Biamp 930-10008-00006 Biamp MRB-L-X400-T-DXS5

Product Overview

The Biamp MRB-L-X400-T-DXS5 is a certified large conference room audio bundle pairing the TesiraFORTÉ X 400 meeting room DSP with a Parlé table Beamtracking microphone and Desono DX-S5 surface-mount loudspeakers. It provides the DSP, amplification, loudspeakers, and cabling to equip a large meeting room of roughly 5m x 11m for up to 18 participants. This UC-agnostic large meeting room bundle connects to a room codec over USB and supports Microsoft Teams Rooms, Zoom Rooms, Google Meet, and Cisco Webex. Surface-mount loudspeakers suit rooms where wall placement is preferred over ceiling installation.

Product Description

This bundle targets AV integrators building out large conference rooms and boardrooms that need dependable table capture and wall-mounted playback. The TesiraFORTÉ X 400 unifies audio DSP and network connectivity in one device and distributes PoE+ power to peripherals over Gigabit Ethernet. A Parlé table microphone with Beamtracking follows talkers around the table, and custom Acoustic Echo Cancellation with AI noise reduction keeps remote participants clear. Desono DX-S5 surface-mount loudspeakers are tuned for voice reproduction in commercial meeting spaces. Biamp Launch automates device discovery and tuning with no custom programming and issues a performance report at commissioning. Microphone mute buttons and LEDs stay synchronized with the UC software. Integrators preferring flush ceiling playback can review the MRB-L-X400-T-CIC6LP, and the broader Biamp collection carries matching peripherals and accessories. Support for AVB, Dante, and AES67 lets the bundle join larger networked Tesira systems.

Key Features

• TesiraFORTÉ X 400 DSP — A single meeting room DSP provides processing, networking, and PoE+ power for the entire bundle.
• Table Beamtracking microphone — A Parlé table microphone tracks active talkers with clear pickup and UC-synced mute indication.
• Desono DX-S5 loudspeakers — Surface-mount loudspeakers are tuned for voice reproduction in large conference room applications.
• Biamp Launch automated tuning — Discovery and room tuning complete without custom programming and produce a full performance report.
• Custom AEC and noise reduction — Acoustic Echo Cancellation and AI noise reduction improve the far-end experience on any UC platform.
• UC platform flexibility — A single USB connection supports Microsoft Teams Rooms, Zoom Rooms, Google Meet, and Cisco Webex.
• Networked audio support — AVB, Dante, and AES67 support enables integration into larger networked AV systems.

Typical Applications

• Boardroom
• Large conference room
• All-hands room
• Training room
• Commercial meeting space

Technical Specifications

Specifications compiled from Biamp MRB-L-X400 series and TesiraFORTÉ X 400 datasheets. Confirm detailed specifications against current Biamp documentation.

Frequently Asked Questions

Which UC platforms does it support?
Connecting to a room codec over USB, the bundle works with Microsoft Teams Rooms, Zoom Rooms, Google Meet, Cisco Webex, and GoTo Meeting.

What room size is the MRB-L-X400-T built for?
It is a large-room bundle for spaces of roughly 5m x 11m seating up to 18 participants.

What are the DX-S5 loudspeakers?
They are Desono DX-S5 surface-mount loudspeakers tuned for voice reproduction, powered by the included AMP-450BP PoE+ amplifier.

How is the system deployed?
Biamp Launch runs automated device discovery and tuning without custom programming and provides a post-commissioning performance report.

Can it integrate with a larger AV system?
Yes. The TesiraFORTÉ X 400 supports AVB, Dante, and AES67 networked audio plus SIP VoIP for larger Tesira integrations.

Is custom programming needed?
No custom programming is required for standard deployment; the DSP remains fully customizable in Tesira software.

What warranty applies?
The TesiraFORTÉ X 400 DSP is covered by Biamp's five-year warranty; verify coverage for other components with Biamp.
