Panasonic PT-FRQ50BU7 5,200 Lumens, 1DLP, 4K (3840 x 2160 pixels) (With Quad Pixel Drive) laser projector, CEC compatibility (Black)
Panasonic PT-FRQ50BU7 5,200 Lumens, 1DLP, 4K (3840 x 2160 pixels) (With Quad Pixel Drive) laser projector, CEC compatibility (Black) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Panasonic PT-FRQ50BU7 5,200 Lumens, 1DLP, 4K (3840 x 2160 pixels) (...
Product Overview
The Panasonic PT-FRQ50BU7 is a 5,200-lumen 4K DLP laser projector for commercial installations that need detailed imagery and continuous uptime, from corporate showcases to public performance spaces. A single-chip DLP engine with SOLID SHINE laser and Quad Pixel Drive renders 4K (3,840 × 2,160) on screen, while filter-free cooling supports 24/7 operation. As a commercial installation projector, it combines 4K DIGITAL LINK transport, Free Grid geometry correction, and laser failover redundancy for demanding fixed-install AV. The black cabinet suits ceiling-mounted deployments and darker rooms where a low-visibility finish is preferred.
Product Description
The PT-FRQ50BU7 uses Quad Pixel Drive to shift 1080p imaging vertically and horizontally for a 4K on-screen result, paired with Rich Color Enhancer for brighter, more faithful color in well-lit rooms. Installers can align the image on irregular surfaces with joystick-controlled vertical and horizontal lens shift, 2x optical zoom, and Free Grid, which overlays a selectable 2×2 to 16×16 grid for precise, PC-free correction. Built for permanent deployment, the projector uses filterless head-pipe cooling and a hermetically sealed optical block for roughly 20,000 hours of maintenance-free operation, and its failover circuitry with redundant laser modules limits brightness loss if a single diode fails. 4K DIGITAL LINK carries uncompressed 4K/60p video and control over a single CAT 5e or higher run up to 164 feet, and Ethernet cloning copies settings to as many as 99 projectors for large rollouts. For comparable Panasonic options, see the white-cabinet PT-FRQ50WU7, the brighter PT-FRQ60BU7, and the WUXGA PT-FRZ50BU7.
Key Features
- 4K via Quad Pixel Drive — Rapid vertical and horizontal pixel shifting renders 3,840 × 2,160 imagery from the 1-chip DLP engine.
- 5,200-Lumen SOLID SHINE Laser — Sustains brightness for well-lit rooms without lamp replacement.
- Filter-Free 24/7 Operation — Head-pipe cooling and a sealed optical block support roughly 20,000 hours of maintenance-free runtime.
- Laser Failover Redundancy — A multi-laser drive engine limits brightness loss if a single diode or module fails during operation.
- Free Grid Geometry Correction — PC-free 2×2 to 16×16 grid correction aligns the image to irregular surfaces and objects.
- 4K DIGITAL LINK Transport — Carries uncompressed 4K/60p video and control over a single CAT 5e+ run up to 164 feet.
- Settings Cloning — Copies configuration to up to 99 projectors over Ethernet for consistent large installations.
- Review Preview Lite — Lets operators preview image adjustments on a laptop before a presentation, even in standby.
Typical Applications
- Conference room
- Auditorium
- House of worship
- Multi-purpose room
- Training room
- Broadcast studio
Technical Specifications
| Brightness | 5,200 lumens |
|---|---|
| Imaging System | 1-chip DLP |
| Light Source | SOLID SHINE laser |
| On-Screen Resolution | 4K (3,840 × 2,160) via Quad Pixel Drive (1080p native, pixel-shifted) |
| Geometry Correction | Free Grid (selectable 2×2, 4×4, 8×8, 16×16) |
| Zoom / Lens Shift | 2x optical zoom; joystick-controlled vertical and horizontal lens shift |
| Cooling / Maintenance | Filter-free head-pipe cooling; sealed optical block; ~20,000 hours maintenance-free |
| Duty Cycle | 24/7 operation |
| Signal Transport | 4K DIGITAL LINK, uncompressed 4K/60p over CAT 5e+ up to 164 ft; settings cloning to 99 units |
| Reliability | Failover circuitry with redundant laser modules |
| HDMI Control | CEC compatible |
| Cabinet Color | Black |
Specifications sourced from Panasonic / vendor data. Throw ratio, lens-shift range values, dynamic contrast ratio, power consumption, fan noise level, dimensions, and weight require manual review against the current Panasonic PT-FRQ50BU7 spec sheet.
Competitor Comparison
| Criteria | Panasonic PT-FRQ50BU7 | Epson Pro L630U | Sony VPL-FHZ75 |
|---|---|---|---|
| On-screen resolution | 4K (3,840 × 2,160) rendered via Quad Pixel Drive pixel shifting. | WUXGA with 4K signal acceptance, not full 4K-class pixel-shift display. | WUXGA native; accepts 4K input but displays at WUXGA. |
| Imaging technology | Single-chip DLP with sealed optics. | 3LCD with replaceable air filter. | 3LCD (BrightEra). |
| Brightness class | 5,200 lumens for mid-size rooms with ambient light. | 6,000-lumen class, brighter for larger rooms. | 6,500-lumen class, brighter for larger venues. |
| Maintenance model | Filter-free, sealed for 24/7 duty with ~20,000-hour maintenance-free runtime. | Uses a replaceable air filter requiring periodic service. | Laser engine with filter maintenance per Sony guidance. |
| Reliability features | Failover circuitry and redundant laser modules for sustained uptime. | Standard laser engine without published multi-module failover. | Standard laser engine without published multi-module failover. |
| Signal transport | 4K DIGITAL LINK over single CAT 5e+ run with settings cloning to 99 units. | HDBaseT transport; no Panasonic DIGITAL LINK cloning ecosystem. | HDBaseT transport; no DIGITAL LINK ecosystem. |
| Installer differentiator | 4K display plus failover redundancy in a compact 1-chip body. | Broad interchangeable-lens lineup on a different mount system. | Sony installation lens range on its own mount system. |
Competitor positioning is indicative; confirm current model specifications with each manufacturer before procurement.
Frequently Asked Questions
Does the PT-FRQ50BU7 display true 4K? It renders a 4K (3,840 × 2,160) on-screen image using Quad Pixel Drive, which shifts a 1080p imager to reconstruct 4K detail. It accepts 4K source signals and is well suited to detailed data and high-resolution content.
Can it run continuously in a 24/7 installation? Yes. Filter-free head-pipe cooling and a sealed optical block are designed for around-the-clock operation with approximately 20,000 hours of maintenance-free use.
How does it integrate over a network? 4K DIGITAL LINK carries uncompressed 4K/60p video and control over a single CAT 5e or higher cable up to 164 feet, and Ethernet lets you clone settings across as many as 99 projectors for uniform large deployments.
What happens if a laser diode fails? Failover circuitry and a multi-laser drive engine with redundant modules limit brightness loss so the projector keeps operating until service can be scheduled.
What warranty and support apply? Coverage follows Panasonic's commercial projector warranty; terms and extended-service options vary. Contact Creation Networks for current warranty details and Panasonic Pro AV service options.
