QSC PL-DC8-YM – Yoke Mount for PL-DC8
Product Overview
The QSC PL-DC8-YM is a yoke mount bracket engineered for secure, flexible deployment of the QSC PL-DC8 installation loudspeaker. Crafted from high-grade galvanized steel with industrial weather-resistant coatings, it delivers reliable support, multiple rigging options, and optimized acoustic isolation. The PL-DC8-YM yoke mount is an ideal accessory for both permanent and temporary AV installations.
Product Description
Made from 2.7 mm galvanized cold-rolled steel with a UV- and salt-spray-rated powder coating, the bracket offers a quick-setup slot plus a closer-positioned fixed hole, and includes two rubber spacers to minimize vibration between the loudspeaker and mount. A 13 mm center hole supports clamp mounting, while 240 mm and 386.4 mm truss patterns provide universal rigging support. Purpose-built for the QSC PL-DC8, it suits conference rooms, houses of worship, lecture halls, and multi-use commercial AV environments.
Key Features
- Durable galvanized steel — Made from 2.7 mm galvanized cold-rolled steel for strength and rigidity.
- Weather-resistant finish — Powder coating rated for 1000 hours of UV exposure and 200 hours of salt spray.
- Dual mounting configurations — Quick-setup slot plus a closer-positioned fixed hole for varied rigging needs.
- Vibration isolation — Two round rubber spacers minimize vibration for improved acoustic performance.
- Truss-compatible rigging — 13 mm clamp hole plus 240 mm and 386.4 mm truss-mounting patterns.
- Traceability ID — Unique part identifier for inventory tracking and quality control.
Technical Specifications
| Specification | Value |
|---|---|
| Model / SKU | PL-DC8-YM |
| Type | Yoke mount bracket |
| Material | 2.7 mm galvanized cold-rolled steel |
| Coating | Powder coat rated 1000 h UV + 200 h salt spray |
| Speaker mounting | Quick-setup slot + fixed hole |
| Vibration isolation | 2 rubber spacers included |
| Clamp hole | 13 mm |
| Truss spacing | 240 mm (11 x 7 mm oblong) & 386.4 mm (7 x 20 mm slot) |
| Compatibility | QSC PL-DC8 |
| Traceability | Unique identifier included |
