ZeeVee ZyPer4K-XR HDMI 2.0 Output Decoder, Accepts IP Streaming via 10Gbit/Copper, PoE - Z4KDECC3XR

Product Overview

The ZeeVee ZyPer4K-XR HDMI 2.0 Copper Decoder (Z4KDECC3XR) is a compact, fanless AV-over-IP decoder that receives uncompressed 4KP60 4:4:4 video over 10Gbit Cat6a infrastructure and outputs via HDMI 2.0. PoE-powered from the network switch, it requires no local power supply, making it an efficient endpoint for commercial AV-over-IP distribution systems. As a rugged AV-over-IP decoder for government and enterprise deployments, it operates silently and reliably in noise-sensitive environments. The Z4KDECC3XR is fully compatible with ZyPer4K and ZyPer4K-XS ecosystems for scalable system design.

Product Description

The Z4KDECC3XR decodes uncompressed 4KP60 4:4:4 video received over a 10Gbit IP network and delivers it through an HDMI 2.0 output to any compatible display or sink device. Cat6a cabling up to 100 meters connects the decoder to the network switch, while PoE eliminates the need for local AC power at the display endpoint. The fanless form factor is particularly valuable in boardrooms, courtrooms, control rooms, and government facilities where audible fan noise is unacceptable. HDCP 2.2 and AES-128 encryption support secure content delivery, including protected source material and classified environments. Analog stereo audio is available via 3.5mm for flexible audio routing. USB extension support enables KVM-over-IP configurations when paired with ZyPer4K-XS or other XR devices. Management is centralized through ZeeVee's ZyPer Management Platform. The unit carries a 3-year warranty.

Key Features

• Uncompressed 4KP60 4:4:4 Output — Delivers full-bandwidth 4K to connected displays with no perceptible latency.
• PoE Powered (10GBase-T) — Powered directly from the switch over Cat6a, eliminating endpoint power wiring.
• Fanless Compact Design — Silent operation with no moving parts for noise-sensitive installations.
• HDMI 2.0 Output — Connects directly to 4K displays, projectors, or video walls.
• HDCP 2.2 + AES-128 — Secure content delivery for protected and sensitive distribution environments.
• 3.5mm Analog Audio Output — Unbalanced stereo audio breakout for local audio routing.
• USB Extension Support — Supports KVM workflows when paired with compatible ZyPer XS/XR devices.
• ZyPer4K / ZyPer4K-XS Compatible — Integrates into existing ZyPer4K infrastructure.

Typical Applications

• Government and military operations centers
• Corporate boardrooms and conference centers
• Control rooms and NOC/SOC environments
• University digital signage and AV distribution
• Healthcare facility display endpoints
• Courtroom and judicial AV systems

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does the Z4KDECC3XR require a dedicated power supply at the display location?

No. The decoder is PoE-powered over the Cat6a network cable, requiring only a PoE-capable 10GBase-T switch port at the infrastructure level.

What is the maximum cable distance from switch to decoder?

Cat6a up to 100 meters (approximately 328 feet) between the network switch and the decoder endpoint.

Can the Z4KDECC3XR receive video from ZyPer4K encoders (non-XR)?

Yes. The XR decoder is backward compatible with ZyPer4K and ZyPer4K-XS encoders within the same managed network.

Is this decoder suitable for video wall applications?

Yes. Multiple decoders can be deployed and managed through the ZyPer Management Platform for video wall and multi-display configurations.

Does the decoder support audio extraction?

Yes. Unbalanced stereo analog audio is available via the 3.5mm connector alongside the HDMI output.
