ZeeVee ZV739-3E-X20 Hydra 3-foot AV Cable; Satellite DIN connector - qty 20 Pack

Product Overview

The ZeeVee ZV739-3E-X20 is a 20-pack of 3-foot satellite DIN AV cables for connecting DirecTV H25 receivers to ZeeVee encoders in commercial IPTV headend installations. Each cable features a full-size DIN connector at the encoder end and a mini-DIN connector compatible with the DirecTV H25's output port, enabling component video and analog audio to be passed from the satellite receiver into the ZeeVee encoding chain. This bulk pack is designed for hospitality and multi-tenant facility deployments where large numbers of DirecTV H25 receivers feed a ZeeVee headend system.

Product Description

The ZV739-3E-X20 provides 20 units of ZeeVee's proprietary satellite Hydra cable in the 3-foot length, suited to large DirecTV H25-based ZeeVee IPTV headend builds in hotels, hospitals, and multi-tenant commercial facilities. The mini-DIN end connects to the DirecTV H25 receiver's output port for component video and analog audio. The full-size DIN end connects to compatible ZeeVee encoder input ports. The 3-foot length is designed for rack installations where the H25 receiver is co-located with or immediately adjacent to the ZeeVee encoder. Ordering as a 20-pack reduces per-cable procurement cost and simplifies sourcing for large system builds where cable quantities align with receiver counts.

Key Features

• 20-Pack — Cost-effective procurement for bulk DirecTV H25 to ZeeVee encoder installations.
• DirecTV H25 Compatible — Mini-DIN end matches the DirecTV H25 receiver output connector for component video and analog audio.
• 3-Foot Length — Designed for rack-adjacent H25 receiver to encoder connections.
• ZeeVee Encoder Compatible — Full-size DIN connects to ZeeVee encoder input ports in supported headend systems.

Typical Applications

• Hospitality IPTV headend installations using DirecTV H25 receivers with ZeeVee encoders
• Multi-tenant facility ZeeVee headend builds with large H25 receiver banks
• Healthcare and senior living facility ZeeVee IPTV systems with DirecTV H25 sources

Technical Specifications

Frequently Asked Questions

Are these cables compatible with DirecTV receivers other than the H25?

The ZV739-3E-X20 is specified for the DirecTV H25 receiver. Other DirecTV models may use different output connector formats. Verify connector compatibility before ordering for non-H25 receivers.

Are there standard off-the-shelf cables that can substitute for the ZV739-3E-X20?

No. The ZeeVee encoder DIN input and the DirecTV H25 output connector combination is a proprietary interface that requires ZeeVee's Hydra satellite cable. Standard mini-DIN or component video cables are not compatible with this connection configuration.

When should I use the 3-foot versus the 6-foot version?

Use the 3-foot ZV739-3E-X20 when the DirecTV H25 receiver is co-located in the same rack bay or immediately adjacent to the ZeeVee encoder. For receivers mounted further away, use the 6-foot ZV739-6-X20.

Does the 20-pack provide a cost advantage over individual cable purchases?

Yes. The 20-pack pricing provides a reduced per-cable cost compared to ordering individual ZV739-3E cables, making it the appropriate procurement option for deployments requiring 10 or more cables.

Is this cable applicable to ZyPer4K-based headend systems?

These Hydra satellite cables are designed for HDbridge and ZvPRO encoder platforms. ZyPer4K encoders use HDMI 2.0 inputs and do not use the DIN connector format. This cable is not applicable to ZyPer4K systems.
