Avocor AVX-1320 – 132" dvLED with Stand and ATA Case

This is the complete portable configuration of the Avocor AVX-1320: the 132-inch direct view LED (dvLED) display, the Avocor mobile stand, and a rolling ATA shipping case — everything needed to deploy, relocate, and transport a full-scale LED video wall.

Product Overview

The Avocor AVX-1320 with mobile stand and ATA case is a turnkey portable dvLED video wall package for rental and staging operations, executive briefing programs, and enterprises that run a single premium display across multiple venues. The 132" 21:9 ultra-wide LED display delivers 2400 x 1080 resolution at a 1.27mm pixel pitch, the stand makes it freestanding anywhere with power, and the air-transport-association rated case protects the cabinets between sites. It is the most flexible commercial deployment option in the AVX-1320 lineup — no wall construction at any destination, and no custom crating between them.

Product Description

The display is Avocor's all-in-one tiled X Series architecture: 20 die-cast magnesium cabinets in a 5 x 4 array with a built-in processor, forming a single 3064 x 1489 x 31mm screen at 108 kg (238 lbs). Rolled into a room on the mobile stand, the freestanding dvLED video wall is presentation-ready without rigging or wall reinforcement; packed into the rolling ATA road case, it travels by truck or air freight to the next venue with the LED modules protected. Image quality holds commercial standards wherever it lands — up to 500 cd/m² calibrated brightness, 98% uniformity, 6500:1 contrast, and a 3,840 Hz refresh rate with 16-bit processing that stays flicker-free on broadcast and conference cameras. Connectivity is identical to the fixed-install model: three HDMI 2.0 inputs with HDCP 2.2, front USB-C and USB-A ports, optical SPDIF out, and RS-232 plus LAN for AV system integration and show control. Built-in WiFi, DisplayNote Montage wireless sharing, Rise Vision digital signage, and Avocor FUSE cloud management let one team operate the display across every site it visits. Front service access and the included spare LED modules make on-site repair practical mid-event, which is exactly what a touring LED wall requires.

Key Features

• Complete Portable Kit — Display, mobile stand, and rolling ATA case in one purchase cover deployment, relocation, and protected transport end to end.
• Stand-Based Setup at Any Venue — The mobile stand makes the 132" wall freestanding, so no destination needs wall reinforcement, rigging, or construction work.
• ATA-Rated Transport Protection — The rolling air-transport-association case shields the die-cast magnesium cabinets and LED modules during repeated road and freight moves.
• 21:9 Ultra-Wide Resolution — The 2400 x 1080 canvas supports Microsoft Teams Front Row, multi-source event layouts, and widescreen presentation graphics.
• 1.27mm Fine Pixel Pitch — Single SMD pixels deliver sharp detail at viewing distances beyond 2.5 meters for seated audiences in briefing and event rooms.
• Built-In Processing — The all-in-one tiled design with internal processor removes external controllers from the road kit, cutting setup time and failure points.
• Mid-Event Serviceability — Front service access plus included spare LED modules and removal tool allow module swaps on site without striking the wall.
• Fleet-Ready Management — RS-232, LAN (RJ45), and Avocor FUSE cloud management let AV teams monitor and control the display remotely across venues.
• Integrated Audio and Sharing — Two 30W forward-facing speakers, optical SPDIF out, and DisplayNote Montage wireless sharing reduce the supporting equipment each deployment needs.

Typical Applications

• Multi-purpose rooms and venues hosting rotating events
• All-hands rooms shared across a multi-building campus
• Broadcast studios and temporary production stages
• Auditorium and house of worship productions that tour or reconfigure seasonally
• Training rooms delivered at rotating client or branch sites
• Government spaces and briefing centers requiring relocatable display infrastructure

Technical Specifications

Frequently Asked Questions

Who is the stand-plus-case configuration designed for?

Organizations that deploy one premium LED wall in more than one place: rental and staging companies, event producers, multi-campus enterprises, and executive briefing programs. The stand handles in-room mobility; the ATA case handles between-site transport.

Can the display still be wall-mounted at a permanent destination?

Yes. The vendor supports both stand and wall installation, and a wall mount ships in the box, so the same display can finish its life in a fixed boardroom installation.

Is the display compatible with Microsoft Teams Front Row and video conferencing?

Yes. The 21:9 2400 x 1080 resolution matches the Teams Front Row layout; connect a certified Teams Rooms compute device or conferencing codec through HDMI 2.0 (HDCP 2.2).

What does setup at a new venue involve?

The all-in-one tiled design with a built-in processor means no external video wall controller or pixel mapping at each stop. Crews position the stand, connect power (AC 100–240V) and sources, and the display is operational — far faster than component LED walls.

How are repairs handled on the road?

Service access is from the front, and spare LED modules plus a removal tool ship with the display, so a technician can replace a damaged module at the venue without specialized rear access.

What lighter-commitment configurations exist?

Creation Networks also offers the AVX-1320 display only, the AVX-1320 with ATA case, and the AVX-1320 with mobile stand. For 16:9 rooms, consider the Avocor AVX-1380 138", or browse the Avocor collection.

Does Creation Networks support warranty and deployment planning?

Yes. Our team provides pre-sales system design, logistics and site planning for transportable dvLED deployments, and manufacturer-backed warranty support throughout the life of the display.
