Symetrix 80-0226 xIO XLR 1x1, Black, Euro
Symetrix 80-0226 xIO XLR 1x1, Black, Euro is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Symetrix 80-0226 xIO XLR 1x1, Black, Euro
Product Overview
The Symetrix 80-0226 xIO XLR 1x1 is a Dante wall plate endpoint in black, designed for European single-gang wall and junction boxes. It provides one balanced XLR microphone/line input and one balanced XLR output on a Euro-format wall plate, powered over Ethernet via IEEE 802.3af PoE. Audio conversion is 24-bit with 48 kHz and 96 kHz support and 1 ms minimum Dante latency. The black finish matches dark fixture specifications in European commercial AV installations.
Product Description
The xIO XLR 1x1 Euro black is the black-finish European variant, providing identical electrical performance as the Euro white version (80-0214) in a black finish for Euro gang boxes. Configured in Symetrix Composer within the overall DSP site file. Compliant with CE, UKCA, EAC, FCC Part 15, and RoHS.
Key Features
- 1 XLR Input + 1 XLR Output — Balanced mic/line input and line output on a Euro wall plate.
- Dante + AES67 — PoE-powered IEEE 802.3af; 48 and 96 kHz.
- Euro Single-Gang, Black — Fits standard European wall boxes; black finish.
- Die-Cast Zinc Chassis — Commercial-grade for permanent installation.
- Composer Programmable — Fully configured in Symetrix Composer.
Typical Applications
- European conference rooms and boardrooms with black fixture specifications
- International AV installations requiring Euro gang box wall plates in black
Technical Specifications
| Specification | Value |
|---|---|
| SKU | 80-0226 |
| Analog Inputs | 1 balanced XLR mic/line |
| Analog Outputs | 1 balanced XLR line |
| Dante Channels | 1 transmit + 1 receive |
| AES67 | Supported |
| Sample Rates | 48 kHz, 96 kHz |
| Min Dante Latency | 1 ms |
| Power | PoE IEEE 802.3af |
| Form Factor | Euro single-gang, black |
| Chassis | Die-cast zinc |
| Compliance | CE, UKCA, EAC, FCC Part 15, RoHS |
