Listen Tech C-Series Multiloop Driver 14A 120v/230v - C14-2N

Product Overview

The Listen Technologies C14-2N is a networked C-Series multiloop hearing loop driver rated at 14 A RMS / 48 V RMS, the most potent driver in the C-Series. Its high output voltage drives more current, making it suited to areas of high metal loss and large-venue installations where the driver sits far from the loop. As a 1U rack-mount loop driver with a 100 V line input, it is designed for permanent commercial assistive-listening loop systems. (For an otherwise identical unit with a Dante audio input, see the C14-2D (Dante version).)

Product Description

The C14-2N combines high output with precise control for demanding induction-loop installations. A simple digital interface allows accurate adjustment, and the unit operates as a networked or stand-alone device. Networking adds a browser interface for remote reporting, adjustment, active status monitoring, and fault reporting via email or Telnet, helping integrators manage loops across multiple rooms or sites. Dual outputs deliver an accurate, stable 90° phase shift for multiloop array designs, while built-in test tones and clear diagnostics speed commissioning. The driver is optimized for speech intelligibility while remaining capable of high-quality musical reproduction, and its data output is compliant with the IEC 62489-1 standard. A compact 1U rack-mount chassis with an internal power supply and industry-standard Phoenix connectors make it straightforward to integrate into a commercial AV rack.

Key Features

• 14 A RMS / 48 V RMS output — High current and voltage for high-metal-loss areas and large venues.
• Network and stand-alone operation — Deploy locally or manage over the network.
• Browser-based remote management — Remote reporting, adjustment, status monitoring, and fault alerts via email or Telnet.
• Dual outputs with 90° phase shift — Accurate, stable phase shift for multiloop array designs.
• Built-in test tones and diagnostics — Clear indicators speed setup and troubleshooting.
• Loopworks Measure LoopLink compatible — Direct, automated driver control during measurement.
• IEC 62489-1 compliant — Meets the international induction-loop performance standard.
• Compact 1U rack-mount — Internal power supply and Phoenix connectors for clean rack integration.
• 100 V line input — Direct connection to constant-voltage audio distribution.
• Optimized for speech, capable with music — High intelligibility plus quality musical reproduction.

Typical Applications

• Auditorium — High-output loop coverage for large seating areas.
• House of worship — Whole-room hearing loops with strong intelligibility.
• Government space — Networked monitoring and fault reporting for public buildings.
• Commercial meeting space / multi-purpose room — Multiloop designs for metal-rich structures.
• Broadcast studio — Precise control and IEC-compliant performance for critical audio.

Technical Specifications

Frequently Asked Questions

How is the C14-2N different from the C14-2D?
Both share the same 14 A RMS / 48 V RMS output and feature set. The C14-2N uses a 100 V line input, while the C14-2D adds a Dante audio input for networked audio routing.

When is the C14-2 output level needed?
For areas of high metal loss and large venues, or where the driver must sit far from the loop and needs extra current to maintain field strength.

Can the driver be monitored remotely?
Yes. When networked, a browser interface provides remote reporting, adjustment, status monitoring, and fault reporting via email or Telnet.

Does it meet hearing-loop standards?
Its data is compliant with IEC 62489-1, the international performance standard for induction-loop systems.

Is it a multiloop driver?
Yes. Dual outputs with an accurate 90° phase shift support phased-array loop designs that reduce spill.
