MaxHub UW92NA 92” Ultra Wide Commercial Display

Product Overview

The MAXHUB UW92NA is a 92" 21:9 ultra-wide commercial display delivering 5K resolution (5120×2160) for Microsoft Teams Signature Rooms, hybrid conferencing, command-and-control environments, and large-format commercial display applications. At 600 nits and rated for 24/7 continuous operation, the UW92NA provides the high-brightness, wide-canvas performance demanded by enterprise conference rooms and immersive visual installations. The built-in Android 13 system with 8GB RAM and 64GB storage, combined with a dual Wi-Fi 6 module and OPS slot, makes it a complete conferencing and digital signage platform. Crestron Connected certified with RS232/IP control, it integrates directly into professional AV control infrastructures.

Product Description

The MAXHUB UW92NA 92" ultra-wide commercial display provides 33% more horizontal visual canvas than a comparable 16:9 display of the same height, making it the purpose-built choice for Microsoft Teams Front Row and Signature Room configurations where participant video, shared content, and meeting controls must all occupy the screen simultaneously without compression. The 5K (5120×2160) VA panel renders text, video, and data at native pixel density across the full 21:9 field, at 600 nits — the highest brightness in the CMA/UW commercial line — for maximum legibility in daylit or high-ambient-light rooms. The 24/7 commercial duty cycle and 50,000-hour panel lifetime rating support continuous use in executive briefing centers, operations rooms, and premium conference facilities. Android 13 with MAXHUB Meeting OS V6 runs on an octa-core ARM processor (A76×4 + A55×4) with Mali-G610 GPU, 8GB RAM, and 64GB storage, providing a capable on-display compute platform for MAXHUB Share, digital signage playback, and collaboration applications. Connectivity includes four HDMI inputs (three HDMI 2.0 + one HDMI 2.1), DisplayPort, USB Type-C (100W PD), four USB 3.0 ports, RS232, and dual RJ45 (in/out) for network passthrough. The 2.1-channel speaker system (2×20W + 20W subwoofer) delivers substantial audio for large rooms without external speakers. An OPS module slot accepts OPS62A or OPS72A modules for full Windows-based conferencing. Crestron Connected certification enables XiO Cloud management, and Q-SYS and Extron control are natively supported via RS232/IP. Screen rotation and Wake on LAN are supported for automated room management. For the 105" sibling, see the MAXHUB UW105NA. For standard-format CMA displays, browse the full MAXHUB collection at Creation Networks.

Key Features

• 92" 21:9 Ultra-Wide Format — 33% more horizontal screen canvas than comparable 16:9 displays; purpose-built for Microsoft Teams Front Row and Signature Room configurations.
• 5K Resolution (5120×2160) — Native 5K pixel density across the full 21:9 panel for sharp text, video, and data visualization at commercial scale.
• 600 Nits Brightness — Highest-brightness UW/CMA model; maintains clear display legibility in daylit and high-ambient-light conference environments.
• 24/7 Commercial Duty Cycle — Rated for continuous operation with a minimum panel lifetime of 50,000 hours for always-on installations.
• Android 13 / 8GB RAM / 64GB Storage — Octa-core ARM SoC (A76×4 + A55×4) running MAXHUB Meeting OS V6 for on-display applications and digital signage without a PC.
• 2.1-Channel Speaker System — 2×20W + 20W subwoofer provides substantial audio coverage for large conference rooms without external amplification.
• OPS Slot (OPS62A / OPS72A) — Slot-in OPS module bay for optional Windows PC, enabling Teams Rooms, Zoom, Webex, or dedicated signage applications.
• Wi-Fi 6 + Bluetooth 5.2 — Dual-band 802.11ax with Bluetooth 5.2 for wireless device connectivity and BYOM peripheral support.
• Crestron Connected / Q-SYS / Extron — Certified and compatible with major AV control systems for enterprise room integration without custom programming.
• Full I/O Suite — 4× HDMI (2.0×3 + 2.1×1), DisplayPort, USB-C (100W PD), 4× USB 3.0, RS232, SPDIF, dual RJ45; VESA 800×600mm.

Typical Applications

• Boardroom
• Conference room
• Commercial meeting space
• Government space
• All-hands room
• Training room

Technical Specifications

Specifications sourced from MaxHub (maxhub.com).

Frequently Asked Questions

Why is 21:9 aspect ratio preferred for Microsoft Teams Rooms?
The 21:9 format is specifically optimized for Microsoft Teams Front Row layout, which displays participant video on a horizontal band below the shared content area. The wider canvas allows content, gallery, and meeting controls to coexist on screen simultaneously, replicating an in-person meeting experience for hybrid participants.

What OPS modules are compatible with the UW92NA?
The UW92NA accepts OPS62A and OPS72A slot-in Windows PC modules. Contact Creation Networks to match the appropriate OPS module for your Microsoft Teams Rooms or digital signage application.

What VESA mounting hardware does the UW92NA require?
The UW92NA uses an 800×600 mm VESA pattern. Given the 43 kg net weight and 2182 mm width, professional installation is recommended. A wall mount is included; contact Creation Networks for structural installation guidance.

What AV control systems are compatible with the UW92NA?
The UW92NA is Crestron Connected certified (XiO Cloud) and natively supports Q-SYS and Extron control via RS232 and IP. It also supports Wake on LAN and HDMI CEC for automated room management.

Is the UW92NA rated for 24/7 commercial use?
Yes. The UW92NA carries a 24/7 operation rating with a minimum panel lifetime of 50,000 hours, suitable for always-on executive briefing rooms and continuous-use conference facilities.

What warranty and support are available?
The UW92NA includes a 3-year display warranty. Contact Creation Networks for installation support, project configuration, and service coordination.
