Cisco Room Vision PTZ Wall Mount, Arctic White - CS-CAM-RVPTZ-WBKL

Product Overview

CS-CAM-RVPTZ-WBKL is the wall-only mounting bracket for the Cisco Room Vision PTZ camera in Arctic White, finished to match the camera. It is the slim bracket intended for Ethernet-only deployments, where a single PoE+ Cat5e run is the only cable reaching the camera. All Room Vision PTZ mounting options are ordered separately from the main unit, so this is a line item on the quote rather than something in the camera carton.

Product Description

Most Room Vision PTZ installations put the camera on a wall, at or slightly above display height, looking back down the room. This is the bracket for that job and nothing else. Because the Room Vision PTZ runs on one Ethernet cable that carries power, 4K video and camera control together, the bracket only has to manage a single cable, and it is built slim on that assumption. Where a room needs the camera on a ceiling, or where the installation also carries HDMI, this is the wrong part and CS-CAM-RVPTZ-CBKL is the one to specify instead. The two are not interchangeable.

For layout, the figure that matters is the assembly depth. Camera and bracket together occupy 165 mm wide by 200 mm high by 217 mm deep, so the camera stands roughly 217 mm off the finished wall surface. Check that against any millwork, display bezel or acoustic panel near the mounting position before the rough-in is set. The bracket weighs 0.7 kg on its own and carries a 2.3 kg camera, so the total hanging load is modest, but the anchor still has to suit the wall construction. Pick the bracket before the cable is pulled, because the bracket, not the camera, determines where the Cat5e needs to terminate. Bracket, camera and PoE+ injector are quoted as separate line items on the same room, so check all three against the rest of the Cisco room device catalog before the order goes out.

Key Features

• Wall-Only Mounting — Designed for a wall surface; it does not mount to a ceiling.
• Built for Single-Cable Deployment — Sized around the one PoE+ Ethernet run that carries power, video and control.
• Arctic White Finish — Matches the Arctic White Room Vision PTZ camera and light wall surfaces.
• Slim Assembly — Camera and bracket together project 217 mm from the wall.
• Light Bracket Weight — 0.7 kg (1.54 lb) before the camera is fitted.
• Matched to the Camera Interface — Engineered for the Room Vision PTZ mounting interface rather than a generic pattern.
