Sonance VX66LCR – In-Wall LCR Channel Speaker
Sonance VX66LCR – In-Wall LCR Channel Speaker is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sonance VX66LCR – In-Wall LCR Channel Speaker
Product Overview
The Sonance VX66LCR is a larger-format in-wall LCR speaker from the Visual Experience Series, designed for front, center, and surround channels in home theaters that need more output than a standard two-way in-wall speaker. Dual 6.5" Kevlar/Nomex woofers and a ceramic dome tweeter are arranged for clear dialogue and dynamic range in larger media rooms.
Product Description
The VX66LCR pairs two 6.5" Kevlar/Nomex woofers with rubber surrounds around a single 1.0" Ferrofluid-cooled ceramic dome tweeter, giving it more cone area and higher power handling than the smaller VX62LCR for larger rooms or higher-output home theater builds. A sinusoidal textured waveguide shapes tweeter dispersion for consistent coverage across a wide seating area, and Sonance's CDX crossover keeps dialogue intelligible whether the system is playing at reference level or background volume. The speaker installs with a two-piece Flex Frame into a standard wall cavity and accepts Micro Trim, trimless, or TRUFIG-mounted grilles finished in Brilliant White satin, with custom paint or laser-printed options available. Home theater integrators building a full Sonance system can round out the layout with matching in-ceiling surrounds; browse in-ceiling speakers for compatible rear-channel options. The VX66LCR is best specified for front, center, or surround positions in dedicated theater rooms rather than general background music zones.
Key Features
- Dual 6.5" Kevlar/Nomex Woofers — Two Kevlar/Nomex cones with rubber surrounds provide higher cone area for larger rooms.
- Ferrofluid-Cooled Ceramic Tweeter — The 1.0" ceramic dome tweeter is cooled by Ferrofluid for stable output at higher levels.
- Sinusoidal Textured Waveguide — Waveguide loading evens out high-frequency dispersion across a wide seating area.
- Sonance CDX Crossover — A tuned crossover design preserves dialogue clarity across the volume range.
- Two-Piece Flex Frame — Streamlines installation into a standard drywall cutout.
- Multiple Grille Options — Micro Trim, trimless, and TRUFIG-mounted grille styles are available in Brilliant White satin or custom finishes.
- Limited Lifetime Warranty — Visual Experience Series speakers purchased through an authorized dealer carry a limited lifetime warranty.
Typical Applications
Front, center, and surround channel placement in larger home theaters and dedicated media rooms that need higher output than a standard two-way speaker.
Technical Specifications
| Tweeter | 1.0" (25mm) ceramic dome, Ferrofluid-cooled |
| Woofers | Two 6.5" (165mm) Kevlar/Nomex cones, rubber surrounds |
| Frequency Response | 43Hz – 20kHz (±3dB) |
| Sensitivity | 90dB (2.83V/1m) |
| Power Handling | 5W minimum; 140W maximum (RMS) |
| Cutout Dimensions | 6.94" x 14.57" (176.21mm x 370.08mm) |
| Mounting Depth | 3.5" (88.9mm) |
| Dispersion | Sinusoidal Textured Waveguide |
| Finish | Brilliant White (Satin) |
Frequently Asked Questions
How does the VX66LCR differ from the VX62LCR?
The VX66LCR uses higher power-handling Kevlar/Nomex woofers and a ceramic dome tweeter, giving it more output for larger rooms than the VX62LCR.
What is the mounting depth?
The VX66LCR requires 3.5" (88.9mm) of mounting depth.
What cutout size is needed?
The wall cutout measures 6.94" by 14.57".
What is the power handling rating?
Sonance rates the VX66LCR at 5 watts minimum and 140 watts maximum RMS.
What channel positions is it designed for?
It is intended for front, center, or surround channel duty in home theater layouts.
What grille finishes are available?
The VX66LCR ships in Brilliant White satin, with custom paint or laser-printed grille options available.
