Poly Studio G62 – PoE+ Adapter and Cable Kit

Product Overview

The Poly Studio G62 PoE+ adapter and cable kit (A02F9AA) powers a Poly Studio G62 room codec from a single Ethernet run instead of a separate AC feed at the device. HP's product sheet describes the part as a 45 W, 2.5 Gbps PoE++ adapter with magnets, a 0.23 m CAT6A cable, and a power cord, so the kit supplies both the injector and the short patch lead the install needs. For an integrator, that means one cable to the codec position and no requirement for a powered outlet behind the display. Order it whenever a G62 is deployed in a room where running mains power to the device location is impractical or would fail a plenum or cable-management standard.

Product Description

This kit exists to solve a cabling problem specific to the Poly Studio G62 video conferencing system. The G62 is a modular room codec that pairs with a separate camera and controller, and it is frequently mounted behind or beside a display where there is a structured cabling drop but no convenient outlet. Powering it over Ethernet collapses the device's power and data requirements into the one run that already exists, which is why PoE is the default assumption in most modern room designs. The same applies to the government builds — the Studio G62 GSA/TAA configuration deploys identically.

Two details on the HP product sheet matter when specifying this part. First, the adapter is rated at 45 W and 2.5 Gbps — above the 30 W ceiling of standard 802.3at PoE+ and above gigabit — so it is doing more than a commodity injector, and substituting a generic PoE+ injector is not a like-for-like swap. Second, the CAT6A cable included is 0.23 m, a short jumper between the adapter and the device or wall plate rather than the full horizontal run; the structured cabling from the closet to the room position is still the installer's responsibility. The adapter body is magnetic, which lets it sit against a mount plate or steel display bracket instead of hanging on its own cable weight.

Where a room needs more headroom than 45 W or a different device is being powered, the Poly PoE++ 65 W 2.5G adapter is the higher-capacity alternative across the Studio video bar range. Rooms being built out from scratch usually pair this power kit with the Studio G62 mount kit so the codec, its mounting hardware, and its power source are a single line group on the bill of materials. Confirm the adapter's power class against the current HP documentation for your specific G62 configuration before ordering, since powering requirements differ between codec builds and attached peripherals.

Key Features

• Single-Cable Deployment — Powers the Studio G62 over its Ethernet run so no AC outlet is required at the codec position.
• 45 W Power Capacity — HP rates the adapter at 45 W, above the 30 W ceiling of standard 802.3at PoE+, giving the codec real headroom rather than a marginal supply.
• 2.5 Gbps Data Throughput — Passes multi-gigabit Ethernet, so the power injection does not become the bottleneck on a modern access layer.
• CAT6A Jumper Included — A 0.23 m CAT6A cable ships in the kit for the short hop between the adapter and the device or wall plate.
• Magnetic Adapter Body — Lets the injector sit against a mount plate or steel bracket instead of hanging from its own cabling.
• Power Cord Supplied — The kit is complete on arrival, so the installer does not source a separate mains lead.
• Cleaner Cable Management — Removing the second power run behind a display simplifies the pathway and reduces what has to be concealed or plenum-rated.
• OEM Powering Accessory — Keeps the codec inside HP's supported powering configuration rather than relying on a commodity injector.

Technical Specifications
