MaxHub V925 XBoard V7 92” Ultra-Wide for Microsoft Teams Rooms

Product Overview

The MaxHub V925 XBoard V7 is a 92-inch ultra-wide interactive flat panel built for hybrid conferencing, command-and-control environments, and large-format collaboration spaces. Sharing the same 21:9 ultra-wide 5K (5120×2160) panel architecture as the Teams-certified V925T, the V925 delivers the full XBoard V7 feature set—Trident Lens triple camera system, 16-microphone array, and 50-point touchscreen—on the Windows 11 IoT platform in a non-Teams-certified configuration that is ideal for organizations running multiple UC platforms. AV integrators specifying a 92-inch ultra-wide interactive display for boardrooms, operations centers, or multi-purpose rooms will find the V925 a capable all-in-one solution without requiring a separate compute unit or audio system.

Product Description

The V925 is built on the same XBoard V7 hardware platform as the V925T. Its 92-inch IPS panel with 21:9 aspect ratio and 5120×2160 (5K) resolution provides the panoramic canvas that makes it uniquely effective for side-by-side content layouts, wide-room monitoring, and multi-source display scenarios. The integrated Trident Lens system combines three 50-megapixel cameras (one wide-angle panoramic and two telephoto) with AI scene intelligence for auto-framing, speaker tracking, and 5× hybrid zoom—capabilities typically requiring a separate PTZ camera. The 16-microphone array delivers 15-meter voice pick-up with AI noise cancellation and echo suppression. Windows 11 IoT is the operating system, supporting the MAXHUB Share app for wireless BYOM from any device, as well as Miracast, AirPlay, and Chromecast. For a Teams Rooms-certified version of this panel, see the MaxHub V925T. For a smaller Teams Rooms display, see the MaxHub V865T 86". Browse the full MaxHub catalog at Creation Networks.

Key Features

• 92" 21:9 Ultra-Wide 5K Panel — 5120×2160 resolution at 21:9 supports panoramic content layouts, multi-source display, and Microsoft Teams Front Row when paired with the Teams Rooms application.
• Trident Lens Triple Camera System — Three 50-megapixel cameras with AI auto-framing, speaker tracking, multi-speaker tracking, and 5× hybrid zoom deliver conference-quality video without an external PTZ unit.
• 16-Microphone Array — 180° capture with 15-meter range, AI noise cancellation, AEC, and AGC for clear full-room audio pick-up.
• 2.1-Channel Integrated Audio — 2×10W plus 20W subwoofer with adaptive EQ and spatial sound processing, eliminating the need for an external speaker system.
• 50-Point Infrared Touchscreen — Zero-parallax 9H tempered glass (25% haze) with Windows Ink, direct annotation, palm rejection, and handwriting recognition.
• Windows 11 IoT Compute Module — 12th Gen Intel Core i5-1240P, 16 GB DDR4, 256 GB SSD integrated—no external PC required.
• Wi-Fi 6 & Bluetooth 5.2 — 802.11ax dual-band wireless for MAXHUB Share, Miracast, AirPlay, and Chromecast content sharing.
• HDMI, USB-C & RJ45 I/O — HDMI IN×2, USB-C IN×1 (DP 1.2 + BYOD), USB 3.0×2, USB 2.0×1, Gigabit Ethernet, Audio Out, RS232.
• OPS Slot — PC module slot supports optional compute module upgrades or alternative OS deployments.

Typical Applications

• Boardroom
• Conference room
• All-hands room
• Commercial meeting space
• Government space
• Multi-purpose room
• Auditorium

Technical Specifications

Specifications sourced from MaxHub (maxhub.com).

Frequently Asked Questions

What is the difference between the V925 and the V925T?
The V925T carries Microsoft Teams Rooms certification and ships with the MTR application pre-installed and pre-configured. The V925 runs Windows 11 IoT and the full XBoard V7 hardware feature set but is not factory-MTR-certified, making it suitable for organizations using Zoom Rooms, custom UC deployments, or other Windows-based collaboration applications.

Can the V925 be used with Microsoft Teams?
Yes. The V925 runs Windows 11 IoT and the Teams Rooms application can be installed and licensed by your IT team. For a factory-certified Teams Rooms experience, the V925T is recommended.

Does the V925 require an external camera or microphone?
No. The Trident Lens triple camera system and 16-microphone array are fully integrated into the display unit. No external PTZ camera, USB camera bar, or ceiling microphone is required for most conference room deployments.

What mounting options are available for a 92-inch display?
The V925 is designed for permanent wall installation using a compatible VESA mount (specifications available from Creation Networks). Contact Creation Networks for mount recommendations and professional installation services.

How does BYOD content sharing work?
Wired BYOD is supported via HDMI 2.0 or USB-C (DisplayPort 1.2). Wireless sharing is available through the MAXHUB Share app (Windows/Mac/iOS/Android), Miracast, AirPlay, and Chromecast without requiring a Wi-Fi network for ultrasonic P2P connections.

Who do I contact for installation, integration, or support?
Contact Creation Networks for AV system design, volume pricing, and post-sale support. Creation Networks is an authorized MaxHub reseller with commercial AV integration expertise.
