Meyer Sound ULTRA-X80 Versatile Point Source Loudspeaker - 09.330.001.01
Meyer Sound ULTRA-X80 Versatile Point Source Loudspeaker - 09.330.001.01 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Meyer Sound ULTRA-X80 Versatile Point Source Loudspeaker - 09.330.0...
Product Overview
The Meyer Sound ULTRA-X80 is a versatile self-powered point source loudspeaker designed for permanent installation and portable reinforcement in large rooms and venues. With 95-degree horizontal by 40-degree vertical coverage, it delivers wide, even pattern control for auditoriums, houses of worship, and multi-purpose performance spaces. Its dual 12-inch low-frequency section and 4-inch diaphragm compression driver produce high output with the tonal accuracy associated with the Meyer Sound point source line. Onboard amplification and processing make it a complete loudspeaker system in a single enclosure.
Product Description
The ULTRA-X80 pairs two 12-inch long-excursion cone drivers with a single 4-inch diaphragm compression driver mounted to a rotatable horn, allowing the 95-degree by 40-degree pattern to be oriented for either horizontal or vertical deployment. The enclosure is built from premium multi-ply birch with a textured black finish and a powder-coated steel grille. Standard analog and digital audio inputs are both provided, with the digital path being AVB and Milan certified for networked system integration. For tighter pattern control in longer-throw applications, the Meyer Sound ULTRA-X82 offers a narrower 50-degree horizontal coverage, and additional models are available through the Meyer Sound collection. Low-frequency extension can be added with a companion subwoofer such as the Meyer Sound 750-LFC. The integrated amplification and telemetry provide a complete, self-contained loudspeaker for demanding installed and touring systems.
Key Features
- Point Source Design — A unified two-way point source format delivers consistent coverage and predictable pattern control across the listening area.
- 95-degree Horizontal Coverage — The wide 95-degree by 40-degree pattern suits broad audience areas in auditoriums and worship spaces.
- Dual 12-inch Low Frequency — Two 12-inch long-excursion cone drivers provide substantial low-frequency output and headroom.
- Rotatable Horn — The 4-inch diaphragm compression driver mounts to a rotatable horn for flexible horizontal or vertical orientation.
- Self-Powered — Onboard amplification and signal processing make the loudspeaker a complete system in a single enclosure.
- Analog and Digital Inputs — Standard analog XLR and AVB/Milan-certified digital inputs support both conventional and networked audio.
- Loudspeaker Telemetry — Telemetry transmitted over the Ethernet port allows remote monitoring in Meyer Sound software.
Typical Applications
- House of worship main and fill systems
- Auditorium and performing arts reinforcement
- Multi-purpose and multi-purpose performance rooms
- Government and civic assembly spaces
- All-hands and large meeting venues
Technical Specifications
| Operating Frequency Range | 55 Hz - 18 kHz, ±6 dB |
| AES75 Maximum Linear SPL | 122 dBZ, 140 dBZpk, 119.6 dBA (RMS input +3.0 dBV, 50°C) |
| Horizontal Coverage | 95° |
| Vertical Coverage | 40° |
| Low Frequency | Two 12-inch long-excursion cone drivers |
| High Frequency | One 4-inch diaphragm compression driver on a rotatable horn |
| Weight | 62.6 kg (138 lb) |
| Enclosure | Premium multi-ply birch, textured black finish |
| Rigging | M8 x 1.25 mm attachment points, six on bottom, six on top |
| AC Connector | Neutrik powerCON TRUE1 TOP |
| Operating Voltage | 200 - 240 V AC, 50 or 60 Hz |
| Max Long-Term Continuous Power | 900 W (>10 sec) |
| Burst Power | 2400 W (<1 sec) |
| Idle Power | 55 W |
| Analog Input | Neutrik XLR 3-pin TOP female input with male loop output |
| Digital Input | Neutrik etherCON TOP; AVB, Milan Certified |
Specifications sourced from Meyer Sound. Subject to change without notice.
Competitor Comparison
| Criteria | Meyer Sound ULTRA-X80 | L-Acoustics X15 HiQ | d&b E12 |
| Format | The ULTRA-X80 is a self-powered two-way point source with dual 12-inch low-frequency drivers and onboard amplification. | The X15 HiQ is a passive coaxial point source requiring external L-Acoustics amplification. | The E12 is a passive two-way point source driven by an external d&b amplifier. |
| Amplification | Amplification and processing are built into the ULTRA-X80 enclosure. | The X15 HiQ relies on external amplifier controllers for power and processing. | The E12 relies on external d&b amplifiers for power and processing. |
| Networked Audio | The ULTRA-X80 includes an AVB, Milan-certified digital input alongside analog. | The X15 HiQ uses analog input at the loudspeaker with networking handled upstream. | The E12 uses analog input at the loudspeaker with networking handled upstream. |
| Coverage | The ULTRA-X80 provides 95-degree horizontal by 40-degree vertical coverage from a rotatable horn. | The X15 HiQ offers a rotatable 40-degree by 60-degree pattern. | The E12 offers a rotatable 75-degree by 40-degree pattern. |
| Monitoring | The ULTRA-X80 transmits loudspeaker telemetry over Ethernet for remote monitoring. | The X15 HiQ provides monitoring through its external amplified controllers. | The E12 provides monitoring through its external d&b amplifiers. |
Frequently Asked Questions
Is the ULTRA-X80 self-powered?
Yes. Amplification and signal processing are built into the enclosure, so no external amplifier is required.
What is the coverage pattern?
The ULTRA-X80 provides 95-degree horizontal by 40-degree vertical coverage, and the horn is rotatable for horizontal or vertical orientation.
Does it support networked audio?
Yes. It provides a standard analog XLR input plus an AVB, Milan-certified digital input over a Neutrik etherCON connection.
Can I add a subwoofer?
Yes. A companion subwoofer such as the Meyer Sound 750-LFC can extend low-frequency response for full-range systems.
What warranty applies?
This product is covered under Meyer Sound's standard product warranty. For details, please contact us.
