Sonance VX62R TL – Round Thin-Line In-Ceiling Speaker
Product Overview
The Sonance VX62R TL is a round thin-line in-ceiling speaker from the Visual Experience Series, built for integrators who want a low-profile ceiling speaker with a discreet, minimal-bezel grille appearance. It is a strong fit for whole-home audio zones where ceiling clearance is limited.
Product Description
The VX62R TL pairs a 6.5" textured polypropylene woofer with a Ferrofluid-cooled 1.0" cloth dome tweeter, tuned through Sonance's CDX crossover for consistent tonal balance across the volume range. A sinusoidal textured waveguide widens tweeter dispersion for even coverage, and the thin-line chassis mounts in 2.91" of depth, shallower than a standard-depth in-ceiling speaker. The speaker supports a two-stage installation process, letting crews rough in the bracket and wiring before drywall or ceiling material is finished, with the driver and grille completed later during trim-out. Multiple grille finishes are available, including TRUFIG-mounted trimless styles, with custom painting or laser printing offered to match ceiling finishes. Integrators building a whole-home Sonance system can browse the complete in-ceiling speakers lineup to match the VX62R TL with companion models for other rooms.
Key Features
- 6.5" Textured Polypropylene Woofer — Paired with a Ferrofluid-cooled cloth dome tweeter for balanced full-range output.
- Sinusoidal Textured Waveguide — Widens dispersion for even coverage across the listening area.
- Thin-Line 2.91" Mounting Depth — Fits shallower ceiling cavities than a standard-depth in-ceiling speaker.
- Sonance CDX Crossover — Preserves tonal balance from quiet background levels to louder listening.
- Two-Stage Installation — Allows preconstruction wiring and bracket placement ahead of finish work.
- Multiple Grille Options — Micro Trim, trimless, and TRUFIG-mounted grille finishes are available.
Typical Applications
Whole-home audio zones, kitchens, bathrooms, and living areas where a low-profile, discreet ceiling speaker is preferred.
Technical Specifications
| Tweeter | 1.0" (25mm) cloth dome, Ferrofluid-cooled |
| Woofer | 6.5" (165mm) textured polypropylene cone, rubber surround |
| Frequency Response | 45Hz – 20kHz (±3dB) |
| Sensitivity | 89dB (2.83V/1m) |
| Power Handling | 5W minimum; 125W maximum (RMS) |
| Cutout Diameter | 8.25" (209.55mm) |
| Mounting Depth | 2.91" (73.91mm) |
| Dispersion | Sinusoidal Textured Waveguide |
| Finish | Brilliant White (Satin) |
Frequently Asked Questions
What is the mounting depth of the VX62R TL?
It requires 2.91" (73.91mm) of mounting depth, shallower than a standard-depth in-ceiling speaker.
What cutout size does it require?
The cutout diameter is 8.25" (209.55mm).
What is the power handling rating?
The VX62R TL is rated for 5 watts minimum and 125 watts maximum RMS.
Can the VX62R TL be installed before the ceiling is finished?
Yes, its two-stage installation design allows the bracket and wiring to be set before finish work, with the speaker and grille added later.
What grille styles are available?
Micro Trim, trimless, and TRUFIG-mounted grille options are available.
What is the frequency response?
Sonance rates the VX62R TL at 45Hz to 20kHz, ±3dB.
