Vaddio EasyIP 20 Mixer Base Kit (Black) – AV-over-IP Conferencing System

Product Overview

The Vaddio EasyIP 20 Mixer Base Kit is an AV-over-IP video conferencing system in a single bundle, designed for large meeting rooms and multi-camera deployments. The kit pairs a professional IP PTZ camera with the EasyIP Mixer and an EasyIP Switch, giving integrators a network-based room system that scales without point-to-point cabling. It is built for organizations standardizing on AV-over-IP system design who need Dante audio, USB conferencing, and HDMI output from one managed platform.

Product Description

At the center of the kit is the EasyIP 20 camera, a network PTZ camera that streams up to 1080p/60 over the LAN or via HDMI, with 20x zoom and a 70-degree horizontal field of view for wide rooms. Vaddio's Tri-Synchronous Motion drives the pan, tilt, and zoom axes together for smooth, natural movement and repeatable presets. Because the camera connects over IP, additional EasyIP cameras can be added to the network and switched from the same EasyIP Mixer.

The EasyIP Mixer ties the system together, pairing with up to four EasyIP cameras and providing a Dante audio matrix alongside concurrent 1080p/60 USB 3.0 and HDMI output. The USB 3.0 stream connects directly to soft codecs such as Zoom, Microsoft Teams, and Google Meet, making this a practical USB 3.0 video conferencing system for large rooms, while HDMI feeds in-room displays or recorders. The included EasyIP Switch supplies the managed network backbone for the cameras and mixer. For smaller spaces, compare the EasyIP 10 Base Kit, or browse the full Vaddio collection. The EasyIP Mixer is also available on its own for system expansion.

Key Features

• Complete AV-over-IP Kit — Includes an EasyIP 20 camera, EasyIP Mixer, and EasyIP Switch to deploy a room system from one order.
• 20x Zoom IP PTZ Camera — Reaches across large rooms with a 70-degree wide field of view for full coverage.
• 1080p/60 Video — Streams high-definition video over the LAN or via HDMI for conferencing and display.
• Tri-Synchronous Motion — Moves pan, tilt, and zoom simultaneously for smooth shots and accurate preset recall.
• Dante Audio Matrix — Routes networked audio through a Dante matrix for flexible mic and speaker integration.
• Concurrent USB 3.0 and HDMI — Outputs to soft codecs and in-room displays at the same time.
• Multi-Camera Ready — The EasyIP Mixer pairs with up to four networked EasyIP cameras for multi-angle rooms.
• RS-232 and IP Control — Supports VISCA serial control and web-based IP control for integration with room control systems.

Typical Applications

• Conference room
• Boardroom
• Multi-purpose room
• Training room
• All-hands room
• Auditorium

Technical Specifications

• Kit model: EasyIP 20 Mixer Base Kit (999-30231-000), Black
• Included components: EasyIP 20 camera, EasyIP Mixer, EasyIP Switch
• Camera zoom: 20x
• Horizontal field of view: 70°
• Video resolution: Up to 1080p/60 over LAN or HDMI
• Camera motion: Tri-Synchronous pan / tilt / zoom
• Audio: Dante audio matrix via EasyIP Mixer
• Mixer outputs: Concurrent 1080p/60 USB 3.0 and HDMI
• Camera capacity: Mixer pairs with up to four EasyIP cameras
• Control: RS-232 (VISCA), IP/web control over RJ45 LAN

Specifications are drawn from the manufacturer (Legrand AV / Vaddio) and authorized distributor data. Confirm full electrical and mechanical specifications on the Vaddio datasheet before final system design.

Frequently Asked Questions

What is included in the EasyIP 20 Mixer Base Kit? The kit bundles one EasyIP 20 IP PTZ camera, one EasyIP Mixer, and one EasyIP Switch, providing the core of an AV-over-IP room system in a single part number.

How many cameras can the system support? The EasyIP Mixer pairs with up to four EasyIP cameras on the network, so you can expand to multi-camera coverage by adding cameras rather than replacing the base system.

Which conferencing platforms does it work with? The mixer's USB 3.0 output presents the system as a standard USB device to soft codecs such as Zoom, Microsoft Teams, and Google Meet.

Does it handle room audio? Yes. The EasyIP Mixer includes a Dante audio matrix for routing networked microphones and speakers, with concurrent USB and HDMI output.

How is the camera controlled? The camera supports RS-232 serial control using the VISCA protocol and IP control through a web configuration interface over its RJ45 LAN port, for integration with Crestron, Extron, AMX, and similar systems.

What warranty and support apply? Vaddio products carry the manufacturer's standard warranty; contact Creation Networks for current warranty terms, system design assistance, and post-sale support.
