Shure ULXD2-SM58 VHF Digital Handheld Wireless Microphone Transmitter with SM58 Capsule - ULXD2/SM58=-V50
Shure ULXD2-SM58 VHF Digital Handheld Wireless Microphone Transmitter with SM58 Capsule - ULXD2/SM58=-V50 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Shure ULXD2-SM58 VHF Digital Handheld Wireless Microphone Transmitt...
Product Overview
The Shure ULXD2/SM58 wireless handheld transmitter is a digital handheld microphone transmitter for professional sound reinforcement in houses of worship, auditoriums, and commercial event spaces. This V50-band model operates in the VHF 174 to 216 MHz range and pairs a rugged aluminum body with the included SM58 cardioid dynamic cartridge, the industry-standard vocal capsule. As part of the ULX-D digital wireless system, it delivers 24-bit/48 kHz audio, AES-256 encryption, and a rechargeable lithium-ion battery for reliable all-day operation. It is a dependable handheld for AV integrators standardizing on secure, networked wireless.
Product Description
The Shure ULXD2/SM58 is a digital handheld wireless microphone transmitter for the ULX-D system, combining a lightweight, rugged aluminum body with an integrated antenna and the legendary SM58 capsule. The cardioid dynamic cartridge delivers the familiar, reliable vocal sound trusted across live production, with strong off-axis rejection that helps control feedback in reverberant rooms. Audio is converted at 24-bit/48 kHz, and AES-256 bit encryption secures transmission for applications where privacy matters. Proprietary Shure Gain Ranging optimizes dynamic range for any input source, eliminating the need for transmitter gain adjustments and simplifying setup. A Shure lithium-ion rechargeable battery pack provides over nine hours of run time with precise metering in hours and minutes and zero memory effect, while a backlit LCD with an easy-to-navigate menu keeps control simple. This V50-band configuration covers the VHF 174 to 216 MHz range, an option some installations prefer for spectrum availability. For AV system designers standardizing on ULX-D, the ULXD2/SM58 is a cost-effective, robust handheld vocal transmitter for installs and portable rigs.
Key Features
- SM58 Cardioid Capsule — The included SM58 cardioid dynamic cartridge delivers the industry-standard vocal sound with reliable feedback rejection.
- 24-bit/48 kHz Digital Audio — High-resolution conversion provides clear, accurate vocal reproduction.
- AES-256 Encryption — Built-in AES-256 bit encryption secures transmission for applications requiring privacy.
- Shure Gain Ranging — Proprietary gain ranging optimizes dynamic range for any source and eliminates manual transmitter gain adjustments.
- Rechargeable Lithium-Ion Power — The Shure Li-Ion battery pack provides over nine hours of run time with precise metering and zero memory effect.
- Rugged Aluminum Body — A lightweight, durable aluminum housing with integrated antenna stands up to demanding professional use.
- VHF V50 Band — Operation in the 174 to 216 MHz VHF range provides an alternative to UHF where spectrum availability favors lower bands.
Typical Applications
- House of worship
- Auditorium
- Conference room
- Multi-purpose room
- All-hands room
- Training room
- Broadcast studio
Technical Specifications
| Type | Digital handheld wireless transmitter (ULX-D) |
| Capsule | SM58 cardioid dynamic |
| Frequency Band | V50: 174 to 216 MHz (VHF) |
| Conversion | 24-bit / 48 kHz |
| Encryption | AES-256 bit |
| Battery | Shure Li-Ion rechargeable, over 9 hours |
| Body | Aluminum with integrated antenna |
| Dimensions | 10.1 x 2.0 in (256 x 51 mm) L x Dia. |
| Weight | 12.0 oz (340 g) without batteries |
| Model | ULXD2/SM58=-V50 |
Frequently Asked Questions
Which receiver does the ULXD2/SM58 work with?
It operates with ULX-D digital wireless receivers, such as the ULXD4 series, tuned to the matching V50 frequency band.
What frequency range does the V50 band cover?
This configuration operates in the V50 VHF band, 174 to 216 MHz. Confirm local frequency coordination for your region.
Does the transmitter require manual gain setting?
No. Shure Gain Ranging optimizes dynamic range for any input source, removing the need for transmitter gain adjustments.
How long does the battery last?
The Shure lithium-ion rechargeable battery pack provides over nine hours of run time with precise metering and zero memory effect.
Is transmission secure?
Yes. The ULXD2 includes AES-256 bit encryption for applications requiring secure wireless transmission.
How does the SM58 capsule differ from the Beta 58A?
The SM58 is a cardioid dynamic capsule and the industry-standard live vocal mic; the Beta 58A is supercardioid with tighter pickup. Both are available on the ULXD2 platform.
Related Shure wireless products at Creation Networks: the Shure ULXD4Q quad-channel receiver (V50) and the Shure ULXD2/Beta 58A handheld transmitter.
