QSC PL-DC24-YM Yoke Mount for PL-DC24

Yoke Mount Bracket for PL-DC24 Loudspeakers

Lightweight, Durable Mounting Solution for AV Installations

The Yoke Mount Bracket for the PL-DC24 loudspeaker offers a reliable and versatile solution for mounting in professional AV environments. Designed for secure installation and precise alignment, this bracket balances rugged durability with a slimmer profile. It includes truss-compatible mounting options, dual loudspeaker attachment points, and acoustic isolation spacers—ideal for integrators seeking flexibility, speed, and stability.

Key Features and Benefits

• Slim but Strong Construction
  Made from 2 mm thick galvanized cold-rolled steel (CRS) to deliver strength while minimizing weight—ideal for ceiling or truss-mounted loudspeakers.
• Industrial-Grade Coating
  Finished with a powder coating rated for 1000 hours of UV exposure and 200 hours of salt spray resistance, ensuring corrosion protection for long-term use in commercial spaces.
• Dual Loudspeaker Mounting Options
  Equipped with both a quick-install slot for rapid setup and an additional fixed hole to mount the speaker closer to the bracket when space is limited or tighter rigging is required.
• Integrated Vibration Control
  Includes two round rubber spacers to isolate the loudspeaker from the bracket—reducing mechanical resonance and enhancing audio fidelity.
• Clamp and Truss Compatibility
  Engineered for a wide range of rigging options:
• 13 mm center hole for clamp mounting
• 240 mm spacing (10.5 × 7 mm oblong holes)
• 308 mm spacing (four 8.5 mm round holes)
• Traceability Identifier
  Each bracket is uniquely marked with a traceability code to support project documentation, inventory tracking, and quality control processes.

Ideal Applications

• Houses of Worship
• Boardrooms
• Government Facilities
• Corporate AV Installations
• Training Rooms
• Lecture Halls
• Multi-Purpose Rooms
• Live Performance Venues
• Auditoriums

Competitive Advantages

• Slim Profile, High Strength: Thinner steel provides reduced weight without compromising load capacity.
• Mounting Flexibility: Two speaker mounting options accommodate various spatial constraints and install needs.
• Enhanced Audio Performance: Vibration-isolating spacers help preserve audio clarity and hardware integrity.
• Multi-Truss Compatibility: Fits both U.S. and international truss spacing standards for ease of rigging.
• Professional-Grade Reliability: Traceability support ensures accountability for commercial AV deployments.
