MaxHub V555T XBoard V7 Series 55" for Microsoft Teams Rooms, 4K Interactive Display

Product Overview

The MaxHub V555T XBoard V7 is a 55-inch Microsoft Teams Rooms certified interactive display designed for huddle rooms, small offices, and compact collaboration spaces requiring a full-featured, all-in-one Teams Rooms panel. The V555T delivers 4K UHD (3840×2160) on a 16:9 ADS panel with the complete XBoard V7 platform: Trident Lens triple camera system, 16-microphone array, 2.1-channel integrated speakers, and Windows 11 IoT compute. For organizations standardizing on the XBoard V7 Teams Rooms platform across multiple room sizes, the V555T provides a consistent certified experience at the 55-inch tier—the most compact option in the XBoard V7 MTR lineup.

Product Description

The V555T is the 55-inch variant of the XBoard V7 Teams Rooms line and shares the same hardware architecture as the 65-inch V655T, 75-inch V755T, and 86-inch V865T. The Trident Lens system integrates three 50-megapixel cameras (one panoramic at 99° diagonal, two telephoto) with AI auto-framing, speaker tracking, multi-speaker tracking, and 5× hybrid zoom—providing conference-quality video coverage of a huddle room or small conference space without an external camera bar. The 16-microphone array delivers 15-meter pick-up range at 180° with AI noise cancellation, acoustic echo cancellation, and auto gain control. The 2.1-channel speaker system (2×10W plus 20W subwoofer) provides clear room audio. Windows 11 IoT and the Teams Rooms application are pre-installed on the integrated 12th Gen Intel Core i5 compute module. The 50-point touch interface with 9H zero-parallax glass supports Windows Ink, direct annotation, and palm rejection. The OPS slot allows future compute module upgrades. For a larger Teams display, see the V655T 65" or the V755T 75". Browse the full range at Creation Networks.

Key Features

• 55" 4K UHD Display — 3840×2160 ADS panel with DLED backlight, 350 nits brightness, 1200:1 contrast, and 10-bit color (1.07B, 90% NTSC) in the most compact XBoard V7 MTR form factor.
• Microsoft Teams Rooms Certified — Factory MTR-certified, Windows 11 IoT and Teams Rooms pre-installed; ready for deployment in huddle rooms and small conference spaces.
• Trident Lens Triple Camera System — 3×50 MP cameras with AI auto-framing, speaker tracking, multi-speaker tracking, and 5× hybrid zoom; no external camera required for huddle room coverage.
• 16-Microphone Array — 180° capture, 15-meter range, AI noise cancellation, AEC, and AGC for clear voice pick-up in compact meeting spaces.
• 2.1-Channel Integrated Audio — 2×10W plus 20W subwoofer with AI spatial sound; no external speaker bar required.
• 50-Point Touch with Windows Ink — Zero-parallax 9H tempered glass (25% haze), 50-point IR touch, Windows Ink, direct annotation, palm rejection, and handwriting recognition.
• 12th Gen Intel Core i5 Compute — Integrated i5-1240P, 16 GB DDR4, 256 GB SSD running Windows 11 IoT; OPS slot for future module upgrades.
• Wi-Fi 6, Bluetooth 5.2 & Gigabit Ethernet — Full wireless and wired connectivity; MAXHUB Share, Miracast, AirPlay, Chromecast, and P2P wireless sharing supported.

Typical Applications

• Huddle room
• Conference room
• Commercial meeting space
• Training room
• Government space
• Multi-purpose room

Technical Specifications

Specifications sourced from MaxHub (maxhub.com).

Frequently Asked Questions

Is the V555T the right size for a small huddle room?
Yes. The 55-inch display is optimized for rooms seating 2–6 participants. The AI camera system with auto-framing and the 16-microphone array provide full coverage in compact spaces without requiring an external camera or microphone.

Is the V555T Microsoft Teams Rooms certified?
Yes. The V555T carries full Microsoft Teams Rooms factory certification. Windows 11 IoT and the Teams Rooms application are pre-installed. A Microsoft Teams Rooms license from Microsoft is required to activate the service.

Can the V555T run Zoom Rooms or other UC platforms?
The V555T runs Windows 11 IoT, allowing installation of Zoom Rooms or other Windows-compatible UC applications. The unit is factory-certified and optimized for Teams Rooms; verify platform compatibility with your UC vendor for specific software versions.

What BYOD options are available?
Wired BYOD is supported via HDMI 2.0 or USB-C (DisplayPort 1.2 + USB data). Wireless sharing via the MAXHUB Share app, Miracast, AirPlay, and Chromecast is also available, including P2P wireless connection without joining the room Wi-Fi network.

Can the V555T be integrated with a control system such as Crestron or Extron?
Yes. The RS232 port and RJ45 Ethernet interface support RS232/IP control protocols compatible with Crestron, Extron, and Q-SYS systems. MAXHUB Pivot provides centralized remote management across multiple deployed units.

Who do I contact for AV system design, pricing, or support?
Contact Creation Networks for commercial AV integration, volume pricing, and post-sale support. Creation Networks is an authorized MaxHub reseller.
