Avocor AVH-8620 – 86" 4K Interactive Touchscreen Display

The Avocor AVH-8620 brings 86 inches of 4K interactive canvas to large conference rooms and all-hands spaces where every seat needs to read the content and any participant may step up to annotate.

Product Overview

The AVH-8620 is an 86-inch 4K interactive touchscreen display from Avocor's H Series, designed as the front-of-room collaboration surface for large commercial meeting spaces. Its direct-lit LED panel delivers 3840 x 2160 resolution at 60Hz with 400 cd/m² brightness through optically bonded glass, while PCAP touch supports up to 40 simultaneous touch points plus a stylus. For AV integrators specifying a large format interactive display for boardrooms, training rooms, and hybrid meeting rooms, the AVH-8620 combines panel size, touch performance, and connectivity in a single commercial-grade unit.

Product Description

At 86 inches, this display suits rooms seating roughly 10 to 20 people, where smaller panels leave back-row participants squinting at spreadsheets. Connectivity is built for AV system integration: four HDMI 2.0 inputs with HDCP 2.3, DisplayPort 1.4, HDMI out for confidence monitoring or overflow displays, and a USB-C port with 100W power delivery so a presenter can connect video, touch, and laptop charging over one cable. The OPS slot accepts a slide-in PC for Microsoft Teams Rooms, Zoom Rooms, or digital signage playback without external boxes. A 24 GHz radar presence sensor wakes the display automatically, and dual LAN plus RS-232 connect it to room control systems. Included software covers the full meeting workflow — DisplayNote Montage for wireless screen sharing, Lucidspark whiteboarding, Rise Vision digital signage, the UiQ tile-based launcher, and Avocor FUSE for remote fleet management.

Need a TAA-compliant version for government procurement? See the Avocor AVH-862GV. For mid-sized rooms, the 75-inch Avocor AVH-7520 offers the same feature set in a smaller footprint. Explore the complete Avocor collection.

Key Features

• 86-Inch 4K UHD Display — The 3840 x 2160 direct-lit LED panel keeps fine detail readable across large conference rooms and all-hands spaces.
• 40-Point Touch with Stylus — PCAP touch supports up to 40 simultaneous points so multiple participants can write, sketch, and move content at the same time.
• Optically Bonded Anti-Glare Glass — Zero-parallax 2mm bonded glass with anti-glare and anti-fingerprint coatings makes writing feel precise and keeps the screen clean-looking through back-to-back meetings.
• Single-Cable USB-C Connection — The Type-C port delivers 100W of laptop charging while carrying video and touch, ideal for BYOD meeting rooms.
• Extensive Video I/O — Four HDMI 2.0 inputs, DisplayPort 1.4, and HDMI 2.0 out give integrators flexibility for room PCs, codecs, and overflow displays.
• OPS Slot for Embedded Compute — Slide in an OPS PC to run UC platforms or signage without external players or cabling.
• Presence and Light Sensors — A 24 GHz radar presence detector and ambient light sensor automate wake-up and picture settings as people enter the room.
• Built-In Spatial Stereo Audio — Two 16W downward-facing speakers handle program audio and far-end voice in standard meeting rooms.
• Cloud Fleet Management — Avocor FUSE lets IT remotely monitor, configure, and update every display in the building from one dashboard.

Typical Applications

• Boardroom
• Conference room
• All-hands room
• Training room
• Commercial meeting space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

What room size suits an 86-inch interactive display?

The AVH-8620 is sized for large conference rooms, boardrooms, and training rooms — typically spaces seating 10 to 20 people. For rooms of 6 to 12, the 75-inch AVH-7520 is usually the better fit.

Can I run Microsoft Teams Rooms or Zoom Rooms on it?

Yes. Connect a Teams Rooms or Zoom Rooms compute via HDMI/USB-B or install an OPS PC directly in the display's slot. Touch passes back to the room system, so participants can annotate shared content during calls.

Does touch work with Mac and Windows laptops?

Yes. The display supports up to 40-point touch on Windows 8/10 and works with Mac OSX; Linux supports single touch. USB-B and USB-C connections both carry touch data.

How is the display installed?

An 800 x 600mm VESA wall mount is included. The panel weighs 61 kg (134.5 lbs), so plan a two- or three-person lift and confirm wall structure. Mobile stands with compatible VESA patterns are an alternative for multi-purpose rooms.

Can IT manage multiple displays remotely?

Yes. Avocor FUSE cloud management provides remote monitoring, configuration, and firmware updates across the fleet, while RS-232 and dual LAN support control system integration in each room.

Is there a TAA-compliant version for government buyers?

Yes — the AVH-862GV carries the same specifications with TAA-compliant sourcing for federal and GSA procurement.

What warranty applies?

The AVH-8620 is covered by Avocor's global commercial warranty, and Creation Networks supports system design, deployment, and after-sale service for commercial installations.
