Extron TLP Pro 1025M 10" Wall Mount TouchLink Pro Touchpanel Black - Wall Mount, No Camera
Extron TLP Pro 1025M 10" Wall Mount TouchLink Pro Touchpanel Black - Wall Mount, No Camera is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Looking for a specific Extron product or custom AV solution? Our certified experts can source any Extron device to meet your project requirements. Please contact Creation Networks for a personalized quote or to learn more about our certified Extron design, programming, installation and maintenance services for conference rooms, auditoriums, training centers, and hybrid collaboration spaces. Creation Networks offers direct technical support during the initial Extron implementation and future support of Extron products as needed.
Extron TLP Pro 1025M 10" Wall Mount TouchLink Pro Touchpanel B...
Product Description
The Extron TLP Pro 1025M (No Camera) is a 10" wall mount TouchLink Pro touchpanel built for commercial AV control in environments where a camera-free device is required, such as secure facilities, government spaces, healthcare, and corporate boardrooms with privacy policies. This black, no-camera configuration delivers the same control capabilities as the standard 1025M while meeting deployment standards that prohibit onboard imaging hardware.
Internally, this Extron wall mount touchpanel pairs a high-performance quad-core processor and 2 GB of memory with a 1280x800 capacitive touchscreen protected by scratch- and smudge-resistant Corning Gorilla Glass. Power over Ethernet delivers both power and communication over a single Ethernet cable, so AV integrators and IT teams can deploy it on existing network infrastructure with minimal cabling. It works with any Extron control processor and the HC 400 Series for complete, interactive control of source devices.
Interfaces are designed in Extron GUI Designer using ready-made room templates and refined with Global Configurator or ControlScript. With the optional LinkLicense for TLP Control Processor and the TLCA 1 expansion adapter, this no-camera commercial AV touchpanel becomes a standalone Pro xi Series control system. Compare the standard TLP Pro 1025M, the tabletop TLP Pro 1025T, or browse the full Extron collection.
Key Features
- No-Camera Configuration — This black model ships without an onboard camera, meeting security and privacy requirements in government, healthcare, and corporate deployments.
- 10" Capacitive Touchscreen — The 1280x800 WXGA display with 24-bit color and Gorilla Glass provides a bright, durable control surface for daily commercial use.
- Quad-Core Performance — A quad-core processor with 2 GB RAM and 8 GB storage delivers fast, responsive operation across complex control interfaces.
- Power over Ethernet — PoE (IEEE 802.3af, class 3) supplies power and data over one Ethernet cable, simplifying installation and cabling.
- Flexible Mounting — The panel installs in a two-gang junction box or on a wall, lectern, furniture, glass, or rack to fit any room.
- Broad Control Compatibility — It works with any Extron control processor and the HC 400 Series for full interactive AV control.
- Standalone Control Option — LinkLicense for TLP Control Processor plus the TLCA 1 adapter turn it into a Pro xi Series control system supporting up to eight Ethernet devices.
- Environmental Sensors — A light sensor adjusts brightness to ambient lighting and a motion detector wakes the panel for energy savings.
- Enterprise Management — GlobalViewer Enterprise enables remote management, monitoring, and control across the AV deployment.
- TAA Compliant Version Available — A TAA-compliant configuration is available on request for government procurement.
Technical Specifications
| Model | Extron TLP Pro 1025M (No Camera) |
|---|---|
| Type | 10" wall mount TouchLink Pro touchpanel, black |
| Screen Type | TFT active matrix color LCD, capacitive touch |
| Display Size | 10.1" (25.7 cm), measured diagonally |
| Resolution | 1280x800 (WXGA) |
| Pixel Density | 149 PPI |
| Aspect Ratio | 16:10 |
| Color Depth | 24-bit, 16.7 million colors |
| Brightness | 420 nits (cd/m²) |
| Contrast | 800:1 |
| Backlight | LED |
| Viewing Angle | ±85° horizontal, ±85° vertical |
| Memory | 2 GB RAM, 8 GB storage |
| Ethernet | 1 female RJ-45; 10/100/1000Base-T, half/full duplex with autodetect |
| USB | 1 high-speed USB 2.0 device, 1 micro-B receptacle |
| Digital Input | 1 configurable digital input, 3.5 mm 2-pole captive screw connector |
| Audio Output | 2 mono speakers, 89 dB max SPL @ 0.1 m |
| Sensors | Motion sensor (on/off), light sensor (auto/manual) |
| Power Input | Power over Ethernet (PoE 802.3af, class 3) |
| Power Consumption | 12.9 watts (device) |
| Mounting | Wall, furniture, glass, or rack |
| Enclosure | Plastic |
| Dimensions | 6.84" H x 10.13" W x 1.26" D (174 x 257 x 32 mm) |
| Weight | 2.05 lbs (0.92 kg) |
| Regulatory Compliance | BIS, CE, c-UL, UL, C-Tick, FCC Class A, ICES, KC, VCCI, RoHS, WEEE |
| Warranty | 3 years parts and labor; display and overlay components covered for 1 year |
Frequently Asked Questions
How does the No Camera version differ from the standard TLP Pro 1025M?
The No Camera configuration ships without an onboard camera, otherwise matching the standard 1025M in display, processing, connectivity, and control features. It is intended for secure or privacy-sensitive environments that prohibit imaging hardware.
What control processors is it compatible with?
It works with any Extron control processor and the HC 400 Series. With the LinkLicense for TLP Control Processor it can also run standalone as a Pro xi Series control system.
How is the touchpanel powered?
It uses Power over Ethernet (IEEE 802.3af, class 3), drawing power and communication over a single Ethernet cable from a PoE switch or injector. No separate power supply is included.
Where can it be installed?
The panel mounts in a two-gang junction box or on a wall, lectern, furniture, glass, or rack, suiting conference rooms, secure facilities, and classrooms.
What warranty applies?
Extron provides a 3-year parts and labor warranty, with the display and overlay components covered for 1 year. A TAA-compliant version is available on request.
