Panasonic ET-DLE020 0.28:1, ultra short-throw lens with power zoom (for use with compatible 1DLP projectors)
Panasonic ET-DLE020 0.28:1, ultra short-throw lens with power zoom (for use with compatible 1DLP projectors) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Panasonic ET-DLE020 0.28:1, ultra short-throw lens with power zoom ...
Product Overview
The Panasonic ET-DLE020 is a 0.28:1 ultra short-throw zoom lens with power zoom and zero offset, built for compatible Panasonic 1-chip DLP laser projectors in tight-clearance commercial AV installations. This ultra short-throw projector lens lets integrators mount a projector close to the screen wall for digital signage, lobby projection, and rear-projection applications where projector-to-screen distance is limited.
Product Description
The ET-DLE020 delivers an ultra short-throw ratio of 0.28:1 (WUXGA) with a power-zoom installation margin and zero image offset, allowing full top-to-bottom screen coverage with minimal shadowing even in low-ceiling rooms. Its straight, mirrorless optical path supports on-axis, screen-centered installation for rear-projection setups, while the aspherical all-glass design is heat- and scratch-resistant for long-term commercial use. Combined with the wide vertical and horizontal lens shift of compatible Panasonic laser projectors, it broadens placement options and supports edge-blended multi-screen projection. For longer projector-to-screen distances on the same 1DLP projector platforms, compare it with standard zoom options such as ET-DLE060, ET-DLE105, ET-DLE170.
Key Features
- 0.28:1 Ultra Short-Throw Ratio - Projects a large image from a few inches off the wall for tight-clearance installs.
- Power Zoom with Zero Offset - Provides a 1.77 in installation margin and centered projection for flexible alignment.
- Aspherical All-Glass Optics - Heat- and scratch-resistant construction supports continuous commercial duty cycles.
- Mirrorless Straight Design - Enables on-axis, screen-centered rear-projection installation.
- Edge-Blend Ready - Works with compatible projector lens shift for multi-screen and blended configurations.
- Wide Projection Range - Supports 100 in to 400 in image sizes on compatible 1DLP laser projectors.
Typical Applications
- commercial meeting space
- multi-purpose room
- government space
- house of worship
Technical Specifications
| Lens Type | Ultra short-throw, power zoom |
|---|---|
| Throw Ratio | 0.28 - 0.299:1 (WUXGA); 0.294 - 0.314:1 (WXGA); 0.29 - 0.309:1 (XGA) |
| Aperture | f/2 |
| Focal Length | f = 4.1 - 4.4 mm |
| Projection Size | 100 in - 400 in (254 - 1016 cm) |
| Lens Shift | Vertical: -16 to 50%; Horizontal: -20 to 10% |
| Compatibility | Panasonic PT-RCQ10, PT-RCQ80, PT-RZ120, PT-RZ970, PT-RW930, PT-RX110, PT-RZ870, PT-RZ770, PT-RW730, PT-RZ660, PT-RW620 |
| Dimensions (diam x L) | diam 170.0 mm x L 391.0 mm (6.7 in x 15.4 in) |
| Weight | 7.05 lb / 3.2 kg |
Frequently Asked Questions
Which projectors accept the ET-DLE020? It is compatible with Panasonic 1DLP laser models including the PT-RCQ10, PT-RCQ80, PT-RZ120, PT-RZ970, PT-RW930, PT-RX110, PT-RZ870, PT-RZ770, PT-RW730, PT-RZ660, and PT-RW620. Verify your exact model before ordering.
How close to the wall can the projector sit? With a 0.28:1 throw ratio and zero offset, the projector can be installed very close to the screen wall, reducing shadowing and presenter eye strain in low-ceiling rooms.
Is it suitable for rear projection? Yes. The mirrorless straight optical design supports on-axis, screen-centered rear-projection installation.
Can it be used for edge-blended video walls? Yes, when paired with the lens shift of compatible Panasonic laser projectors, it supports multi-screen edge-blending.
Who should install it? A qualified AV integrator should handle lens installation and optical alignment, especially for rigged or rear-projection deployments.
