QSC RMP-100 – Q-SYS RoomSuite Room Processor

Product Overview

The QSC Q-SYS RMP-100 room processor is the central processing engine of the Q-SYS RoomSuite Modular System, purpose-built to standardize and scale conferencing across commercial meeting spaces. Acting as a dedicated conference room AV processor with PoE+, it handles audio processing, network video, USB AV bridging, and display control from a single half-rack unit. Integrators deploy the RMP-100 as a no-code Q-SYS meeting room processor, configuring rooms through a web-based workflow rather than traditional programming. It supports leading UC platforms and BYOD video conferencing, making it a repeatable foundation for medium to large room standardization.

Product Description

The QSC Q-SYS RMP-100 room processor consolidates the core hardware a collaboration space needs into one commercial-grade device. Its integrated Ethernet switch delivers seven 1 Gbps AV LAN ports with PoE+ output plus a dedicated PoE++ expander port, powering Q-SYS NL loudspeakers, NC cameras, NM microphones, and third-party endpoints directly over the network. As an HDMI 2.0 4K60 room processor, it accepts two HDMI inputs and drives two HDMI outputs with HDCP 2.2 support for reliable content sharing and display control. A USB-C port provides USB AV bridging for local UC compute, connecting camera and audio to a room PC or codec for BYOD video conferencing.

Because the RMP-100 does not require Q-SYS Designer Software, integrators commission rooms through a streamlined web interface that covers device discovery, video I/O setup, and room audio optimization. Once deployed, the processor supports Q-SYS Reflect remote management for centralized monitoring, preset deployment, and bulk firmware updates across a fleet of spaces. RS-232 and CEC control manage displays, while a GPIO input connects an occupancy sensor for simple room automation. The RMP-100 pairs with the QIO-VEN4 expander to add a further HDMI input and four more PoE+ ports, extending the platform to larger rooms. For AV system designers standardizing conference room, boardroom, and training room deployments, it delivers a scalable, network-based signal path that fits cleanly into new and existing Q-SYS ecosystems.

Key Features

• Dedicated Room Processor — An application-specific processor for the meeting room centralizes audio, video, control, and networking in one commercial-grade unit.
• Integrated PoE+ Network Switch — Seven 1 Gbps AV LAN ports supply PoE+ power to Q-SYS endpoints and third-party microphones, reducing external switching hardware.
• HDMI 2.0 Video I/O — Two HDMI inputs and two HDMI outputs support up to 4K60 in BYOM mode with HDCP 2.2 for secure content sharing.
• USB-C AV Bridging — A USB 3.1 Type-C port bridges room audio and camera to local UC compute for platform-agnostic BYOD video conferencing.
• No-Code Web Configuration — A web-based workflow commissions rooms without Q-SYS Designer Software, accelerating standardized deployment at scale.
• Q-SYS Reflect Management — Remote monitoring, preset deployment, and bulk firmware updates let teams maintain many rooms from a single interface.
• Display and Room Control — Dual RS-232 ports, HDMI CEC, and a GPIO occupancy-sensor input enable display control and simple room automation.
• Modular Scalability — Pairing with the QIO-VEN4 expander adds video input and PoE+ ports to extend the system into larger rooms.

Typical Applications

• Conference Room — Standardized UC and BYOD conferencing for standard meeting spaces.
• Boardroom — Multi-display, multi-source presentation with centralized control.
• Training Room — Networked audio and video distribution for instructional environments.
• Multi-Purpose Room — Flexible source switching and room automation for reconfigurable spaces.
• Commercial Meeting Space — Fleet deployments where remote management and repeatable setup matter.
• All-Hands Room — Larger collaboration spaces using expanded video and networked endpoints.

Technical Specifications

Specifications sourced from the QSC Q-SYS RoomSuite Modular System specifications sheet.

Frequently Asked Questions

What endpoints and peripherals is the RMP-100 compatible with?
The RMP-100 supports Q-SYS networked collaboration endpoints, including NL Series loudspeakers, NC Series cameras, and NM Series microphones, plus select third-party ceiling microphones. Its built-in PoE+ switch powers these devices over the network. Companion products such as the QSC NL-C4 network ceiling loudspeaker and QSC NC-20x60 network PTZ camera integrate directly with the processor.

Does the RMP-100 require Q-SYS Designer Software to configure?
No. The RMP-100 is commissioned through a no-code, web-based workflow that handles device discovery, video I/O setup, and room audio optimization. This lets integrators standardize deployments without traditional Q-SYS programming.

How does the RMP-100 fit into an existing AV network?
The processor provides seven PoE+ AV LAN ports and two auxiliary control ports on a Q-LAN network. For larger installations, pair it with a managed switch such as the QSC NS10-125+ pre-configured PoE+ switch to expand port count and PoE budget.

Can it bridge audio and video to a room PC or UC codec?
Yes. The USB-C port provides USB AV bridging for local UC compute, connecting room audio and camera to a codec or PC for BYOD conferencing. Deployments requiring bridging on additional Q-SYS hardware can add the QSC SLQBR-P AV bridging license.

How is the system controlled by end users?
User control interfaces are generated automatically during setup and can be presented on a Q-SYS touch screen controller such as the QSC TSC-101-G3 10-inch PoE touch controller. RS-232 and CEC handle display power and source control.

How are multiple rooms managed and maintained?
The RMP-100 integrates with Q-SYS Reflect for remote monitoring, preset deployment, and bulk firmware updates, so AV and IT teams can manage a fleet of RoomSuite and Core-based spaces from one interface.

What warranty and support are available?
The RMP-100 carries the QSC Q-SYS manufacturer limited warranty. Contact the Creation Networks team for current warranty terms, extended coverage options, and pre-sales system design or post-installation support.
