Barco EM FIBER CABLE/RUGGED/MPO24 Kit (300M) - R9009010

Product Overview

Moving uncompressed video between an Event Master processor and remote displays across a large venue is a job copper cannot handle, and standard patch fiber rarely survives the rigging and foot traffic of a live show floor. The Barco EM Fiber Cable/Rugged/MPO24 Kit (300M), article number R9009010, packages a 300-meter ruggedized MPO24 fiber run with the transceivers and adapters needed to carry expansion-link signals end to end. It is built for Barco Event Master systems such as the E2, S3, and EC-210, where processor-to-screen distances exceed what HDMI or DisplayPort cabling can reach. The kit ships ready to deploy on a reel for fast load-in and tear-down.

Product Description

This complete fiber transport kit includes the cable on a reel, two MTP-to-Neutrik (opticalCON-style) adapters with jumper cables, and two 300-meter expansion-link transceivers, giving you a turnkey link between an Event Master processor frame and a remote endpoint. The ruggedized MPO24 jacket is engineered for repeated rental staging cycles, protecting the 24-fiber MPO termination against crushing, pulling, and the abrasion typical of arena and stadium deployments. The included MTP-to-opticalCON breakout adapters let crews transition from the rugged trunk to the standardized connectors used at the processor and at the screen-side electronics.

For shorter cable runs, see the 100M version of this rugged MPO24 kit. If you only need the optical modules, the matching 300m Expansion Link Fiber TX/RX Module is available separately, and panel-mount integration is handled by the 4-Port Rack Mount MTP to opticalCON Adapters. Browse the full range of compatible processing and transport gear in the Barco collection.

Key Features

• 300-meter rugged fiber run — Carries expansion-link video over a single 300m cable for long processor-to-screen distances.
• MPO24 termination — Uses a 24-fiber MPO interface for high-density optical transport in a single connector.
• Ruggedized jacket — Heavy-duty construction stands up to repeated rental staging load-in and tear-down cycles.
• Cable on reel — Reel packaging speeds deployment and retrieval and reduces tangling on site.
• MTP-to-opticalCON adapters included — Two adapters with jumper cables transition the rugged trunk to standardized connectors.
• Two transceivers included — Matched 300m optical modules complete the link at both ends.
• Event Master compatibility — Designed for Barco E2, S3, and EC-210 processing platforms.

Typical Applications

• Large-event and rental staging — Long fiber runs between an Event Master processor and stage or screen positions.
• Arena and stadium video — Reaching scoreboards and ribbon displays far from the control position.
• Corporate general sessions — Transporting processed content across large ballrooms and convention halls.
• Broadcast and multi-camera productions — Routing high-bandwidth video over distances copper cannot support.

Technical Specifications

Frequently Asked Questions

Which Barco systems does this kit work with? It is designed for the Barco Event Master ecosystem, including the E2, S3, and EC-210 processors, for expansion-link fiber transport.

What is included in the kit? The cable on a reel, two MTP-to-opticalCON-style adapters with jumper cables, and two 300-meter transceivers.

What connector does the cable use? A ruggedized MPO24 (24-fiber) termination, with the included adapters breaking out to standard connectors at each end.

Is there a shorter version available? Yes, the same kit is offered in a 100-meter configuration (R9008989) for shorter cable runs.
