

Which projectors is the ET-D75LE95 compatible with? It supports select Panasonic 3-chip DLP installation projectors and explicitly excludes the PT-RQ50KU. Confirm your specific model against Panasonic's lens compatibility chart.

How close can the projector sit to the screen? With a throw ratio around 0.39:1, the projector mounts very close to the screen, reducing presenter shadowing and the footprint in tight rooms.

What image sizes does it support? Diagonal image sizes from 120 to 600 inches, depending on the host projector.

Does the throw ratio change between projectors? Yes. The effective throw ratio and lens shift vary by projector model; verify against the compatibility chart for your unit.

What warranty applies? Coverage follows Panasonic's standard professional lens warranty; confirm current terms at the time of purchase.
