Meyer Sound 900-LFC 3100W Powered Subwoofer with 18" LF Driver (No Rig) - 09.246.201.11
Meyer Sound 900-LFC 3100W Powered Subwoofer with 18" LF Driver (No Rig) - 09.246.201.11 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Meyer Sound 900-LFC 3100W Powered Subwoofer with 18" LF Driver...
Product Overview
The Meyer Sound 900-LFC is a compact self-powered low-frequency control element for scalable low-frequency reinforcement in touring and fixed installations. This no-rig configuration omits the QuickFly rigging frame, making it ideal for ground-stacked and pole-mounted deployments at a lower cost and weight. A single 18-inch long-excursion driver and an onboard class D amplifier deliver high continuous output with extremely low distortion. It is a natural low-frequency complement for Meyer Sound LEOPARD line array systems.
Product Description
This variant ships without rigging, which lowers cabinet weight to 136 lb and suits ground-stacked subwoofer arrays and pole-mounted pairings. Inside, a two-channel open-loop class D amplifier rated at 3100 W peak resides in a single field-replaceable module containing the amplifier and control circuitry. The integral pole-mount receptacle pairs the unit with ULTRA Series loudspeakers, and RMS remote monitoring reports operating parameters to a Mac or Windows host computer. Units can later be transported in stacks using the optional MCF-900 caster frame, which accommodates cabinets with or without rigging. For flown applications, the rigging-equipped 900-LFC or the larger Meyer Sound VLFC arrayable subwoofer may be preferable, and the matching array system is the Meyer Sound LEOPARD line array loudspeaker. See the full Meyer Sound collection for processing and accessories.
Key Features
- 18-inch LF Driver — A single dual-coil, long-excursion 18-inch cone driver with 2 ohm nominal impedance produces high-output, low-distortion low frequencies.
- Self-Powered Class D Amplifier — A two-channel, open-loop class D amplifier rated at 3100 W peak is housed in a field-replaceable module.
- No-Rig Configuration — Without the rigging frame the cabinet weighs 136 lb and suits ground-stacked and pole-mounted deployments.
- Low Distortion — THD, IM, and TIM measure below 0.02 percent for exceptional linearity and transient reproduction.
- RMS Remote Monitoring — A two-conductor twisted-pair network reports all amplifier operating parameters to a host computer.
- Integral Pole Mount — A built-in pole-mount receptacle pairs the subwoofer with ULTRA Series loudspeakers.
- Caster Frame Ready — Compatible with the optional MCF-900 caster frame for transport in stacks.
Typical Applications
- House of Worship — Provides ground-stacked low-frequency reinforcement for worship spaces.
- Auditorium — Extends low-frequency response for theatrical and presentation sound systems.
- Multi-Purpose Room — Supports flexible ground-stacked low end across varied events.
- Broadcast Studio — Delivers linear, low-distortion low frequencies for production audio.
Technical Specifications
| Operating Frequency Range | 30 Hz – 125 Hz |
| Frequency Response | 32 Hz – 115 Hz ±4 dB |
| Phase Response | 40 Hz – 110 Hz ±30° |
| Linear Peak SPL | 133 dB with crest factor >10 dB (M-noise) |
| Low Frequency Driver | One 18-inch dual-coil, long-excursion cone driver; 2 Ω nominal |
| Amplifier | Two-channel, open-loop, class D; 3100 W peak |
| THD, IM, TIM | < 0.02% |
| AC Power | powerCON 20 input with loop; 90–265 V AC, 50–60 Hz |
| Dimensions without Rigging | W 27.43 in x H 24.43 in x D 24.89 in (697 x 621 x 632 mm) |
| Weight without Rigging | 136 lb (61.7 kg) |
| Enclosure | Premium multi-ply birch with textured black finish |
Specifications sourced from Meyer Sound. Subject to change without notice.
Competitor Comparison
| Criteria | Meyer Sound 900-LFC | L-Acoustics KS21 | d&b SL-SUB |
| Amplification | The 900-LFC is self-powered with an integrated class D amplifier in the cabinet. | The KS21 is externally amplified and requires an LA-series amplified controller. | The SL-SUB is externally amplified and requires a d&b amplifier. |
| Driver Configuration | It uses a single 18-inch long-excursion driver. | It uses a single 21-inch driver. | It uses dual 21-inch drivers in a larger cabinet. |
| Monitoring | It includes Meyer Sound RMS remote monitoring of all amplifier parameters. | Monitoring is handled through the external amplifier and LA Network Manager. | Monitoring is handled through the external amplifier and R1 software. |
| System Integration | It integrates directly with LEOPARD arrays using the shared MG-LEOPARD/900 grid. | It integrates within the L-Acoustics K and Kara array ecosystem. | It integrates within the d&b SL-Series ecosystem. |
Frequently Asked Questions
Can rigging be added later? This unit ships without the rigging frame. The optional MRK-900 rigging kit adds flying capability; please contact us to confirm field-fit options for your unit.
Is it compatible with LEOPARD systems? Yes. It is designed as a low-frequency complement for LEOPARD arrays and shares the MG-LEOPARD/900 grid ecosystem when equipped with rigging.
Does it require an external amplifier? No. The 900-LFC is self-powered and can be driven and aligned using a Meyer Sound Galileo GALAXY Network Platform.
How is it transported? The optional MCF-900 caster frame transports cabinets in stacks and accommodates units with or without rigging.
What warranty applies? This product is covered under Meyer Sound's standard product warranty. For details please contact us.
