Poly Edge E500 – IP Desk Phone with Advanced Business Features

Product Overview

The Poly Edge E500 IP desk phone (HP 82M94AA, Poly 2200-87855-025) is an Open SIP business phone built around a single large 5-inch colour display with 12 physical line keys and support for up to 48 line key assignments. It runs on IEEE 802.3af Class 4 Power over Ethernet through a two-port gigabit switch with PC passthrough, and accepts up to two Poly Edge E Expansion Modules for reception and attendant console positions. Two USB Type-C ports handle headsets, storage, and expansion module connectivity. For a telephony buyer standardizing an estate where users need many monitored appearances on one readable screen, the E500 is the workhorse set in the Edge E line.

Product Description

The design decision that separates the E500 from the rest of the range is screen area. Rather than splitting appearances across a primary and secondary display, it puts 12 line keys against one 5-inch colour LCD, with four context-sensitive soft keys beneath and a pagination key that brings additional lines and contacts into view up to 48 total assignments. That layout suits users who scan a monitored group quickly — support desks, trading floors, front-of-house — where reading two screens costs time. When a position needs more than 48, two Poly Edge E Expansion Modules can be attached, each carrying up to 66 additional contacts, which turns the set into an attendant console without changing the underlying phone.

Provisioning and network integration follow standard Open SIP practice for mass deployment: IETF SIP (RFC 3261) with SDP, manual or DHCP setup, SNTP time synchronisation, and central provisioning over FTP, FTPS, TFTP, HTTP, or HTTPS, with provisioning and call server redundancy where the call platform supports it. The two-port gigabit switch conforms to IEEE 802.3-2005 Clause 40 and IEEE 802.3-2002 Clause 28, and the set supports 802.1p/Q VLAN tagging, Layer 3 ToS, CDP and DHCP VLAN discovery, LLDP-MED, static NAT configuration, and dual-stack IPv4/IPv6. Security covers 802.1X with EAPOL, SRTP media encryption, TLS, encrypted configuration files, digest authentication, HTTPS secure provisioning, and signed software executables. The E500 carries FCC Part 15 Class B, CE Mark, and TAA regulatory approvals, and UL 62368-1 safety listing, which matters for federal and government procurement.

Audio uses the same Poly stack found across the Edge E family: HD Voice on the handset, headset, and speakerphone paths, Acoustic Clarity for full-duplex operation and echo cancellation, Acoustic Fence for handset and wired headset use, and NoiseBlockAI on the speakerphone. Frequency response runs 150 Hz to 14 kHz with TIA-920 wideband type 1 compliance. Headsets connect over the dedicated RJ-9 port or USB Type-C, and the set is electronic hook switch capable. Unlike the Poly Edge E450, the E500 does not include integrated Wi-Fi or Bluetooth — specify the E450 where desks lack a data drop or users need a Bluetooth headset. For desks without PoE, order the Poly 25W power supply separately, and for high-volume positions add the Poly Edge E Expansion Module.

Key Features

• 5-Inch Colour Display — A single large LCD keeps monitored appearances readable at a glance instead of splitting them across two screens.
• 12 Line Keys, 48 Assignments — Twelve physical keys plus a pagination key support up to 48 line, contact, and feature assignments on the base set.
• Dual Expansion Module Support — Up to two Poly Edge E Expansion Modules add 66 contacts each, turning the phone into an attendant console position.
• Two USB Type-C Ports — Both ports handle headsets, storage, and expansion module connectivity, so a headset and a module can be attached at the same time.
• Class 4 PoE with PC Passthrough — IEEE 802.3af Class 4 PoE at 13 W maximum over a two-port gigabit switch keeps each desk to one cable run.
• Open SIP Provisioning — IETF SIP with FTP, FTPS, TFTP, HTTP, and HTTPS central provisioning and server redundancy supports large standards-based deployments.
• TAA and CE Approvals — FCC Part 15 Class B, CE Mark, and TAA regulatory approvals make the set eligible for federal and government procurement.
• Poly Audio Processing — HD Voice, Acoustic Clarity, Acoustic Fence, and NoiseBlockAI keep open-plan background noise off the call.
• RJ-9, USB and EHS Headsets — A dedicated RJ-9 port, USB Type-C, and electronic hook switch support let an existing headset estate carry over.
• Microban Antimicrobial Protection — Console, handset, and handset cord carry integrated Microban protection for hot-desking and shared workstations.
• Accessibility Compliance — ADA Section 508 Subpart B, hearing aid compatibility, TTY adapter support, text-to-speech, and adjustable colour and font settings are built in.
