QSC Digital Cinema Input/Output for Q-SYS - DCIO

DCIO is a cinema-specific interface that serves as the audio I/O for each screen in a Q-SYS enabled cinema complex. The DCIO – along with Q-SYS™ Cores, DPA-Q amplifiers and DCS loudspeakers – provides a cost-effective way to realize the full benefits of a Q-SYS enabled cinema for every room in a multiplex, by delivering a full-system approach to cinema audio
design. Using Q-SYS Designer and custom UCIs, touchpanels, and mobile apps, the
user can configure, control, and monitor their theatre audio equipment through a
seamless system view.

Features

• Digital Cinema Inputs/Outputs for
Q-SYS™ enabled cinemas and
cinema complexes
• Routes inputs/outputs from
projector IMB and alternate
content sources to Q-SYS Core
over Q-LAN, QSC’s network
distribution technology
•16 channel AES/EBU inputs
from IMB
• Mic/line input
• Line level monitor output
• Powered monitor output to passive
speaker
• HDMI 2.0/HDCP 2.2 input/output
for non-sync sources (DCIO-H
version only)
• Dolby Audio™ (featuring Dolby
Digital Plus™ and Dolby® Surround
7.1) and DTS-HD® decoding
(DCIO-H version only)
• Four relay control outputs
• HI/VI outputs
• Automation inputs include RS-232
and GPI
