Sonance VX66 TL – Thin-Line Rectangle In-Wall Speaker

Product Overview

The Sonance VX66 TL is a thin-line rectangular in-wall speaker from the Visual Experience Series, built for installers who need the VX66's driver performance in a shallower wall cavity than the standard-depth VX66 model requires.

Product Description

The VX66 TL pairs a 6.5" Kevlar/Nomex woofer with a Ferrofluid-cooled 1.0" ceramic dome tweeter, the same driver combination used in the standard VX66, but housed in a thinner chassis that mounts in 2.53" of depth. This makes it a practical option for exterior walls, thin partition walls, or framing with limited stud depth where the standard VX66 would not fit. Sonance's CDX crossover keeps tonal balance consistent across the volume range, and Micro Trim, trimless, or TRUFIG-mounted grille finishes are available in Brilliant White satin, with custom paint or laser-printed options offered for architectural matching. Integrators completing a Sonance Visual Experience system can pair the VX66 TL with matching in-ceiling speakers for rooms where a ceiling location is preferred instead, keeping tonal character consistent throughout the home.

Key Features

• 6.5" Kevlar/Nomex Woofer — Delivers the same driver performance as the standard VX66 in a thinner chassis.
• Ferrofluid-Cooled Ceramic Tweeter — Provides stable high-frequency output at higher listening levels.
• Thin-Line 2.53" Mounting Depth — Fits shallower wall cavities than the standard-depth VX66.
• Sonance CDX Crossover — Maintains tonal balance from background levels to louder listening.
• Multiple Grille Options — Micro Trim, trimless, and TRUFIG-mounted grilles are available in Brilliant White satin or custom finishes.

Typical Applications

Exterior walls, thin partitions, and framing with limited stud depth where the standard-depth VX66 will not fit.

Technical Specifications

Frequently Asked Questions

How does the VX66 TL differ from the standard VX66?

It uses the same driver set in a thinner chassis, mounting in 2.53" of depth versus the standard VX66's 3.48".

What cutout size is required?

The cutout measures 6.94" by 10.75", the same as the standard VX66.

What is the power handling rating?

It is rated for 5 watts minimum and 140 watts maximum RMS.

When should I choose the TL version over the standard VX66?

Choose the TL version when the wall cavity is too shallow for the standard 3.48" mounting depth, such as in exterior walls or thin partitions.

What grille finishes are available?

Micro Trim, trimless, and TRUFIG-mounted grilles are available in Brilliant White satin, with custom paint or laser-print options.
