Yamaha ADECIA Tabletop Microphone and Network Switch Bundle – AD-1TT

Product Overview

The Yamaha ADECIA Tabletop Microphone and Network Switch Bundle pairs one RM-TT wired tabletop microphone pod with the SWR-2100-5G network switch, providing the core network and microphone infrastructure for an ADECIA wired tabletop deployment. This bundle is designed for AV integrators who already own or plan to procure the RM-CR Remote Conference Processor separately, offering a focused entry point into the ADECIA wired tabletop ecosystem. Available in white or black to match table and ceiling aesthetics, the bundle ships with the switch and pod verified for compatibility. Additional RM-TT pods can be added to expand coverage up to the RM-CR’s maximum of 14 pods (or 16 without VXL1-16P).

Product Description

The RM-TT pod in this bundle measures W140 × D140 × H41.5 mm and weighs 310g, sitting low-profile on the conference table. A single Cat 5e+ STP cable connects the pod to the SWR-2100-5G switch, delivering Dante audio (1 in / 2 out at 48kHz/24-bit), control signals, and IEEE 802.3af PoE power (4.5W max) on one run. Standard latency is 46ms, with a 20ms low-latency Dante mode available for demanding applications.

The RM-TT supports six selectable polar patterns — Cardioid, Hyper-cardioid, Super-cardioid, Omnidirectional, Bidirectional, and Toroid — configurable through ADECIA management software. Onboard processing includes Auto Voice Tracking, AEC, Noise Reduction, Dereverberation, Auto Mixer, AGC, PEQ, and Output Gain, operating without external DSP. The SWR-2100-5G switch powers the pod and provides the network infrastructure to connect additional pods and the RM-CR processor as the system grows. This bundle does not include the RM-CR processor; integrators should specify the processor separately or select a complete ADECIA system bundle at creationnetworks.net.

The bundle is available in white or black. Status, mute, and network port indicators are integrated into each RM-TT pod. The pod ships with a tabletop mounting adapter, screws, spacers, and installation manual. For complete ADECIA tabletop solutions with processor included, and for ceiling-based ADECIA bundles, visit creationnetworks.net.

Key Features

• Starter Bundle for ADECIA Integrators — RM-TT pod and SWR-2100-5G switch in one SKU; add the RM-CR processor separately to complete the system.
• Single-Cable PoE per Pod — Dante audio, control, and power over one Cat 5e+ STP cable; no table power outlets required.
• Six Selectable Polar Patterns — Cardioid, Hyper-cardioid, Super-cardioid, Omnidirectional, Bidirectional, and Toroid selectable per pod via software.
• Auto Voice Tracking — Active speaker tracking without manual beam adjustment or operator intervention.
• Integrated Signal Processing — AEC, Noise Reduction, Dereverberation, Auto Mixer, AGC, PEQ, and Output Gain onboard the RM-TT pod.
• Native Dante Transport — 48kHz/24-bit Dante with 1 in / 2 out integrates with existing Dante-enabled AV infrastructure.
• Expandable Architecture — Add RM-TT pods to the same SWR switch and RM-CR processor to cover larger tables, up to 14 pods per processor.
• Available in White or Black — Match table and interior finishes across commercial environments.
• Low-Latency Dante Mode — 20ms latency option for applications where end-to-end audio delay is a critical specification.
• Accessories Included — Tabletop mounting adapter, screws, spacers, and installation manual ship with the pod.

Typical Applications

• Small to medium conference rooms where the integrator supplies the RM-CR processor separately
• Phased ADECIA deployments adding microphone infrastructure before processor procurement
• System expansions adding a switch and initial pod to an existing ADECIA installation
• Corporate huddle rooms and small boardrooms
• Government and higher education meeting rooms
• Healthcare and professional services conference facilities
• AV-over-IP Dante projects requiring modular component procurement

Technical Specifications

Frequently Asked Questions

Does this bundle include the RM-CR Remote Conference Processor?

No. This bundle includes the RM-TT wired tabletop microphone pod and the SWR-2100-5G network switch only. The RM-CR Remote Conference Processor is required to complete the ADECIA system and must be purchased separately. For complete bundles including the RM-CR, see the full ADECIA Wired Tabletop Solution at creationnetworks.net.

Why would an integrator choose this bundle over the complete system?

This bundle suits integrators who already own an RM-CR from a previous deployment, who are phasing procurement across project milestones, or who need to add switch and pod infrastructure before the processor is specified. It also allows procurement teams to source the processor and microphone infrastructure on separate purchase orders.

How many additional RM-TT pods can be added to this system?

The SWR-2100-5G switch and a single RM-CR processor support up to 14 RM-TT pods (or 16 without VXL1-16P). This bundle starts with one pod; additional RM-TT units can be added to the same switch and processor as the installation grows.

What cabling is required per pod?

Each RM-TT pod requires one Cat 5e or better shielded twisted pair (STP) cable run from the pod to the SWR-2100-5G switch. This cable carries Dante audio, control, and PoE power simultaneously. No power outlet at the table is needed.

Is this bundle available in both white and black?

Yes. The bundle is available in white (RM-TT-W) or black (RM-TT-B) finish. All specifications are identical; the finish choice should match the conference table and room interior.

Which UC platforms are compatible with the RM-TT when paired with an RM-CR?

When paired with the RM-CR processor, the system supports Windows, macOS, iOS, and Android via USB, Bluetooth, or analog audio I/O, covering Microsoft Teams, Zoom, Cisco Webex, and other major UC platforms.

Can the polar pattern be changed after the pod is installed?

Yes. The six polar patterns (Cardioid, Hyper-cardioid, Super-cardioid, Omnidirectional, Bidirectional, Toroid) are configured through ADECIA management software and can be updated at any time without physical access to the pod.
