Product Overview
The Shure MX395B/BI-LED is a low-profile figure-8 boundary microphone with a remote logic-control LED for clear mute and status indication. Its bidirectional pattern captures two talkers facing each other across a table while the LED gives participants visible feedback on microphone state. The black housing stays discreet in commercial AV installations.
Product Description
Part of the Shure Microflex low-profile boundary family, the MX395B/BI-LED figure-8 boundary microphone adds a logic-controlled LED that an installed control system can drive to show mute or active status. The bidirectional pattern captures sound from the front and rear while rejecting the sides, making one unit efficient for two participants seated opposite each other on an interview desk or narrow conference table. A 5-pin XLR connector carries both audio and logic, and a female connector is included to simplify wiring into installed mixers, DSP processors, and control systems. With a wide 50 Hz to 17 kHz response and low susceptibility to RF and electromagnetic interference, it delivers accurate speech reproduction for conferencing and commercial meeting spaces. The black finish blends with dark tables and modern interiors.
Key Features
- Logic-control LED — A remote-controllable LED gives participants clear visual feedback on mute or active status.
- Figure-8 bidirectional pickup — Captures talkers in front of and behind the microphone while rejecting side noise, ideal for two facing participants.
- 5-pin XLR with included female connector — Carries audio and logic together and simplifies wiring into control systems and DSP processors.
- Low-profile boundary design — The near-flush housing keeps conference and interview tables visually uncluttered.
- Black finish — Blends discreetly with dark tables and modern conference room interiors.
Technical Specifications
| Type | Electret condenser (boundary) |
| Polar pattern | Bidirectional (figure-8) |
| Frequency response | 50 Hz – 17 kHz |
| Sensitivity | –37 dBV/Pa (14 mV) |
| Output impedance | 150 Ω EIA rated (170 Ω actual) |
| Output configuration | Active balanced |
| Connector | 5-pin XLR (female connector included) |
| Status indicator | Remote logic-control LED |
| Finish | Black |
| SKU | MX395B/BI-LED |
Comparable Microflex boundary options include the non-LED MX395B/BI figure-8 and the cardioid MX395B/C-LED.
