QSC E118SW – 18-Inch Passive Subwoofer (Black)
Product Overview
The QSC E118SW is an 18-inch passive direct-radiating subwoofer from QSC's E Series, built for live performance, DJ and dance music, karaoke, and event production. It requires external amplification and integrates with E Series full-range loudspeakers for sub/satellite systems.
It delivers deep, high-output low frequency with a peak SPL of 133 dB and includes a speaker pole for satellite mounting.
Product Description
The E118SW is a direct-radiating 18-inch subwoofer requiring an amplifier with a minimum of 800 W continuous (3200 W peak). It offers a frequency response of 37 Hz to 230 Hz (-6 dB) and a peak SPL of 133 dB. QSC recommends a speaker processor or DSP-equipped amplifier — such as QSC GXD or PLD amplifiers, or TouchMix mixers — to set crossovers, limiting, and EQ, with factory presets for live reinforcement, stage monitoring, dance music, and karaoke.
The rugged plywood enclosure is finished in black textured paint with a foam-lined perforated-steel grille. A threaded M20 pole socket and a speaker pole are provided for sub/satellite use with any E Series two-way full-range loudspeaker, and attachment points accept four optional casters for portable use.
Pair it with E Series full-range models such as the QSC E112 and QSC E115.
Key Features
- 18-inch direct-radiating sub — High-output low frequency with a 133 dB peak SPL and 37 Hz–230 Hz (-6 dB) response.
- 800 W continuous / 3200 W peak — High power handling for demanding live and DJ use (external amplifier required).
- E Series Entertainment System DSP — Factory tunings via QSC GXD, PLD amplifiers, or TouchMix mixers.
- Included speaker pole — A threaded M20 socket and speaker pole support sub/satellite setups with E Series full-range loudspeakers.
- Caster-ready — Attachment points accept four optional casters for portability.
- Rugged build — Plywood enclosure with black textured paint and a foam-lined perforated-steel grille.
Typical Applications
- House of worship
- Auditorium
- Multi-purpose room
- Commercial meeting space
Technical Specifications
| Configuration | Passive direct-radiating subwoofer |
| Driver | 18 in woofer |
| Frequency response | 37 Hz – 230 Hz (-6 dB) |
| Maximum SPL | 133 dB (peak) |
| Amplifier required | Min. 800 W continuous (3200 W peak) |
| Enclosure | Plywood, black textured paint, foam-lined steel grille |
| Mounting | M20 pole socket; speaker pole included; attachment points for 4 optional casters |
Competitor Comparison
| Criteria | QSC E118SW | JBL JRX218S | Electro-Voice TX1181 |
|---|---|---|---|
| Driver | 18 in passive direct-radiating | 18 in passive | 18 in passive |
| Power handling | 800 W cont / 3200 W peak | High continuous handling | High continuous handling |
| Peak SPL | 133 dB | High output | High output |
| DSP tunings | E Series presets via GXD/PLD/TouchMix | Amplifier-dependent | Amplifier-dependent |
| Sub/satellite | M20 pole socket + included pole | Pole socket | Pole socket |
Frequently Asked Questions
Does the E118SW need an amplifier?
Yes. It is a passive subwoofer requiring at least 800 W continuous (3200 W peak); QSC GXD or PLD amplifiers add factory DSP tunings.
Can I mount full-range speakers on it?
Yes. A threaded M20 pole socket and an included speaker pole support sub/satellite setups with E Series two-way loudspeakers.
Is it portable?
It has attachment points for four optional casters in addition to pole-mount and ground use.
What warranty and support come with this subwoofer?
QSC loudspeakers are covered under QSC's standard limited warranty; refer to QSC's published warranty terms for the current coverage period applicable to this model. Creation Networks provides pre- and post-sale support for system design and integration questions.
