Dell UltraSharp U2724D 27" 1440p Monitor - DELL-U2724D

Product Overview

The Dell UltraSharp U2724D is a 27-inch QHD monitor built for commercial AV deployments where color accuracy and clean connectivity matter. Using Dell's IPS Black technology, it delivers 2560 x 1440 resolution at a 120 Hz refresh rate with a 2000:1 typical contrast ratio for deeper blacks than standard IPS panels. With an integrated USB-C hub, DisplayPort daisy-chain output, and a fully adjustable stand, this commercial-grade monitor fits conference rooms, AV workstations, and multi-display setups. Factory-calibrated to 100% sRGB and 98% DCI-P3, it is a dependable color-accurate monitor for integrators specifying color-critical displays.

Product Description

The Dell UltraSharp U2724D 27-inch QHD monitor pairs Dell's IPS Black panel with a 120 Hz refresh rate, giving AV system designers a display that handles documents, design work, and video review with equal clarity. The 2560 x 1440 resolution spreads roughly 1.77x more working area than Full HD across the 27-inch screen, and the 2000:1 typical contrast ratio renders text and dark interface elements cleanly in controlled-light environments. Color coverage of 100% sRGB, 100% BT.709, and 98% DCI-P3 with an average Delta E under 2 makes this a color-accurate monitor suited to broadcast review and content workflows.

Connectivity is built for integration. A USB-C upstream port drives the integrated USB hub, a USB-C downstream port supplies 15W of device charging, and two 10 Gbps USB-A downstream ports handle peripherals. Dual DisplayPort 1.4 connections (one input, one output) enable DisplayPort daisy-chaining across multiple displays, while the HDMI input supports up to QHD at 120 Hz. The fully adjustable stand offers 150 mm of height travel plus tilt, swivel, and pivot, and the 100 x 100 mm VESA pattern supports articulating-arm and wall mounting in conference rooms and huddle rooms. An ambient light sensor, ComfortView Plus low-blue-light backlight, and Picture-by-Picture/Picture-in-Picture support round out a monitor designed for all-day commercial use. Compare related displays in our Dell collection.

Key Features

• IPS Black Panel — Delivers a 2000:1 typical contrast ratio for deeper blacks and better on-screen text legibility than conventional IPS.
• QHD 120 Hz Resolution — 2560 x 1440 at 120 Hz provides crisp detail and smooth motion for design, review, and multitasking.
• Factory Color Accuracy — Covers 100% sRGB, 100% BT.709, and 98% DCI-P3 with an average Delta E under 2 for color-critical work.
• Integrated USB-C Hub — A data USB-C upstream port plus 10 Gbps USB-A and USB-C downstream ports consolidate peripherals at the display.
• DisplayPort Daisy-Chain — DisplayPort 1.4 input and output let integrators link multiple monitors from a single source.
• Fully Adjustable Stand — 150 mm height, tilt, swivel, and pivot adjustment supports ergonomic placement in shared spaces.
• VESA Mountable — 100 x 100 mm pattern enables wall, arm, and cart mounting for conference rooms and huddle rooms.
• Ambient Light Sensor — Automatically adjusts brightness and color temperature for consistent viewing across the workday.

Typical Applications

• Conference room and boardroom presentation displays
• Huddle room and multi-purpose room workstations
• AV system design and content-review stations
• Broadcast studio monitoring and color review
• Government and commercial meeting space deployments
• Training room multi-monitor setups

Technical Specifications

Frequently Asked Questions

Can the U2724D daisy-chain multiple monitors?
Yes. The DisplayPort 1.4 output supports MST daisy-chaining, letting you drive additional displays from one source for multi-monitor conference room and workstation setups.

Does the USB-C port charge or dock a laptop?
The USB-C upstream port is data-only and powers the monitor's USB hub; it does not carry video or full laptop power delivery. The USB-C downstream port provides 15W for charging accessories. For laptop video, use HDMI or DisplayPort.

How is the monitor mounted in a commercial install?
It ships with a fully adjustable stand and uses a standard 100 x 100 mm VESA pattern, so it can be attached to articulating arms, wall mounts, or carts for conference rooms and huddle rooms.

Is it accurate enough for color-critical AV work?
Each unit is factory-calibrated and covers 100% sRGB, 100% BT.709, and 98% DCI-P3 with an average Delta E under 2, making it suitable for broadcast review and content production.

What warranty and support are included?
The U2724D includes Dell's 3-Year Advanced Exchange Service with Premium Panel Exchange, which covers panel defects including bright-pixel issues during the term.

Does it have built-in speakers?
No. The monitor provides a 3.5 mm audio line-out for connecting external speakers or a soundbar, which is typical for commercial-grade displays.

Dell U2724D vs. U2724DE vs. U2725QE: Which UltraSharp 27 Fits?

Buyers researching the U2724D almost always end up weighing it against Dell's Thunderbolt docking sibling, the U2724DE, and the newer 4K U2725QE. All three share the IPS Black panel family, the 150 mm height-adjustable stand and the same 3-year exchange coverage. The real decision is docking, networking and resolution — not picture quality.

Choose the U2724D when the workstation already has a dock, a desktop tower, or an AV source that outputs DisplayPort or HDMI, and you simply want the best 27-inch QHD panel Dell ships without paying for docking hardware you will not use. Choose the U2724DE when a laptop needs one cable for video, 90 W charging, wired 2.5GbE and KVM switching. Choose the U2725QE when you need 4K detail, HDR, or higher brightness for content review.

The older U2723DE occupies the same docking slot as the U2724DE but at 60 Hz; the U2724D's 120 Hz panel is the main generational upgrade over the 2022-era UltraSharp 27 models. There is no QHD "U2725D" in Dell's current UltraSharp 27 line — the 2025 refresh at this size is the 4K U2725QE, so if a spec sheet or quote references a U2725D, confirm the intended model before ordering.

Deployment Notes for Integrators

Desk and mount planning. With the supplied stand the U2724D occupies 24.10" of width and 7.57" of depth, and the screen height travels from 15.18" to 21.09". Full assembly weight is 14.46 lb; the panel alone is 9.90 lb. When specifying articulating arms, dual-monitor stands or wall plates, size the mount to the 9.90 lb panel weight and the 100 x 100 mm VESA pattern, and confirm the arm's range covers the intended sightline before removing the factory stand.

Electrical load planning. The monitor draws 23.9 W in typical on-mode, up to 85 W maximum, and 0.5 W in standby, on a 100–240 VAC, 50/60 Hz input. At typical draw, a bank of four U2724D displays lands under 100 W total, which leaves ample headroom on a standard 120 V circuit and on a 900 W-class UPS shared with a PC and network gear. Use the 85 W maximum figure, not the typical figure, when sizing rack PDUs and UPS capacity for worst-case simultaneous startup.

Cabling. The box includes a 1.8 m DisplayPort-to-DisplayPort cable and a 1 m USB-A to USB-C Gen 2 cable. It does not include an HDMI cable or a USB-C-to-USB-C cable, so add those to the bill of materials if the source requires them. To run 2560 x 1440 at 120 Hz, use the supplied DisplayPort 1.4 cable or a DisplayPort 1.4-rated equivalent; the HDMI input also supports QHD at 120 Hz, but a low-bandwidth HDMI cable or an older source will fall back to 60 Hz.

Daisy-chain planning. The DisplayPort 1.4 output enables MST daisy-chaining from a single source connection. Confirm the host GPU or dock supports DisplayPort MST and has enough bandwidth budget for the number of QHD 120 Hz displays in the chain; feed the first monitor from the source's DisplayPort output, then run monitor-to-monitor from the DP out.

Ordering identifiers. Dell lists this display under order code u2724dsap, Dell part number 210-BKSF and manufacturer part number 6WJY0. Quote it alongside SKU DELL-U2724D for asset tagging and purchase-order matching.

Documentation & Resources

• Dell UltraSharp 27 Monitor U2724D official datasheet (PDF) — full specification sheet, port list, box contents and warranty terms.
• Dell U2724D product page (210-BKSF) — manufacturer specifications, order codes and support entry point.
• Dell Support — user's guide, monitor firmware, Dell Display Manager and drivers by service tag.

More Questions About the Dell U2724D

What is the actual difference between the U2724D and the U2724DE?
The panel is the same: 27-inch IPS Black, 2560 x 1440 at 120 Hz, 2000:1 typical contrast, 350 cd/m². The U2724DE adds a Thunderbolt 4 upstream port with up to 90 W power delivery, a 2.5GbE RJ45 Ethernet port, built-in KVM, and Thunderbolt daisy-chaining. The U2724D's upstream USB-C is data only and carries no video and no laptop charging. If nobody needs single-cable laptop docking, the U2724D delivers identical image quality for less.

Does the U2724D have an Ethernet port or a built-in KVM switch?
No to both. There is no RJ45 port and no KVM function on this model. The USB hub is a straightforward peripheral hub tied to the single upstream USB-C connection, so it does not switch keyboard and mouse between two hosts. Step up to the U2724DE or U2725QE if wired networking or KVM switching is a requirement.

Do I need a specific cable to get 120 Hz?
Use the DisplayPort 1.4 cable included in the box, or a DisplayPort 1.4-rated cable, for 2560 x 1440 at 120 Hz. The HDMI input also supports QHD at 120 Hz, but you will need a high-bandwidth HDMI cable and a source capable of that timing — otherwise the display negotiates down to 60 Hz. Then set the refresh rate manually in the operating system's display settings, because many hosts default to 60 Hz on first connection.

Is IPS Black actually noticeable compared with a regular IPS monitor?
The measurable difference is contrast: 2000:1 typical here versus the roughly 1000:1 common on conventional IPS panels. In practice that shows up as deeper blacks in dark application interfaces, in letterboxed video, and in low-light conference rooms, along with less of the grey-wash look on black backgrounds. It is not OLED-level contrast, but for a color-accurate desktop panel it is a real, visible improvement rather than a marketing number.

How much power should I budget per monitor for UPS and PDU sizing?
Budget 23.9 W for typical operation and 85 W for maximum draw. Standby is 0.5 W. Size UPS and PDU capacity on the maximum figure so that a room full of displays powering on simultaneously does not trip an overload.

Can I mount two U2724D displays on one dual-monitor arm?
Yes. Each panel weighs 9.90 lb without the factory stand and uses the standard 100 x 100 mm VESA pattern, which is within the rating of essentially every commercial dual-arm and pole mount. Verify that the arm's total load rating covers both panels and that the combined 48.2" of width fits the desk before ordering.

Does the U2724D support HDR or high-refresh gaming?
There is no HDR support on this model. The 120 Hz refresh rate and 5 ms Fast-mode response are a genuine benefit for smooth motion and pointer feel, but this is a color-accurate productivity and review display, not a gaming monitor with adaptive-sync marketing. For HDR content review, look at the U2725QE with VESA DisplayHDR 600.

What is covered if a pixel fails?
Dell's Premium Panel Exchange applies for the full warranty term and covers panel replacement for even a single bright pixel, with Advanced Exchange Service shipping a replacement on a next-business-day basis under Dell's terms. That is the practical reason to specify UltraSharp over consumer panels in a fleet rollout.
