Sonance VX66R SST – Stainless Trim In-Ceiling Speaker
Product Overview
The Sonance VX66R SST is a higher-output round in-ceiling speaker from the Visual Experience Series, finished with a stainless steel trim grille for rooms that need both more output than the VX62R SST and a brushed metal aesthetic.
Product Description
The VX66R SST pairs a 6.5" Kevlar/Nomex woofer with a Ferrofluid-cooled 1.0" ceramic dome tweeter, the same driver set used in the standard VX66R, shaped by a sinusoidal textured waveguide for even dispersion across the room. It mounts at a standard 4.92" depth with an 8.25" cutout and supports the same two-stage installation process used throughout the Visual Experience line. The stainless steel trim grille gives it a distinct look compared to the standard Brilliant White satin finish, making it a common choice for kitchens, wine rooms, and modern interiors that pair audio with metal or stainless appliance finishes. Integrators building a complete Sonance system can pair the VX66R SST with other in-ceiling speakers in adjoining rooms where the standard white finish is preferred.
Key Features
- Stainless Steel Trim Grille — A brushed metal finish that pairs well with modern kitchens and stainless appliances.
- 6.5" Kevlar/Nomex Woofer — Paired with a Ferrofluid-cooled ceramic dome tweeter for higher output than the VX62R SST.
- Sinusoidal Textured Waveguide — Provides even dispersion across the listening area.
- Two-Stage Installation — Allows the bracket to be set before the ceiling is finished.
- Sonance CDX Crossover — Maintains tonal balance across the volume range.
Typical Applications
Kitchens, wine rooms, and modern interiors needing higher-output distributed audio with a stainless steel grille finish.
Technical Specifications
| Tweeter | 1.0" (25mm) ceramic dome, Ferrofluid-cooled |
| Woofer | 6.5" (165mm) Kevlar/Nomex cone, rubber surround |
| Frequency Response | 43Hz – 20kHz (±3dB) |
| Sensitivity | 90dB (2.83V/1m) |
| Power Handling | 5W minimum; 140W maximum (RMS) |
| Cutout Diameter | 8.25" (209.55mm) |
| Mounting Depth | 4.92" (124.97mm) |
| Grille Finish | Stainless Steel Trim |
Frequently Asked Questions
How does the VX66R SST differ from the VX62R SST?
It uses higher power-handling Kevlar/Nomex woofers and a ceramic dome tweeter for more output, sharing the same stainless steel trim grille finish.
What is the mounting depth?
It requires 4.92" (124.97mm) of mounting depth.
What cutout size is needed?
The cutout diameter is 8.25" (209.55mm).
What is the power handling rating?
It is rated for 5 watts minimum and 140 watts maximum RMS.
Is the grille available in other finishes?
Yes, the same driver platform is also offered with a standard Brilliant White satin micro trim grille as the VX66R.
