QSC DCIO-H – Q-SYS Digital Cinema HDMI I/O Interface
Product Overview
The QSC DCIO-H is the HDMI-equipped version of QSC's cinema-specific Q-SYS audio interface, serving as the input/output hub for each screen in a Q-SYS-enabled cinema complex. In addition to the full digital cinema audio I/O of the standard DCIO, the DCIO-H adds HDMI 2.0 / HDCP 2.2 input and output for non-sync sources and onboard Dolby and DTS-HD decoding — making it the right choice for auditoriums that present alternate content alongside theatrical features. It routes audio from the projector IMB and other sources to a Q-SYS Core over Q-LAN for full-system cinema audio design.
Product Description
Alongside the DCIO's 16-channel AES/EBU input from the IMB, mic/line input, line-level and powered monitor outputs, four relay control outputs, HI/VI outputs, and RS-232/GPI automation, the DCIO-H adds HDMI 2.0 / HDCP 2.2 input/output for non-sync content and decoding of Dolby Audio (including Dolby Digital Plus and Dolby Surround 7.1) and DTS-HD. This lets a Q-SYS auditorium handle live events, presentations, and streamed or disc-based content with full surround decoding, all managed within Q-SYS Designer alongside Q-SYS Cores, DPA-Q amplifiers, and DCS loudspeakers. For installations that do not require HDMI or onboard decoding, the standard QSC DCIO provides the same core audio I/O.
Key Features
- HDMI 2.0 / HDCP 2.2 input and output — Handles non-sync content sources in a Q-SYS cinema.
- Dolby and DTS-HD decoding — Decodes Dolby Audio (Dolby Digital Plus, Dolby Surround 7.1) and DTS-HD on board.
- 16-channel AES/EBU input from IMB — Full digital cinema audio into the Q-SYS network.
- Mic/line input and monitor outputs — Line-level monitor output plus powered monitor output for a passive speaker.
- Four relay control outputs and HI/VI outputs — Show automation and accessibility feeds.
- RS-232 and GPI automation inputs — Integrates with cinema automation systems.
- Q-LAN networked — Works with Q-SYS Cores, DPA-Q amplifiers, and DCS loudspeakers.
Typical Applications
- Auditorium and cinema screening rooms (theatrical plus alternate content)
- Multi-purpose room
Technical Specifications
| Function | Q-SYS digital cinema audio I/O with HDMI |
| HDMI | HDMI 2.0 / HDCP 2.2 input and output (non-sync sources) |
| Decoding | Dolby Digital Plus, Dolby Surround 7.1, DTS-HD |
| Digital input | 16-channel AES/EBU from IMB |
| Analog input | Mic/line input |
| Monitor outputs | Line-level monitor; powered monitor output for passive speaker |
| Control outputs | Four relay control outputs; HI/VI outputs |
| Automation | RS-232 and GPI inputs |
| Network | Q-LAN (Q-SYS) |
Frequently Asked Questions
What does the DCIO-H add over the standard DCIO? HDMI 2.0/HDCP 2.2 input/output for non-sync sources and onboard Dolby (Digital Plus, Surround 7.1) and DTS-HD decoding, in addition to all of the standard DCIO's audio, control, and automation I/O.
Can it handle alternate content like live events or streaming? Yes — the HDMI inputs and onboard decoding are designed for non-sync content presented alongside theatrical features.
How does it connect to the Q-SYS Core? Over Q-LAN, QSC's networked audio distribution technology.
What about warranty and support? Coverage follows QSC's published warranty terms. Contact Creation Networks support for design and integration help.
