Barco 300m Expansion link fiber TX/RX Module - R9009202

Product Overview

A fiber cable alone cannot move Event Master video; the optical modules at each end convert the electrical expansion-link signal to light and back. The Barco 300m Expansion Link Fiber TX/RX Module, article number R9009202, is the transceiver pair (two per kit) required to run Barco 300-meter fiber cables between an Event Master processor and a remote display. It serves Barco Event Master systems such as the E2, S3, and EC-210 for long-distance signal transport. This product supplies the transmit and receive electronics that terminate the optical link at both ends.

Product Description

This module kit contains two transceivers and is the required optical interface for Barco 300m expansion-link fiber cables. One module sits at the processor end and the other at the screen-side electronics, converting between the expansion-link electrical signal and the optical signal carried over the 300m fiber run. The kit is the matching companion to cable-only products and is the part to order when building or repairing a fiber link from individual components rather than buying a fully bundled kit.

Pair these modules with a 300m fiber cable such as the 300M Install Fiber Cable or the rugged 300M Rugged MPO24 Kit, and use the 4-Port Rack Mount MTP to opticalCON Adapters for panel integration. Browse the full range of Barco fiber transport gear in the Barco collection.

Key Features

• 300m transceiver pair — Two modules per kit terminate the optical link at both ends.
• Required for 300m cables — The mandatory optical interface for Barco 300-meter expansion-link fiber.
• Expansion-link conversion — Converts the Event Master electrical signal to light and back.
• Component-level build — The right part for assembling or repairing a link from individual pieces.
• Event Master compatibility — Designed for Barco E2, S3, and EC-210 processing platforms.
• Matched pair — Transmit and receive modules supplied together for a complete link.

Typical Applications

• Large-event and rental staging — Completing a 300m fiber link in a touring inventory.
• Fixed install with long cable runs — Terminating permanent 300m fiber paths.
• Arena and stadium video — Driving displays positioned far from the control area.
• Broadcast and multi-camera productions — Optical termination for high-bandwidth video transport.

Technical Specifications

Frequently Asked Questions

What does this module do? It converts the Event Master expansion-link electrical signal to and from light so video can travel over fiber; two modules terminate the link at each end.

Is this a cable? No. It is the transceiver pair (2 per kit) required to operate Barco 300m expansion-link fiber cables, which are sold separately.

Which cables does it support? Barco 300-meter expansion-link fiber cables, including the install and rugged MPO24 versions.

Which Barco systems work with it? The Barco Event Master ecosystem, including the E2, S3, and EC-210 processors.
