(Sold as a pair)

CMS 3.0 CMS 503ICT LP

The CMS 503ICT LP is a full bandwidth 200-Watt high sensitivity loudspeaker that utilises our third generation Ceiling Monitor System technology (CMS 3.0). Thanks to an all-new proprietary 5" ICT (Inductive Coupling Technology) point source driver with extended frequency range, the UL certified CMS 503ICT LP delivers consistent broadband directivity with enhanced intelligibility. ICT drivers provide exceptional long-term reliability – and are ideal for constant-usage applications.

Features

Full range ceiling loudspeaker for installation applications
50 Watts continuous, 200 Watts peak power
5" ICT (Inductive Coupling Technology) point source driver for extended frequency range
Ultra-shallow depth profile for applications where cavity space is restricted
High durability design for constant heavy usage in demanding applications
UL 1480 certified for general signalling systems
UL 2043 certified for air-handling spaces
Multiple transformer taps for 70 V and 100 V line systems or 16 Ohm direct input
Low insertion loss 30 W line transformer with easily accessible tapping switch
Optimised for Lab Gruppen low impedance LUCIA amplifiers with up to 8 CMS series loudspeakers per channel
Semi matt white finish fits unobtrusively in any environment
Powder coated UV resistant perforated steel mesh grille with dust protection
Removable magnetic grille for custom painting
Optional ARCO designer grilles available for minimal architectural impact
Self-aligning 4 way clamp mounting system
Mounting C-ring and ceiling tile rails included
10-Year Warranty Program*
Designed and engineered in the U.K.

Data Sheet

Specifications

Performance

Frequency response (-3 dB) <sup>(1)</sup>	88 Hz - 50 kHz
Frequency range (-10 dB) <sup>(1)</sup>	77 Hz - 54 kHz
System sensitivity (1 W @ 1 m) <sup>(2)</sup>	89 dB (1 W = 4 V for 16 Ohms)
Nominal Coverage Angle	90 degrees conical
Power Handling <sup>(3)</sup>
Average	50 W
Programme	100 W
Peak	200 W
Recommended Amplifier Power	100 W @ 16 Ohms
Nominal Impedance (Lo, Z)	16 Ohms
Rated maximum SPL
Average	106 dB
Peak	112 dB
Transformer Taps (via front rotary switch)
70 V	30 W (165 O) / 15 W (330 O) / 7.5 W (660 O) / 3.75 W (1320 O) / OFF & low impedance operation
100 V	30 W (330 O) / 15 W (660 O) / 7.5 W (1320 O) / OFF & low impedance operation

Transducers

Low Frequency	1 x 130 mm (5.0") mineral loaded polypropylene
High Frequency	ICT

Physical

Enclosure
Backcan	Zinc plated steel
Baffle	Reflex loaded UL 94V-0 rated ABS
Grille	Steel, with weather resistant coating
Safety Features	Safety ring located at rear of enclosure for load bearing safety bond
Clamping Design	Security toggle clamp Min / Max clamping range 9.5 mm (0.37") / 60 mm (2.36") Recommended clamp torque: 1.5 Nm
Cable Entry Options	Cable clamp & squeeze connector for conduit up to 22 mm
Connectors	Removable locking connector with screw terminals with “loop through” facility
Compliance	UL-1480, UL-2043, CE
Dimensions
Bezel diameter	274.0 mm (10.79")
Front of ceiling to rear of backcan	98.6 mm (3.88")
Hole cutout diameter	253.0 mm (9.96")
Net Weight (ea)	4.4 kg (9.70 lbs)
Included Accessories	C-Ring, tile-bridge kit, paint mask, cut-out template, grille
Optional Accessories	Plaster (mud) ring, Arco grille
Packed Quantity	2
