Avocor AVH-7520 – 75" 4K Interactive Touchscreen Display

The Avocor AVH-7520 is the 75-inch workhorse of the H Series — the size most integrators specify when standardizing interactive displays across a building full of mid-size meeting rooms.

Product Overview

The AVH-7520 is a 75-inch 4K interactive touchscreen built for the conference rooms and huddle-adjacent spaces where most day-to-day collaboration happens. Its direct-lit LED panel delivers 3840 x 2160 resolution with a quick 6.5ms response time, and PCAP touch supports up to 40 points plus a stylus through zero-parallax bonded glass. For organizations rolling out a commercial interactive display standard across multiple rooms, the AVH-7520 balances screen size, installed weight, and connectivity at a practical price point.

Product Description

This 75-inch meeting room display is sized for rooms seating roughly 6 to 12 people — close enough that annotation feels natural, large enough that shared spreadsheets and drawings stay legible. The connectivity panel reads like an integrator's wish list: four HDMI 2.0 inputs with HDCP 2.3, DisplayPort 1.4, HDMI 2.0 out for a repeater display, USB-C with 100W power delivery for one-cable laptop docking, three USB-B touch ports, and an OPS slot for an embedded room PC. Dual gigabit-class LAN ports and RS-232 connect to room control and scheduling systems. The included software stack — DisplayNote Montage wireless sharing, Lucidspark whiteboarding, UiQ launcher, Rise Vision signage, and FUSE cloud device management — means a room can be productive on day one without additional licensing.

Outfitting a larger boardroom or all-hands space? Step up to the 86-inch Avocor AVH-8620. Government buyers with Trade Agreements Act requirements should specify the TAA-compliant AVH-752GV. Compare every model in the Avocor collection.

Key Features

• 75-Inch 4K UHD Panel — The 3840 x 2160 direct-lit LED display keeps documents, dashboards, and far-end video sharp for everyone in a mid-size meeting room.
• 6.5ms Response Time — Quick panel response keeps pen strokes and touch gestures fluid during fast whiteboarding sessions.
• 40-Point PCAP Touch with Stylus — Multiple participants can annotate, drag, and write simultaneously, with two soft-tip styluses included.
• Zero-Parallax Bonded Glass — 2mm optically bonded glass with anti-glare and anti-fingerprint coating puts the ink exactly where the pen touches.
• One-Cable USB-C Docking — The Type-C port supplies 100W power delivery while carrying video and touch, so presenters connect with a single cable.
• Four HDMI Inputs Plus DisplayPort — Abundant video inputs handle room PCs, UC codecs, wireless presentation gateways, and guest laptops without an external switcher in many designs.
• OPS Slot for Embedded Compute — Slide in an OPS PC for Microsoft Teams Rooms, Zoom Rooms, or digital signage playback with no visible electronics.
• Radar Presence Detection — A 24 GHz presence sensor wakes the display when people enter and supports energy-saving standby policies.
• FUSE Cloud Management — IT can monitor and update an entire fleet of H Series displays remotely, cutting room-by-room support visits.

Typical Applications

• Conference room
• Huddle room
• Training room
• Boardroom
• Commercial meeting space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Is 75 inches the right size for my room?

For conference rooms seating 6 to 12 people with viewers up to about 20 feet away, 75 inches is the most commonly deployed interactive display size. Larger boardrooms and all-hands rooms are better served by the 86-inch AVH-8620.

How do I connect a laptop with touch?

Use the USB-C port for video, touch, and up to 100W charging over one cable, or pair any HDMI/DisplayPort input with a USB-B touch cable. Both methods support 40-point touch on Windows.

Can it run a Microsoft Teams Rooms or Zoom Rooms system?

Yes. Connect a certified room compute over HDMI and USB-B, or install an OPS PC in the display's slot. The touch surface then works for in-meeting annotation and whiteboard apps.

What software is included?

DisplayNote Montage wireless screen sharing, Lucidspark whiteboarding, the UiQ tile-based launcher, Rise Vision digital signage, and Avocor FUSE cloud device management ship with the display at no extra licensing cost.

What mounting hardware do I need?

An 800 x 400mm VESA wall mount is included. The display weighs 48 kg (105.8 lbs), so verify wall structure and use a two-person crew; mobile stands are an option for shared or multi-purpose rooms.

Is there a government procurement version?

Yes. The AVH-752GV is the TAA-compliant 75-inch model for federal and GSA purchases, at the same price and specifications.

What warranty and support apply?

The AVH-7520 carries Avocor's global commercial warranty, and Creation Networks provides design consultation, deployment support, and after-sale service for commercial AV projects.
