ZeeVee Z4KENCFLXR 4K-XR HDMI 2.0 Encoder

Product Overview

The ZeeVee ZyPer4K-XR HDMI 2.0 Fiber Encoder (Z4KENCFLXR) is a compact, fanless AV-over-IP encoder that accepts HDMI 2.0 input and transmits uncompressed 4KP60 4:4:4 video over a 10Gbit 1300nm single-mode fiber network. Single-mode fiber support makes this encoder the correct choice for long-distance inter-building AV distribution where multimode fiber reach is insufficient. Compatible with ZyPer4K and ZyPer4K-XS, it extends the ZyPer ecosystem across campus-scale or wide-area fiber plant deployments.

Product Description

The Z4KENCFLXR accepts HDMI 2.0 sources and encodes them to uncompressed 4KP60 4:4:4 IP video for long-distance distribution over 1300nm single-mode fiber at 10Gbit speeds. Single-mode fiber enables significantly greater transmission distances than multimode, making this encoder appropriate for inter-building, campus-wide, or large-facility deployments where the fiber plant uses single-mode cable. The fanless, compact form factor ensures silent operation without moving parts, appropriate for wiring closets, rack rooms, and noise-sensitive production environments. HDCP 2.2 and AES-128 encryption protect content in transit. Unbalanced stereo audio is available via 3.5mm. USB extension is supported between ZyPer4K-XS and XR devices for KVM-over-IP deployments. The ZyPer Management Platform provides centralized system management. The unit carries a 3-year warranty.

Key Features

• 1300nm Single-Mode Fiber Interface — Supports long-distance inter-building and campus-scale AV-over-IP distribution.
• Uncompressed 4KP60 4:4:4 Encoding — Full-bandwidth 4K with no perceptible latency over IP.
• Fanless Compact Design — Silent, maintenance-free operation for noise-sensitive and space-constrained installations.
• HDMI 2.0 Input — Accepts 4K sources at full 4KP60 resolution.
• HDCP 2.2 + AES-128 — Dual-layer security for protected content and encrypted IP transmission.
• 3.5mm Analog Audio — Unbalanced stereo audio output alongside HDMI.
• USB Extension Support — KVM-capable when paired with ZyPer XS/XR devices.
• ZyPer4K / ZyPer4K-XS Compatible — Extends existing ZyPer4K systems over single-mode fiber.

Typical Applications

• Campus-wide AV-over-IP distribution over single-mode fiber infrastructure
• Inter-building 4K video extension in enterprise and government campuses
• Large-venue production environments with existing single-mode fiber plant
• Long-distance broadcast monitoring and signal distribution
• Hybrid copper/fiber ZyPer4K systems requiring extended reach

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the advantage of single-mode fiber over multimode for AV distribution?

Single-mode fiber supports significantly longer transmission distances than multimode, making it the correct choice for inter-building, campus-wide, or large-venue deployments where multimode reach (typically limited to a few hundred meters) is insufficient.

What fiber cable and connectors are required?

The Z4KENCFLXR uses a 1300nm single-mode fiber interface. Standard OS1 or OS2 single-mode fiber with appropriate connectors compatible with the switch SFP+ transceivers is required. Consult ZeeVee deployment documentation for validated configurations.

Does this encoder support PoE?

No. Fiber XR models do not support PoE. A separate power source is required at the encoder installation point.

Can the Z4KENCFLXR coexist with copper ZyPer4K endpoints on the same system?

Yes. ZyPer4K systems support mixed fiber and copper endpoints managed through a single ZyPer Management Platform instance.

Is HDCP 2.2 content supported over single-mode fiber?

Yes. The Z4KENCFLXR supports HDCP 2.2 content protection regardless of the fiber interface type.
