Dolby Cinema Processor CP950

Note: This product is available by quote. Request a quote to discuss configuration and lead time.

Product Overview

The Dolby CP950 cinema processor drives audio playback in digital cinema auditoriums, delivering Dolby Surround 7.1 and 5.1 to the house. As the newest model in Dolby's cinema processor line, this digital cinema audio processor combines a modular, cost-efficient chassis with an expansion path to Dolby Atmos. It is built for exhibitors who need a reliable cinema processor for movie theaters today and a defined upgrade route tomorrow. The CP950 ships ready to integrate with the projection booth, the screen channels, and the surround arrays of a single auditorium.

Product Description

The CP950 is a Dolby Surround 7.1 cinema processor designed around field serviceability and straightforward installation. Its modular mechanical design lets a technician service or expand the unit in the rack without removing the entire chassis, and the expansion slot accepts the CP950-UPG hardware upgrade kit so the processor can become a Dolby Atmos upgradeable processor when paired with a Full Dolby Atmos License. The unit provides 16 channels of analog output or, alternatively, 16 channels of digital output carried over AES67 or BLU Link, making it a practical choice for AES67 cinema audio deployments and for sites standardizing on networked audio transport. Internal loudspeaker crossovers reduce the need for external processing and lower installation cost, while a high-resolution multi-rate EQ tunes each channel to the room. A built-in booth monitor lets the projectionist confirm audio quality without additional test gear. Operators control the processor from a color touchscreen front panel or remotely through the built-in web interface. The CP950 is compatible with Dolby Atmos Designer for setup and calibration and integrates directly with the Dolby multichannel amplifier. It is well suited to digital cinema auditoriums, screening rooms, and premium large-format houses that want immersive audio readiness in a single processor. For sites that need Atmos out of the box, the CP950A is the integrated-Atmos sibling. Browse the full Dolby Professional collection for matched components.

Key Features

• Dolby Surround 7.1 and 5.1 support — The processor decodes and routes both Dolby Surround 7.1 and 5.1 soundtracks, covering the formats in current theatrical release.
• Field-upgradeable to Dolby Atmos — An expansion slot accepts the CP950-UPG hardware upgrade kit and a Full Dolby Atmos License, so a single auditorium can move to immersive audio without replacing the processor.
• 16 channels of analog or digital output — The unit provides 16 channels of analog output or 16 channels of digital output over AES67 or BLU Link, matching either legacy amplifier racks or networked audio infrastructure.
• Internal loudspeaker crossovers — Built-in crossovers process the loudspeaker feeds directly, removing external processing hardware and reducing installation cost.
• High-resolution multi-rate EQ — Per-channel multi-rate equalization lets an integrator tune the system precisely to the acoustics of the room.
• Built-in booth monitor — An integrated booth monitor lets the projectionist verify audio quality directly from the rack for routine quality assurance.
• Color touchscreen and web interface — A front-panel color touchscreen handles local control while the web interface allows remote configuration from anywhere on the theater network.
• Dolby Atmos Designer compatibility — The processor works with Dolby Atmos Designer for guided setup and precise system calibration.
• Direct amplifier integration — The CP950 connects directly to the Dolby multichannel amplifier for a coordinated processing and amplification chain.

Typical Applications

• Digital cinema auditoriums in commercial multiplexes
• Premium large-format and Dolby Cinema auditoriums requiring an Atmos upgrade path
• Screening rooms and post-production review theaters
• Auditoriums and multi-purpose houses of worship deploying cinema-grade audio

Technical Specifications

Frequently Asked Questions

What audio formats does the CP950 support?

The CP950 supports Dolby Surround 7.1 and 5.1. It can be upgraded to full Dolby Atmos by installing the CP950-UPG hardware upgrade kit together with a Full Dolby Atmos License.

Can the CP950 be upgraded to Dolby Atmos later?

Yes. The processor includes an expansion slot, and its modular design supports field upgrade to Dolby Atmos. If you require Atmos from day one, the CP950A ships with an integrated Atmos media block instead.

How does the CP950 install and rack-mount in the booth?

The CP950 is a rack-mount cinema processor designed for straightforward installation and field service. Its modular mechanical design lets technicians service or expand the unit in place, and internal crossovers reduce the amount of external rack hardware required.

How does it integrate with the rest of the AV system?

The processor outputs 16 channels of analog audio or 16 channels of digital audio over AES67 or BLU Link, and it integrates directly with the Dolby multichannel amplifier. It is also compatible with Dolby Atmos Designer for system setup and calibration.

What warranty and support apply?

The manufacturer warranty applies to this product. For configuration, support, and service questions, contact Creation Networks and our team will assist with your deployment.

How do I purchase and what is the lead time?

This product is available by quote. Request a quote to confirm configuration, pricing, and current lead time for your auditorium project.
