Tannoy QCI 6DC IW High-Performance 6" Dual Concentric In-Wall Loudspeaker (White) - TA-QCI 6DC IW-WH

Tannoy SKU: TA-QCI 6DC IW-WH
No reviews

Price:
Sale price$299.00

Description

For over 90 years Tannoy has been a leader in the pursuit of high-fidelity sound. The most demanding audio professionals around the world rely on Tannoy loudspeakers to create music and sound we love to hear and feel. From recording and mastering engineers to broadcasters and film score composers Tannoy loudspeakers are trusted for their proven reliability, true to source accuracy and ability to reproduce sound the way the artist intended. There really is no substitute for Tannoy. Trusted by music creatives around the world, installed in the world's best venues and locations, perfect for listening at home.

The QCI range is designed with the same high standards and attention to detail as our flagship professional and hi-fi loudspeakers. They deliver high fidelity sound that is extremely natural and detailed. They have the same sonic signature and can be easily mixed and matched to make a stereo, surround or multi-room audiophile system.

  • High-performance loudspeaker for in-wall installation applications

  • 6" Dual Concentric driver featuring Tannoy point-source constant directivity

  • Tulip Waveguide for a smooth, uniform frequency response over a wide area of coverage unachievable with discrete, two-way designs

  • Glass fibre cone with high-excursion, rubber surround for high power handling

  • 70 Watts continuous, 280 Watts peak power

  • Extremely thin bezel for discreet installation

  • Integrated single unit construction for easy installation

  • Semi matt white finish fits unobtrusively in any environment

  • Powder coated UV resistant perforated steel mesh grille with dust protection

  • Removable grille for custom painting

  • Self-aligning clamp mounting system

  • Removable Tannoy grille badge

  • Tannoy - Over 90 years of British sound heritage and innovation

Frequency response (±3 dB)

50 Hz – 20 kHz

Frequency response (-10 dB)

30 Hz – 20 kHz

Sensitivity (1 W @ 1m)

85 dB

Directivity factor (Q)

4.8 averaged 1 kHz to 10 kHz

Directivity index (DI)

6.8 averaged 1 kHz to 10 kHz

Power handling (IEC)
Average

70 W

Programme

140 W

Peak

280 W

Recommended amplifi er power

210 W @ 8 Ω

Nominal Impedance (Lo Z)

8 Ω

Rated maximum SPL (1 m, Lo Z)

107 dB

Average

104 dB

Peak

110 dB

Crossover point

1.6 kHz

Coverage angles
500 Hz

180° horizontal, 160° vertical

1 kHz

141° horizontal, 144° vertical

2 kHz

119° horizontal, 134° vertical

4 kHz

92° horizontal, 87° vertical

Transducers
Low frequency diameter/material/type

165.5 mm (6")

High frequency diameter/material/type

25.4 mm (1)

Physical
Back can

Option 1: BACK CAN IW: Steel, powder coating

Baffle

Reflex loaded UL94 V-0 rated ABS

Grille

Stee l, with weather resistant coating

Safety features

—

Clamping design

Security toggle clamp

Connectors

Phoenix Contact terminal block

Dimensions (HxWxD)

315 x 221 x 105 mm (12.4 x 8.7 x 4.1")

Bezel dimensions

Square: 315 x 221 mm (12.4 x 8.7")

Mounting depth

91.7 mm (3.6")

Hole cutout dimensions

299 x 203 mm (11.8x8")

Net weight

2.9 kg (6.4 lbs)

Packed quantity
Included accessories

Grille, paint mask, cutout template

Optional accessories

Option 1: BACK CAN IW

Option 2: PMK 6 IW
