ViewSonic CDE30 Series 55" UHD 4K Commercial Monitor - CDE5530
Product Overview
The ViewSonic CDE5530 CDE30 Series is a 55-inch 4K commercial digital signage display designed for 24/7 continuous operation. This listing represents the CDE30 series 55-inch model — the same Android 11, Amlogic T982, Crestron/AMX/Extron-certified platform as the larger CDE6530 and CDE7530 in a compact 55-inch footprint suited for standard conference rooms, huddle spaces, and digital signage installations.
The CDE30 platform provides on-board media playback and digital signage app execution via Android 11 with 4GB DDR4 RAM and 32GB storage, eliminating the need for an external media player. Crestron Connected V2, AMX, and Extron certifications enable integration with enterprise AV control systems. Video wall tiling, Picture-in-Picture, and wireless content sharing via ViewBoard Cast, AirPlay, and Miracast are included.
Product Images
Key Features
- 55" 4K ADS Panel, 450 nits — DLED backlight, 1200:1 contrast, anti-glare 3H haze 25%; 24/7 rated
- Crestron Connected V2 + AMX + Extron Certified — AV control system integration with tested drivers
- Android 11, Amlogic T982, 4GB DDR4, 32GB — on-board media player; no external playback hardware required
- Video Wall Tiling up to 9 Screens — via HDMI in/out without external matrix switch
- 3x HDMI 2.1 In + HDMI ARC Out + HDMI 2.0 Out
- SPDIF Optical Audio Output — for external audio system connection
- USB-C Input — single-cable laptop connection
- ViewBoard Cast + AirPlay + Miracast — wireless content sharing
- VESA 400x200mm, compact footprint
- 3-Year Onsite Warranty
Typical Applications
- Conference rooms and huddle spaces
- Corporate reception and lobby digital signage
- Retail and hospitality digital signage
- Multi-screen video wall configurations
- Any 24/7 commercial display deployment requiring AV control integration
Technical Specifications
| Specification | Detail |
|---|---|
| Display Size | 55" |
| Resolution | 3840 x 2160 (4K UHD) |
| Brightness | 450 nits (typical) |
| Contrast Ratio | 1200:1 static / 5000:1 dynamic |
| Panel Type | ADS, DLED backlight |
| Panel Surface | Anti-glare, 3H, Haze 25% |
| Operation Rating | 24/7 |
| Touch | None (non-touch) |
| Operating System | Android 11.0 |
| Processor | Amlogic T982, Quad-Core 1.5GHz |
| RAM / Storage | 4GB DDR4 / 32GB |
| Speakers | 10W x2 (20W total) |
| Video Inputs | 3x HDMI 2.1 In, 1x USB-C |
| Video Outputs | 1x HDMI ARC Out, 1x HDMI 2.0 Out |
| Audio Output | SPDIF Optical Out |
| USB | 1x USB 3.0, 1x USB 2.0 |
| Network | 1x RJ45 Gigabit; Optional Wi-Fi (VB-WIFI-005) |
| Control | RS232 |
| AV Control | Crestron Connected V2, AMX, Extron |
| Video Wall | Up to 9 screens via HDMI in/out |
| VESA Mount | 400 x 200 mm |
| Backlight Life | 50,000 hours |
| Compliance | cTUVus, FCC, Energy Star 8.0, EPEAT, RoHS |
| Warranty | 3-year onsite |
Frequently Asked Questions
- Is this the same as the CDE5530 listed elsewhere on this site?
- Both listings are for the ViewSonic CDE5530 CDE30 Series 55-inch commercial display. They may reflect different pricing tiers, procurement channels, or availability windows. The hardware specifications are identical. Contact Creation Networks if you need clarification on which listing applies to your procurement requirement.
- What differentiates the CDE30 series from ViewSonic's CDE14 series?
- The CDE30 series (this product) runs Android 11 with 4GB DDR4, Crestron/AMX/Extron certification, and HDMI 2.1 inputs with 24/7 operation rating and 450 nits brightness. The CDE14 series runs Android 14 with Q-SYS integration, 16/7 operation rating, and 350 nits brightness, targeting newer deployments where Q-SYS control and lower power consumption are prioritized over 24/7 uptime rating.
- Does this display work with third-party digital signage software?
- Yes. As an Android 11 device, the CDE5530 is compatible with third-party digital signage software including BrightSign, Enplug, Scala, and others that publish Android APKs. Software can be sideloaded or deployed via a supported MDM platform.
