Tannoy VX 5.2-WH Dual Concentric Full Range Loudspeaker (Pair,White) - TA-VX5.2-WH

TannoySKU: TA-VX5.2-WH
No reviews

Price:
Sale price$758.00

Description

Sold as a pair, Although the VX 5.2-WH is the smallest Dual Concentric full range loudspeaker in the VX range, it boasts an exceptional performance-to-size ratio. VX 5.2-WH provides a compact, yet punchy and sonically articulate solution for small-scale performance sound reinforcement, as well as more demanding background music and high-intelligibility speech applications where clarity and natural vocal reproduction are paramount. Thanks to its twin driver design and flexible mounting options, the VX 5.2-WH is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and portable applications.



  • Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications

  • 130 Watts continuous, 520 Watts peak power

  • 5" Dual Concentric full range driver for point source phase coherence

  • 5" low frequency driver for extended bass response

  • Precise 120° H x 90° V dispersion for optimum coverage and forward projection

  • Ideal for FOH, floor monitor, delay and stage front fill applications

  • Vented and internally braced plywood enclosure

  • Finished with hard wearing semi matt white paint finish

  • Rugged powder coated perforated steel mesh grille

  • M6 pole mount socket for small-scale portable PA

  • Optional horizontal mounting yoke (available separately)

  • Neutrik speakON* NL4 and barrier strip connectors for input and link output

  • 10-Year Warranty Program*

  • Designed and engineered in the U.K.

Data Sheet

System
Frequency response

87 Hz - 35 kHz ±3 dB
65 Hz - 45 kHz -10 dB

Nominal dispersion

120° H x 90° V @ -6dB points

Directivity factor (Q)

7.3

Directivity index (DI)

8.6

Power handling (IEC)
Passive

130 Watts continuous, 520 W peak

Bi-amp

Sensitivity

90 dB (1 W @ 1 m)

Maximum SPL
Passive

111 dB continuous, 117 dB peak

Bi-amp

Impedance
Passive

8 Ω

Bi-amp

Crossover Type

Passive with dynamic HF protection

Components

1 x 5" (125 mm) LF driver
1 x 5" (125 mm) constant directivity
Dual Concentric

Enclosure
Connectors

2x Neutrik speakON* NL4
1 x barrier strip terminals

Wiring
Passive

Pins 1+ / 1- Input, Pins 2+ / 2- Link

Bi-Amp

Dimensions H x W x D

334 x 181  x 201 mm(13.1  x 7.1 x 7.9'')

Net weight

4.4 kg (9.7lbs)

Construction

12 mm (1/2'') plywood, vented and internally braced

Finish

Semi matt black paint (white optional)

Grille

Powder coated perforated steel

Flying hardware

M6 x 2 yoke bracket insert
(4 mm allen key)

M6 x 4 inserts

Compatible with industry
standard brackets

Accessories
Multi Angle Wall Mount<br />Multi Angle Wall Mount-WH<br />Yoke Horizontal VX 5.2/VX 6<br />Yoke Horizontal VX 5.2/VX 6 - WH
